JSE JS-01 Instructions

Direct industrial endoscope
INSTRUCTIONS
Product Description
This an industrial endoscope with a high-definition camera, which
is powered by a connected mobile phone and supports display on
the APP as well as photo and video functions. This product is
equipped with a small-diameter high-definition camera with LED
auxiliary lighting. The camera uses a high-sensitivity chip, which
even can also be used normally in a dark working environment.
Safety and Maintenance
Don't hit the camera violently or pull the cable forcefully.
Pay attention that don't scratch the waterproof protective layer of
the probe when using in an environment with sharp protrusions.
The camera is not made of high-temperature-resistant materials.
Please make sure that the temperature inside the engine drops to
normal temperature when used for car engine checking.
When not in use, please ensure that the camera is clean and dry,
and avoid contact with greasy dirt or other corrosive dangerous
items.
This product is not intended for use by persons with limited
physical, sensory or mental abilities.
Keep children out of reach and operation of this device.
This product is an industrial endoscopy camera, not suitable for
medical use or human inspection.Instructions for use
Install APP
Please search for "UseePlus" APP in the APP Store or scan the QR
code below to download and install it. The system supports (IOS9.0
+ and above)
APP introduction
1
Setting
5 9
Enter the photo
Back
2
Connection status 6
Screen rotation
album
prompt
7
Image comparison Take photos/videos
3 10
Photo album
8
Magnification
Color and B&W
4
11
Camera
mode
FAQ help
1. APP does not display pictures
① Check whether the camera light is on, or if the interface contacts
well, re-plug it when necessary
②The camera light flashes during drawing, please keep the power
of the phone above 20%
2. Imaging picture is not clear
The best imaging focal length of the product is: 2cm-10cm, please
calibrate the distance from the object you are looking at, or clean
the front of the camera with a clean alcohol cloth
3: The camera is hot
Camera's heating is normal, especially when the LED light of the
camera is at its highest brightness, but it does not affect normal use
or service life.
Camera
camera diameter 8mm 5.5mm
camera pixel 2 0 0 million pixels
viewing angle
70° 70°
auxiliary lighting 8 LEDs with 6 LEDs with
adjustable brightness adjustable brightness
focus range
20-100mm 20-100mm
IP67
Waterproof rating
JPEG
Photo Format
AVI
Video Format
Accessories
Hook*1,
Magnet*1,
Side Mirror* 1
Instruction manual*1
Camera cable* 1
