Qhou KRIB-XQB201A-GREY6 Instructions

Spin Dry Quick Start Information window
Water level / Powder Level
Put in correct powder level Pressing the "power" key, will
Touch the power key.
according to the selected water show the standard program which
level and to the preferred is set at 01; Select your program
cleanliness of clothes. code & required wash/spin time
[washing dose please refer to the which are shown in a alternate
Hold down the "water level" key to
indicator diagram] display. Select the required water
enter into the spin only program
level by pressing "water level" and
and begin.
entering the correct code as
shown on the control panel.
If the operation is incorrect, the
display will show the wrong
information; if E2 is displayed on
the screen, it means the cover
has not been closed properly.
Display delay start time.
Water level selection Program Selection
Press "program" to enter
Press the "Water level" key to enter in to
into program selection status.
program selection status, press again and
repeat to increase the selected water level as
Select suitable wash process
required. 1 water level, as: 1L to 8L. (L = level
according to wash clothes –
not liters) please always read the label
1L =Minimum
on the clothing before
8L=Maximum
washing.
Select suitable water level according to the
Standard wash and dry
qty of clothes. 01 = Standard
02 = Soft For easy to damage clothing
03 = Quick wash Fast wash
1L/2L Smallest load of clothing
04 =Heavy duty Heavy fabrics and tough stains
05 = Soak wash Tough stains and normal fabric
3L/4L Lightweight load of clothing
06 = Wash only Only wash function
07 = Spin only Only spin function
5L/6L Standard load of clothing
08 =Tub clean Clean the inside tub
09 = Tub air dry Spin Dry the inside tub
7L/8L
Large amount of clothing or blankets
10 = Water recycle Not drain water after wash
If you wish to delay the washing machines progress for any reason
all you need to do is push the start/pause button again.
Pushing the button again will begin the process; if this does not
work, restart the machine by pushing the power button, the internal
memory will continue its process automatically.
After an Alarm has sounded due to improper activity, the machine
will automatically switch off after 1 hour.
If the machine is on standby for 10 minutes or longer in operation,
the machine will automatically switch off.
The machine was tested before leaving factory.It's normal if there
is some water ,please feel easy yo use.
Delay start Child lock
In operation status, press and hold
the "Water level" and "Program" key
First press Power key.
at the same time. The display
window will show the letters "CL",
Hold down the "Program/ delay star"
all buttons will stop working. If the
key to enter into delay start setting,
door is opened at this time, the
press the button again to increase
washing machine will come to an
the delay start time by 1 hour and
immediate halt. If the door is not
repeat until the time required is
closed in under 5 seconds the
displayed. The maximum delay
washing machine will drain its
start is 24 hours. water automatically and the
machine will sound an alarm.
Once you have selected your time In operation status, press and hold
press the "Start" key, flashing the "Water level" and "Program" key
indicator light in the lower right at the same time again to unblock
corner, setting time and then start the child lock function, then all keys
work. can work again.
Start/Pause Power on/off
After plugging in the washing Press for power on; press again
machine and turning on the power, for power off.
press "Start/ Pause" key to start
the program.
Press it again when machine in
For your safety, if the machine
operation to pause or change the
detects any abnormal behavior
computer program.
it will automatically turn itself off.
If the machine is idle for 10
minutes it will automatically
switch off to conserve electricity.
Please turn the machine back
on by using the power button
and selecting your program.
"L" shape pipe end connect
to the washing machine
"Straight" pipe end connect to the
faucet or adapter.
Don't forget to put this Extra O ring into the
"Straight" Pipe end, when using Adapter.
Extra O ring part X part Y
Reminder:
1. Each machine is tested for water intake and drainage during
production. Therefore, there may be water residues or traces
of water inside the washing tub, which is a normal
phenomenon.
Bottom foam
2. Please remove the bottom foam before using the new machine!
Plastic bracket is only keep the washing machine safe when
shipment,the user can remove it or keep it.
Error Digital Display
Error Reason
Information
Incoming water has taken over 20 minutes to
reach water level.
E1 – Water Inlet Fault
The Inlet Valve is blocked or obstructed.
The Water supply is cut off or the stopcock is
open.
Water drainage has taken over 5 minutes.
E2 – Drainage Fault
Drain valve blocked, damaged or faulty.
Drain pipe is damaged.
E3- Top Cover Fault
The cover is open during use.
Clothes are not level or balanced.
E4 – Spin Fault
The machine is standing at an incline.
The wahser is going to drain the water,now
E5 – Water recycle
you can place the drain pipe in the water tank
reminder
to collect the gray/waste water.
Water level sensor fault.
Water Leakage.
E6 – Water Level Fault
Harness contact is loose.
Airway tube is loose.
Machine is Child locked but the cover has been
E7 – Child Protection
opened.
If unsolved the problem after use above methods, please contact maintenance dept and processional
Remarks
maintenance personnel, customer can not assemble or disassemble.
Reminder and Error Code
Plastic bracket
How to fix
Check the reason for low water pressure, open
and close the cover 1 time to restart operation.
Remove the blockage from the inlet valve,
once done open and close the cover 1 time to
restart operation.
Turn on the water supply or stopcock , once
done open and close the cover 1 time to
restart operation.
Reposition the drain pipe for a more
smooth water drainage, once done open
and close the cover 1 time to restart
operation.
Remove the blockage from the drain
valve, once done open and close the
cover 1 time to restart operation.
Close the cover.
Reposition the clothes in the tub so they
are balanced and level and close the
cover.
Place the washing machine on a level
surface, once done please open and
close the cover.
Place the drain pipe in the water tank,
then open nad close the top cover or
press the "Start/Pause" key to drain the
water.
Unplug the machine, wait 10 seconds
and replug the machine. If issue
continues set water level to normal and
restart the machine.
Ensure that your child is a safe distance
from the machine and close the cover.
