Motor Trend SC-4230-BK Installation Instructions

SEAT COVER
INSTALLATION INSTRUCTIONS
FRONT SEAT
1. Remove and cover headrest.
2. Slide the cover evenly over the top
until it reaches the bottom of the
seat.
3. Pull flap through crevice.
4. Fit cover snugly over cushion seat
and connect side strap either under
or behind the seat. Connect straps
hooks to bottom, and avoid wires.
5. Wrap the elastic around the
headrest holes.
REAR BENCH SEAT
1. Remove and cover headrests.
2. Pull seat forward and wrap the
top over the backrest while
aligning straps.(*)
3. Wrap the bottom over the bench
and pull top as well as bottom
cover through the crevice evenly.
4. Attach all elastic hoops with
supplied hooks.
5. Make small cuts for the seat belts
and pull seat belt components
through seat cover.(**)
6. Make small cuts over the
headrest support holes and insert
headrests.
* If possible, removal of cushion bench will make installation easier.
** In the rare occurrence that the bench seat belts are part of the bench and inhibits the usage of the seat covers, temporarily detach the seat belts to
install. Refer to your vehicle manufacturer manual for further information. If the information isn't available, call us for further assistance.
WARNING: Be sure to align the air bag label with the airbag compartment of your seat. An incorrectly positioned seat cover
may interfere with the deployment of a seat mounted airbag. Before driving ensure seat cover is correctly aligned.
Remove headrest and cover headrest.
3
Pull flap through crevice.
1 1
Remove headrests and Pull seat forward and wrap the top over
cover headrests
4
Attach all elastic with hooks.
Scissors
Note: The bench backrest is taller than the seat rest.
1
Slide cover over from top to bottom.
4
Connect straps behind
seat. Attach hooks to
bottom, and avoid wires.
2
the backrest. Align straps.
5
Make small cuts for seat belts.
Pull seat belts through cuts.
TOOLS NEEDED
OR
Retractable Knife
9 PC SET
2
5
Wrap elastic around
headrest holes.
3
Wrap bench. Pull top and bottom
covers through crevice evenly.
6
Make small cuts over
headrest support holes.
