Bath Royale BR720-00 Installation Instructions

Split Wing Nut Installation Instructions
Tools Required: Phillips Head Screwdriver
Important: Rinse and dry underside of mounting bases (confirm clear rubber gaskets are in place).
Clean mounting surface of toilet bowl (around holes) with Windex® or any glass cleaner.
1.
2.
(View from underside of bowl shelf)
Questions? Visit BathRoyale.com or call (704) 589-1009
1. Install mounting bases on toilet bowl.
a. Place mounting bases over holes with posts
facing the front of the bowl.
b. Place stainless steel washers in mounting base
slots.
c. Insert screws through the washers, mounting
bases and holes in the toilet.
2. Install wing nuts. DO NOT turn wing nuts.
Thread wing nut by turning the screw. Do not
completely tighten until the seat is attached and
adjusted.
3. Attach seat, adjust, and tighten screws very
firmly. (It may be necessary to hold wing nut to
keep it from turning.)
Note: Wing nuts work on a wedge principle. For
final tightening, the tips must be centered in the
underside of the mounting hole. If not tightening,
move wing nut around while pushing upward
until tips slip into the hole. As the screw turns, the
points of the wing nut are squeezed tighter into the
mounting hole.
Note: Industry standard mounting holes are round
and / inch in diameter. If your toilet holes are
5
8
not standard we recommend using our "Original"
mounting hardware available at BathRoyale.com.
CARE & CLEANING TIP: DO NOT spray or saturate
the mounting bases. (Doing so may cause the seat
to move out of position.) Spray your cloth first, then
wipe.
