FINDAUTO 104595-5328-1634323432 Installation Instructions

CROSS BAR FOR CHVY EQUNX AND GMC TERAN 2011 UP
Removable Cross Rails
Package Contents
Cross Rails
Instruction Sheet
WARNING/LIMITATION:The load you are carrying plus the weight of the rack must not exceed the
maximum weight limitation of the vehicle's factory rack(150 lbs or 68 Kg).
Installation Procedure:
1. Remove the side rail covers from the left and right hand side at the rear of the luggage carrier.
A small flat bladed tool may be required.
2. Lift upward on the cross rail lever, loaded on the top of the cross rail.
3. Slide the cross rail forward into the desired position.
4. Pull cross rail lever down to lock the cross rail into position.
5. Reinstall the luggage carrier rear side rail covers.
Removal Procedure:
1. Remove the side rail covers from the left and right hand side at the rear of the luggage carrier.
A small flat bladed tool may be required.
2. Lift upward on the cross rail lever and slide cross rail rearward out of the side rail.
3. Reinstall the luggage carrier rear side rail covers.
Installation Manual
Quantity
2
1
