DMI 553-4056-0400 Assembly Instructions

Over Bed Table
Item 553-4056-0400
Assembly Instructions
1. Pull the table out from the packaging and lay at on the
ground, Fig. 1.
2. Pull out the knob on the bottom of the table, Fig. 2.
Position the knob over the small hole on the base of the
table, and insert to lock in place. The table will stand
straight up.
3. Pull the knob under the table top, and align it with one of
the holes, Fig. 3. Adjust the table top to the desired angle.
Care of Table
Wash with clean water and mild soap. Dry thoroughly.
WARNING
• Inspect all parts carefully for cracks/breaks prior to use
• Make sure all parts are tight and secure; the push
button pins must be popped out all the way
• Do not place body weight on the table top
• Do not use the table as an aid to transfer in and out
of bed
• Do not place hot beverages on the table when set at
an angle
Toll-Free Customer Care Help Line 800.622.4714
Manufactured for:
Briggs Medical Service Company
1931 Norman Drive South
Waukegan, IL 60085 USA
www.mabisdmi.com
Made in Taiwan
#910-4056-0400
©2010 Briggs Medical Service Company
Fig. 1
Fig. 2
Fig. 3
