- Page 1 User's Guide Portable Monitor Aluminum alloy anodized metal material Thank you for purchasing this product. Please read this instruction manual carefully and use it correctly.
-
Page 2: Scroll Wheel
Interface & Button Introduction 3.5mm Headphone Hole MiniHDMI Port Scroll wheel Type-C data Port Power/Return Type-C Charging Port Power/Return Connect to a full-featured Type-C Android phone: long press "shut down" or "power on" for more than 3 seconds; short press "return"(When the OSD function is turned on). - Page 3 Basic Connection Operation Of the Device ① Turn On The Power Before Connecting The Device Power the product by connecting to the Type-C power supply port. *Please do not use non-delivered USB power adapters. This will be the reason for the failure. USB Adapter Type-C to USB Cable ※The device can be connected through the delivered power supply.
- Page 4 ③ Connect A C-mount Smart-phone Or Tablet That Can Output Video Smart Phone iPad This Product Type-C to Type-C Cable Type-C to USB cable USB Adapter First of all, make sure to use the delivered USB power adapter and USB to Type-C cable to ...
- Page 5 ⑤ Connect To A Computer With HDMI Port Computer This Product HDMI MiniHDMI Type-C to USB Cable USB Adapter This Product Computer HDMI to MiniHDMI Cable Type-C to USB cable First of all, make sure to use the delivered USB adapter to power this product, and use the ...
- Page 6 ⑥ Connect Other Devices With HDMI Ports Recorder This Product DVD/HDD Burner, etc. HDMI MiniHDMI Type-C to USB Cable USB Adapter Game console with HDMI Port This Product HDMI MiniHDMI Type-C to USB cable First of all, make sure to use the delivered USB power adapter and USB to Type-C cable to ...
- Page 7 Setting Of This Machine <<Menu Panel>> ① Key Operation Method Power/Return 3.5mm Headphone Hole Long Press: On/Off". Scroll wheel Short press: switch between landscape and portrait. Power/Return ② Brightness Brightness 0~100(30/89※) Adjust screen brightness Contrast 0~100(50) Adjust screen contrast Standard Standard mode of image Image suitable for RTS games...
- Page 8 ③ Image Aspect 16:9(Wide)/4:3 Change screen ratio ④ Color Temp. Color Temp. User setting/warm/cool Adjust screen color 0~100(50) Adjust the brightness of RGB red Green 0~100(50) Adjust the brightness of RGB green Blue 0~100(50) Adjust the brightness of RGB blue...
- Page 9 ⑤ OSD Setting Language 12 languages Choose the language to display OSD H.POS. 0~100(50) Set the horizontal position of the display OSD V.POS. 0~100(50) Set the vertical position of the display OSD Time 10~60(10) Set the display time Transparency 0~100(0) Set the transparency of the display ⑥...
-
Page 10: Product Specifications
⑦ Input & Out put Setting Set HDR mode display signal input port Signal aource Type-C / HDMI Low blue light 0~100(0) Reduce blue light Volume 0~100(100) Set the volume level Mute OFF/ON Volume setting Product Specifications Name Portable Monitor Size 346×220×5~10mm Screen Size... - Page 11 Mobile Phone Models That Support Video Output Mate10、Mate10Pro、Mate20、Mate20Pro、Mate20X、Mate RS、Mate30、 HUAWEI P20、P20 Pro、P20 RS、P30、P30 Pro、Honor Note10、Honor V20 Samsung S8、S8+、S9、S9+、S10、S10+、 Note8、Note9、S10 Smartisan R1、Smartisan Pro2S Smartisan Sony XPeria 1(J9110)、XPeria 5、XPeria XZ3 Razer Razer Phone、Razer Phone 2 iPhone iPhone、iPad ONEPLUS One Plus7、7Pro、7T OPPO R17 Pro Asus ROG series of phones AXON 9Pro...
-
Page 12: After Sales Service
After-sales Service Product Quality Assurance This product has a warranty. If the product fails under normal operating conditions in accordance with the instruction manual, please provide the receipt along with the date of purchase and delivery note, so that the product can be repaired for free within one year from the date of purchase, or we will decide whether to exchange for the equivalent product, and we will exchange it.
