Page 1 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 User’s Manual User’s Manual User’s Manual User’s Manual masTER T T T T - - - - Sync Sync Sync Sync Page 1 of 201 User’s Manual...
Page 2: Limited Warranty
For warranty service or repair, products if returned to a service facility at Masibus Head Office, buyer shall prepay all shipping charges to Masibus. Masibus highly recommends that prior to returning equipment for service work, our technical/Customer support department be contacted to provide trouble shooting assistance while the equipment is still installed.
Page 3: Safety Precautions
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 SAFETY PRECAUTIONS The product and the instruction manual describe important information to prevent possible harm to users and damage to the property and to use the product safely. Understand the following description (signs and symbols), read the text and observe descriptions.
Page 4: Table Of Contents
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Table of Contents Unpacking masTER T-Sync Model MTS200R ................. 2-7 Standard Items ........................2-7 Optional Items ........................2-7 Introduction ..........................2-8 GPS Fundamentals ........................3-9 Specification ..........................4-11 Unit Front and Rear Panel Description ..................5-15 masTER T-Sync Model MTS200R Front Panel ..............
Page 5 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Webserver based configuration .................... 106 Serial Communication and Configuration ................107 10.1 Steps to Set Putty for serial communication with MTS200R: ..........108 10.2 Steps to Set HyperTerminal for serial communication with MTS200R: ........110 Timing Outputs –...
Page 6 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Options ........................... 189 15.1 Optional Input Power Supply ....................190 15.1.1 Option 1: AC/DC Power Input ..................190 15.1.2 Option 2: DC Power Input ..................... 190 Appendix List ......................... 191 Troubleshooting ........................
Page 7: Unpacking Master T-Sync Model Mts200R
Documents – User Manual and supporting Appendix manuals, Test Report, Test Certificates(On Customer Request only) • CD for Masibus NTP Utility Software – Qty: 1 INFORMATION • Antenna Cable type (RG6 / RG8) and antenna cable length (15 meters / 30 meters / 50 meters / customized) is shipped only as per customer order.
Page 8: Introduction
MTS200R masTER T-Sync has been developed for the time synchronization requirements in various industries like power, process, IT, telecommunications. Masibus next-generation GPS clock provides enhanced performance and security. It is the most featured and cost-effective GPS time synchronization solution available in 1U compact size. MTS200R is Reliable and provides time accuracy of 150nsec at basic level.
Page 9: Gps Fundamentals
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 3 GPS Fundamentals T-Sync Model MTS200R device is a GPS/GNSS based receiver clock device which provides masTER accurate time output with 1PPS signal. Satellite Navigation system is a system of satellites that provide autonomous geo-spatial positioning with global coverage.
Page 10 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 orbital period of approximately 11 hours, 15 minutes. The overall arrangement is such that, if the constellation is fully populated, a minimum of 5 satellites are in view from any given point at any given time.
Page 11: Specification
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 4 Specification Figure 4-1 masTER T-Sync Model MTS200R Model Timing Accuracy <15 ns with GPS receiver (the receiver is locked on a fixed position). <±0.5 ppm (TCXO) accuracy while GPS Is Unlock* Positioning Accuracy <10mts SEP (with Selective Availability [SA] Disabled).
Page 12 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Serial Protocol: NMEA-0183 (RMC) Port Settings: 9600-8-N-1 Output: RS232/RS485** (Factory Configurable) Interface: 4 way terminal Female Connectors (Rear Panel) No. of Ports: 1 ** RS232 is factory set IRIGB-TTL - DC Level Shift / IEEE 1344/C37.118-2005 Format: IRIG-B(007) [IRIGB TTL] or IEEE 1344/C37.118-2005 (field selectable) Output: TTL into 50 Ω...
Page 13 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Keypad FUNCTION MENU For Entering into Configuration mode. HELP To Display help about every parameter configurations. To save the final Configurations. To come back into Run mode. Scroll between various parameters in ascending order in main menu and to change parameters value in submenu.
Page 14: Physical Dimensions
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 19” Rack Mountable Width:482.6 mm (19”) PHYSICAL Depth:251 mm (9.488”) DIMENSIONS Height: 1 U – 44 mm (3.46”) Weight: 3.1 Kg Approx Ingress Protection: IP20 enclosure Temperature Operating: 0° C to 50° C ENVIRONMENT Storage: -20°...
Page 15: Unit Front And Rear Panel Description
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 5 Unit Front and Rear Panel Description This section provide description of masTER T-Sync Model MTS200R unit front panel and back panel user applicable interface. 5.1 masTER T-Sync Model MTS200R Front Panel Below image shows masTER T-Sync Model MTS200R model front panel.
Page 16: Master T-Sync Model Mts200R Rear Panel
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Scroll between various parameters in descending order in descending order in DOWN main menu and to change parameters value in submenu. main menu and to change parameters value in submenu. To select various available options for the particular To select various available options for the particular LEFT...
Page 17 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 1. Power Supply Card: Input • AC: 90-264V, 47 to 63 Hz&DC: 125-370V), Consumption: 40 W (max) • Plug in screw terminals AWG max. 2.5 mm Output • Power LED status •...
Page 18 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 2. Clock Card: Input • GPS Antenna Input. Relay Output • Relay Rating: AC: 230 V@ 2A; DC: 30V@ 2A / 110V@0.3A/ 220 V@ 0.12 A (max) • C, NO and NC output available •...
Page 19 Model: MTS200R (1U) Doc. Ref. no. : Doc. Ref. no. : - m08A/om/101 Issue no.: 01 3. CPU Card: Output • 1 x 10/100 Mbps ETH0 1 x 10/100 Mbps ETH0 Ethernet port • Optional 1 x 1Gbps ETH1 Optional 1 x 1Gbps ETH1 Ethernet port •...
Page 20 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 4. Relay Card Relay Output • Relay Rating: AC: 230 V@ 2A; DC: 30V@ 2A / 110V@0.3A/ 220 V@ 0.12 A (max) • C - NO/NC selection is possible through hardware jumper.
Page 21 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 5. Event Card: • masTER T-Sync Model MTS200R has the capability to provide multiple event outputs in addition to standard PPM/PPH event output. The single event output provides pulse at configured event interval with pre-configured pulse width.
Page 22 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 6. Serial Card: Serial Output • COM1 and COM2 terminal is RS-232/RS-485 electrical standard DB-9 female connector. • masTER TER T-Sync Model MTS200R provides serial time frame NMEA/T- Format/NGTS format on its COM1 and COM2 terminal.
Page 23 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 7. IRIGB AM/TTL and 1PPS Card PPS Output masTER T-Sync Model MTS200R provides 1PPS output at TTL signal level through BNC connector. Four PPS output is available.LED Status is not available for IRIG-B AM/TTL and PPS o/p.
Page 24 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 8. NTP Card NTP Output T-Sync Model MTS200R masTER provides NTP output at through Ethernet connector. Four NTP is available in single card. Configuration is provided through telnet. Note: Configuration through telnet is explained in the appendix.
Page 25 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 9. Multiple Output Card 1 Multiple output T-Sync Model MTS200R masTER provides Multiple output card. In multiple output card there either modulated output or two TTL output. Two programmable event and 2 Alarm output are also there in the card.
Page 26 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 10. Multiple Output Card 2 Multiple output masTER T-Sync Model MTS200R provides Multiple output card. In multiple output card there either modulated output or one TTL output. 2 Fiber optic outputs are available in the card.
Page 27: Mechanical Dimensions Layout
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 5.3 Mechanical Dimensions Layout Figure 5-3 masTER T-Sync Model MTS200R Mechanical Dimensions Page 27 of 201 User’s Manual...
Page 28: Installation
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 6 Installation Before beginning with unit installation, please follow important safety statements for avoiding installation practices causing malfunctioning of the device as mentioned below. OPERATION RELIABILITY To minimize the possibility of fire or shock hazards, do not expose this instrument to rain or excessive moisture Do not use this instrument in areas under hazardous conditions such as excessive shock, vibration, dirt, moisture, corrosive gases or oil.
Page 29: Gps Antenna Installation
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 WARNING This equipment should be always used with earth grounded. Never defeat the ground connector or operate the equipment in the absence of suitable earth ground connection. WARNING Never work on open unit when power of unit is ON.
Page 30 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 • Offers a full 360° view horizontally, to within 10° vertically of the horizon • Is higher than neighboring buildings/obstructions • Is protected from strong radio frequency (RF) and microwave transmissions •...
Page 31: Mounting The Antenna
Use GPS antenna cable supplied from factory or as per recommended in manual. If antenna cable other than recommended is to be used, contact Masibus Customer Service representative. • Do not cut the antenna cable to shorter its length. Instead, bundle the excess cable to shorten antenna cable length.
Page 32 In-line amplifiers overcome signal attenuation in by amplifying the GPS signal. Use the in-line amplifier for cable runs of 100 to 200 meter. Please contact a masibus Sales Representative for information on how to extend the distance from the antenna to the receiver.
Page 33: Verifying Antenna And Cable Operation
If GPS Surge Suppressor kit is available with purchase order, user should mount it in line with the antenna cable. Additional information on grounding GPS antennas, and grounding in general, are available from masibus Customer Support division (Kit P/N :m-LA-01). Page 33 of 201...
Page 34: Technical Details On Gps Antennas And Cables
Damaged cables may also affect performance. Available Antenna Cables and Accessories for Longer Runs masibus offers longer antenna cables for use with all models of clocks when the standard15 meters (50- foot) cable is inadequate. RG-6 cable runs up to 50 meter, RG-8 cable is available for 100 meters (328 User’s Manual...
Page 35: Unit Installation
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 foot) without the in-line preamplifier. masibus offers in-line amplifier, (P/N: m-LA-01) for long antenna cable requirement up to 200 meters (656 foot). Description Delay, ns Signal Level, dB...
Page 36: Wiring Diagram
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 6.3 Wiring Diagram Figure 6-2masTER T-Sync Model MTS200R Wiring Diagram. User’s Manual Page 36 of 201...
Page 37: Hardware Jumper Setting
COM1 and COM2 terminal RS-232 to RS-485 electrical configurations. However, it is recommended to change the hardware settings after contacting Masibus Customer Support department. For changing above mentioned settings, jumpers are provided on the main card inside the unit. For changing any configuration, follow below procedure step by step.
Page 38: Relay [Rly] Card - Watchdog Relay
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 provided for setting relay output contacts configuration). If required, operator can change the relay contact from C-NO to C-NC contact as explained in below details. 7.1.1 Relay [RLY] Card - WATCHDOG relay: CN8 3-pin jumper on main card is used to change the relay contact for Watchdog relay contacts.
Page 39: Rs232 / Rs485 Output Configurations In Cpu Card
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 RS-232 Configuration: RS-485 Configuration: Table 7-2 COM1 and COM2 terminal RS-232/RS-485 Configuration 7.3 RS232 / RS485 output configurations in CPU Card: 4 pin terminal provides serial NMEA time frame at every second once after unit boots. This terminal can be configured for RS-232 electrical standard or RS-485 electrical standard based communication.
Page 40: Start-Up Operation
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 8 Start-Up Operation 8.1 Receiver Boot-up mode When masTER T-Sync Model MTS200R unit is power up, the time of unit depends on the GPS receiver RTC data. At every Power ON, unit is in UNLOCK mode initially. If GPS antenna is connected after Power ON or was already connected while powering up the unit, the time to getting unit LOCK depends on the duration for which the unit was in Power OFF condition.
Page 41: Battery Backup Rtc And Gps Receiver Ram Configurations
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 8.2 Battery Backup RTC and GPS receiver RAM Configurations: Backup batteries are used to keep the RAM and the Real-Time Clock (RTC) in the receiver running even after unit Power OFF to retain setup and status information, Time, Date, Last Calculated Receiver Position, Almanac and Ephemeris information along with receiver specific parameters allowing resumption of GPS operation automatically once unit mains power is restored.
Page 42 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 • MTS200R is operating system based product so it takes few seconds for boot up which may vary from 15 to 40 seconds to start the main application. During initial boot up period, above two messages are displayed in sequence.
Page 43: Basic Normal Run Mode Operation
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 • Internal NTP driver in operating system takes certain minutes to get the internal clock synchronized within 1 millisecond w.r.t. GPS receiver satellite time as NTP driver adjust (using skew method) its internal clock using complex PLL clock sync method.
Page 44 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 • Other parameters such as Date, GPS LOCK/UNLOCK status and total satellites visible by receiver, as position information, day of week, day of year, type of serial frame format on COM2 terminal, NTP,PPS offset, timezone and DST information are display on 2 line of display.
Page 45 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Status Display: NTP (of internal clock) offset with PPS in milliseconds unit Status Display: Timezone and DST parameter Status Display: Eth0 Port Connection Status Status Display: Eth1 Port Connection Status Page 45 of 201 User’s Manual...
Page 46: Unit Setup Configuration
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 9 Unit Setup Configuration TER T-Sync Model MTS200R setup can be done using front panel keypad buttons or front panel RS-232 based serial console or via Ethernet port eth0 or eth1 using Telnet, SSH, webserver and SNMP. Keypad options provided all basic general settings, network settings for eth0 and eth1 port, network services configuration, GPS receiver related settings and limited NTP server settings.
Page 47 (0001 to 9999.), which can be changed by the user. By factory set, this password is ‘0001’. Another is Immortal Password that cannot be changed by any user and it kept confidential to Masibus Service Engineers. Users are recommended to change the user-defined password as per there requirement.
Page 48 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Figure 9-2 Display Main Menu layout User’s Manual User’s Manual Page 48 of 201...
Page 49: General Settings
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 GENERAL SETTINGS: To enter the configuration mode of MTS200R using front keypad, user need to press “MENU” key and then enter appropriate password. This will allow user to enter configurable parameters option and this parameters can be configured as explained in below section.
Page 50: Set Parity
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 3. SET PARITY COM2 serial port output parity bit at rear panel of MTS200R can be set by using this option. MTS200R is capable to provide serial time frame on COM2 terminal at configurable parity options of NONE / ODD / EVEN.
Page 51: Set Time Format
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Serial Time frame T-format, GPZDA and GPGGA are transmitted at every 1 second while NGTS time frame is transmitted at every 1 minute. Refer section 11.1 for detail description of each time string. As shown above, “LEFT”...
Page 52 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 : After DISPLAY UPDATE RATE option is displayed, press OK key to change its value. After OK key is pressed, cursor will blink which indicates now you can change the value. Its minimum value is 1 second and maximum value is 10 seconds.
Page 53 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 : Cursor will start blinking once user enters this mode by pressing “OK” key. To change specific digit, use “UP” / “DOWN” arrow keys and to change the position of blinking cursor use “LEFT” / ”RIGHT” arrow keys.
Page 54 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 : Cursor will start blinking once user enters this mode by pressing “OK” key. To change specific digit, use “UP” / “DOWN” arrow keys and to change the position of blinking cursor use “LEFT” / ”RIGHT” arrow keys.
Page 55: Time Zone Setting
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Other options in calendar settings are timezone setting for setting the local time, Daylight Settings. All the calendar settings will only become effective once user come out of configuration mode of keypad menu to normal run mode.
Page 56 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 by setting the timezone offset configured in device with respect to UTC time. Timezone format is :hr:min +/- is the offset polarity hr=hours, -12 to +12 min = minutes, 0 to 59 Default timezone set from factory is +05:30.
Page 57 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 m.w.d = month.week of month.day of week of month. This specifies day (0 <= d<= 6) of week (1 <= w<= 5) of month (1 <= m<= 12). Week 1 is the first week in which day occurs and week 5 is the last week in which day occurs.
Page 58: Ethernet Parameters
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 As shown above, “LEFT” and “RIGHT” key are used to change setting of HOUR MODE. “OK” key will save the setting and “ESC” key will reject new setting and keep old value of this parameter in effect and come out of configuration MENU mode to RUN mode.
Page 59 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 communications like Telnet, SSH or Webserver. Network address acquired by DHCP can be viewed on LCD display while navigating to ETH NTW SETTINGS menu. Autoconfiguration is for IPv6 addressing scheme, in which respected Ethernet port will acquire IPv6 address, Subnet Mask and Gateway from network automatically, if the LAN supports IPv6 infrastructure.
Page 60 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 User’s Manual Page 60 of 201...
Page 61 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Configuration of Eth0 (EthX) Parameters 1. Bonding Here, user can configure bonding if MTS200R is with two Ethernet ports. In case of bonding "ENABLE", only configurations of Ethernet port 0 will be applicable to bonding. To configure bonding of Ethernet port 0 and 1, user have to select "ENABLE"...
Page 62 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 3. ETH v4 SUBNETMASK Her, user can configure IPv4 subnet mask for specific port as shown in figure. If DHCP is "ENABLE" for respective port, this configurations will not affect IPv4 address. : Cursor will start blinking once user enters this mode by pressing “OK”...
Page 63 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 automatically. For automatic allocation for IPv6 address, user have to select ENABLE for ETH v6 AUTOCONF and press OK key to save changes as shown in figure. Once, user set AUTOCONF as ENABLE, user need to wait till respected Ethernet port receives IPv6 address from network.
Page 64 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 : Cursor will start blinking once user enters this mode by pressing “OK” key, user can see blinking cursor on 1 position of 2 line. To change specific digit, use “UP” / “DOWN” arrow keys and to change the position of blinking cursor use “LEFT”...
Page 65 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 the position of blinking cursor use “LEFT” / ”RIGHT” arrow keys. UP/DOWN arrow keys will update the digit on which cursor is blinking. After value is edited, press “OK” again to save the parameter or "ESC" to restore parameter value. After user presses “OK”...
Page 66: Ntp Parameters
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 To START/STOP any service follow steps: 1. Go to specific service 2. Press OK key 3. Using UP/DOWN key change START/STOP option. 4. Press OK key User need to restart the particular service if there is any change in those particular service configurations. NTP PARAMETERS: MTS200R act as stratum 1 NTP Server for NTP clients in network.
Page 67: Ntp Service
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 LOCAL CLOCK SERIVCE: MTS200R works on internal clock during Unlock conditions or when internal NTP driver is not synchronized with GPS receiver. User, cannot restart the NTP service during unlock conditions if this parameter is disabled.
Page 68: Reset Unit
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 This parameter instructs the GPS receiver to output the 1PPS output pulse earlier in time to compensate for antenna cable delay. Up to 100 microseconds of equivalent cable delay can be removed. Zero cable delay is set for a zero-length antenna cable.
Page 69: Restore Settings
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 2. Go to option for which you want to configure default settings using LEFT/RIGHT arrow keys. 3. Press OK key. 4. Wait till "Configuring.." message is there on display. Message indicates device is saving new configurations.
Page 70 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 USB Menu User can enter in this menu only if USB Pendrive is connected to USB port of MTS200R at front panel. If USBPendrive is not connected, MTS will blink "NO DEVICE DETECTED". User can do following operations: 1) Firmware Update 2) Configuration Files Update...
Page 71: Console Based Configuration
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Note: 1. If “MENU” key is pressed while configuring this parameter and before saving the new change of this parameter, user will be jumped to “ENTER PASSWORD” option again without saving new settings.
Page 72 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Here fdc2:7142:0:1eba:8cff:fee5:c115 is the Global IPv6 address of the MTS200R. It can be viewed on LCD, Webserver, and SNMP and on console based configuration utility. user: root password: MTS200RLAMBDA Note: Operator can also use “putty”...
Page 73: General Settings
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 INFORMATION • If no data is entered for more than 5 minutes timeout interval, console program “start” will be stopped automatically. After program being stopped, user need to again start the program by above mentioned command to configure device.
Page 74 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Option “2” will allow configuring all parameters mentioned in above figure, as shown in below image. Example: Refer below steps to configure Hour Mode parameter, Step 1: Enter Command number for Hour Mode as given in left most column in above figure, and then press “enter”.
Page 75: Ntp Settings
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Step 4: If there are no parameters to be modified, then enter “0” in “Enter command:” prompt. Thereafter it will ask to save modified parameters. Enter “y” or “Y” for yes and “n” or “N” for not saving them. Once saved, check the parameters update by using option “1”...
Page 76 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 7 = this options restart the ntp service whenever any change to ntp settings or ntp authentication id id done by operator. If ntp service is not restarted, new changes done will not be effective till ntp service is restarted.
Page 77 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 BCAST. Key. 1 NONE/SYMM/AUTO authentication type applicable for ntp broadcast. This can be NONE or has to be same as AUTH. Key parameter. It is for BCAST. Address 1 BCAST.
Page 78 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 MTS200R provides only NTP symmetric key based authentication configuration using SSH, Telnet, serial console port and webserver. However, NTP Autokey based authentication configuration is only provided using webserver access. In order to configure NTP for symmetric key based authentication, it is necessary to configure key Id number and key string (which will be the key identification password) for authentication in ntp.keys file and then configure the added ntp key ID number as trusted key in ntp.conf file.
Page 79 Refer section 11.3 for complete understanding of NTP operation. 2. Default key is provided from factory shipment with key ID number as “1” and key string as “masibus”. However, user can change the key string as per his requirement.
Page 80: Snmp Settings
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 • remote = list of all ntp and time servers available as per defined in /etc/ntp.conf file. • refid = reference name as per individual time servers • st = current stratum value of the ntp server •...
Page 81 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Option “2” in SNMP menu is for configuring each parameter. After pressing option “2”, user will be prompted for command value of each parameter shown in above figure. The command number of each parameter are mentioned in left most column of parameters list.
Page 82 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 “0” is special case to disable SNMP agent configuration for SNMP Manager1. Default: 0 v1 & v2c RO Community public SNMP ro community name for Manager 1 Note: String (v1 / v2c) •...
Page 83 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Manager1 Priv. DES / AES SNMP v3 Encryption Priv. Technique Default: DES Type (v3) Manager1 Priv. User defined SNMP v3 Encryption Priv. passphrase or Passphrase password password Note: •...
Page 84: Ethernet Settings
User defined SNMP system contact information Note: string • Min – 4 chars, Max – 38 chars. • No special characters allowed except _ . , [ ] Default: masibus SNMP Location User defined SNMP system location information string Note: •...
Page 85 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Once user have entered in Ethernet menu “ETH0/1 Network Settings”, below is explanation of various options: 1 = To check current live network settings of Eth0 and Eth1. This are network settings which are alive in system.
Page 86 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 To configure network parameters: Option “3” in Ethernet main menu is used to configure eth0, eth1 parameters as shown in below image. After pressing option “3”, user will be prompted for command value of each parameter shown in above figure.
Page 87 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 If DHCP server is not present, configure this as “0”. Setting eth0 to DHCP will make static configuration IPv4 eth0 network address meaningless. Default: 1 Eth0 IPv4 Address xxx.xxx.xxx.xxx This is v4 format IP address for eth0 port.
Page 88 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 If DHCP server is not present, configure this as “0”. Setting eth0 to DHCP will make static configuration IPv4 eth1 network address meaningless. Default: 1 Eth1 IPv4 Address xxx.xxx.xxx.xxx This is v4 format IP address for eth1 port.
Page 89 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 HTTP Service 0 / 1 Disable (0) or enable (1) HTTP Webserver service in MTS200R. This change will make HTTP service effective on both eth0 & eth1 port. At a time, either HTTP or HTTPS will be active.
Page 90: Network Security Settings
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Syslog1 Address Valid IPv4/IPv6 Syslog server1 v4/v6 format address address. Default: 0.0.0.0 Syslog2 Address Valid IPv4/IPv6 Syslog server1 v4/v6 format address address. Default: 0.0.0.0 Bonding Enable 0 / 1 Disable (0) or enable (1) Bonding in MTS200R.
Page 91 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Below is the explanation for methods to generate SSH and HTTPS security keys through SSH based console configuration utility application. To go to security menu, user need to enter “SEQ” or “seq” in main menu of application utility as shown in below image.
Page 92: Sshv1/V2 Security Keys Menu
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 9.2.5.1 SSHv1/v2 Security Keys menu: Option “1” in security main menu, user can select SSH security menu page. Below image shows the SSH menu page in security settings. This menu allows user to view existing SSH key details, to generate new SSH keys for verison1 and 2, view generated new SSH keys and option to save new generated keys.
Page 93: Https Security Certificate Menu
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 1. Whenever new SSH keys are generated and saved in MTS200R, user need to remove old keys for MTS200R particular IP address at remote PC and then connection with MTS200R new keys can be established.
Page 94 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 User’s Manual Page 94 of 201...
Page 95: Ntp Autokey Menu
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Option “2” is used to generate new HTTPS SSL certificate. MTS200R is capable to generate user defined data based HTTPS certificate. When option “2” is selected, user is prompted to enter few details required for generating security certificate as shown in below figure.
Page 96 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 User need to enter 3 for NTP Autokey settings in console based configuration utility. Once user has User need to enter 3 for NTP Autokey settings in console based configuration utility. Once user has User need to enter 3 for NTP Autokey settings in console based configuration utility.
Page 97 Model: MTS200R (1U) Doc. Ref. no. : Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Whenever a new private certificate is generated by Trusted host, it is Whenever a new private certificate is generated by Trusted host, it is necessary to distribute new key to necessary to distribute new key to all ntp clients for successful associations.
Page 98 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 • Procedure to use NTP Autokey PC Scheme as ntp associations between Procedure to use NTP Autokey PC Scheme as ntp associations between Procedure to use NTP Autokey PC Scheme as ntp associations between MTS200R and ntp clients Procedure for NTP associations between Procedure for NTP associations between MTS200R and client is same as explained in the...
Page 99 Model: MTS200R (1U) Doc. Ref. no. : Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Step 2: Enter the password used to generate the Trusted Server PC keys in password field. After : Enter the password used to generate the Trusted Server PC keys in password field. After : Enter the password used to generate the Trusted Server PC keys in password field.
Page 100 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 webserver and console based configuration utility and selecting IFF scheme in webserver security page or any one of multiple MTS200R connected in a single network as TA. For detailed description please refer 11.3.3.4.2.2 •...
Page 101 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 The keys generated in PC scheme in MTS200R are as follows: IFF Parameter key: “ntpkey_iffkey_MTS200R” IFF Private Key: “ntpkey_host_MTS200R” IFF Private Certificate: “ntpkey_cert_MTS200R” • Procedure to use IFF scheme as ntp associations between MTS200R trusted authority and ntp clients: Step 1: Procedure to use IFF scheme between MTS200R trusted authority and ntp client is same as explained in the 11.3.3.4.2.2.
Page 102 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Step 2: Before generating new key remove the old keys. Now select the IFF scheme as Identify scheme Before generating new key remove the old keys. Now select the IFF scheme as Identify scheme Before generating new key remove the old keys.
Page 103: Default / Restore Settings
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Step 4: After the NTP auto key is transferred from trusted server to server again go to the NTP autokey settings menu in the security menu of console based configuration utility. Now select option 4 to update NTP autokey.
Page 104: Administration Settings Menu
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Option “1” will default General setting to factory default. If user wants to revert to settings which were before default being done, user can use Option “2” to restore the settings. Option “3” will let user view the current settings of General parameters which will be applicable.
Page 105 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Multiple Users can be created for MTS200R device with categories as Super-User, Administrator and Info. Maximum 10 username are allowed within system including “root” user. “root” is default super-user of MTS200R device which cannot be deleted or its username or password modified.
Page 106: Snmp Based Configuration
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Option “4” can delete existing user as shown below. “root” user cannot be modified or deleted. Default factory settings for user are below: Username: root Password: MTS200RLAMBDA 9.3 SNMP based configuration TER T-Sync Model MTS200R support SNMP v1/v2c/v3 protocol for its monitoring and configuration with SNMP Manager.
Page 107: Serial Communication And Configuration
Connect one end of the cross cable to the serial console terminal of device and other endtoan available serial port on your local computer. (If there is no RS-232 terminal in user’s computer, user can use USB- To-Serial convertor. Masibus do not provide USB-To-Serial convertor as part of accessories supplied with TER T-Sync Model MTS200R device).
Page 108: Steps To Set Putty For Serial Communication With Mts200R
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 10.1 Steps to Set Putty for serial communication with MTS200R: 1. Run putty.exe file. Below image will appear when putty software is started. Figure 10-2Putty Software 2. User need to select “Serial” in field “Connection type” as shown in below image. User’s Manual Page 108 of 201...
Page 109 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 3. Now, user need to enter comport number e.g. COM22 in field “Serial line” and baudrate 115200 in field “Speed”. Then click on “Open” which will establish serial communication with MTS200R device as shown in below figures.
Page 110: Steps To Set Hyperterminal For Serial Communication With Mts200R
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 10.2 Steps to Set HyperTerminal for serial communication with MTS200R: Configuration requires a standard 9-way D-type RS-232 cable and standard serial communication software in the PC, such as HyperTerminal. Figure 10-4Path of HyperTerminal Open the HyperTerminal and start new connection on COMx of your PC.
Page 111 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 INFORMATION • Cross cable connection as mentioned in above figure is necessary to communicate with COM2 terminal. • It is recommended to use putty instead of hyperterminal because of limited visible screen size in hyperterminal.
Page 112: Timing Outputs - Serial, Irig-B / Ieee 1344, Ntp
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 11 Timing Outputs – Serial, IRIG-B / IEEE 1344, NTP 11.1 Timing Output – Serial 11.1.1 NMEA-0183 RMC Time frame output TER T-Sync Model MTS200R transmits NMEA time frame on 4 pin Terminal blocks located on the bottom side of the CPU Cardlocated at back panel of unit on every 1 second at 9600 (baud rate), 8 (Data bits), N (NONE parity), 1 (1 stop bit).
Page 113: Ngts Time Frame Output
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Note:Device can be configured to transmit T-format, NGTS, GPZDA or GPGGA time frame through its COM1 or COM2 terminal at rear panel. Configuration of frame type can be done via keypad, via console based configuration utility through serial console terminal or Telnet or SSH, via SNMP or via Webserver.
Page 114: Gpzda Time Frame Output
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Year in Century 0 to 99 Month 1 to 12 Day of Month 1 to 31 Day of Week 1 to 7 Hours 9,10 0 to 23 Minutes 11,12 0 to 59 GMT Marker 0 or 1...
Page 115: Timing Output - Irig-B / Ieee 1344 C37.118-2005
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Note: TER T-Sync Model MTS200R can be configured to transmit T-format, NGTS, GPZDA or GPGGA time frame through its COM1 or COM2 terminal at rear panel. Configuration of frame type can be done via keypad, via console based configuration utility through serial console terminal or Telnet or SSH, via SNMP or via Webserver.
Page 116: Standard Irig-B Output
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 This section will describe IRIG-B Time Code also availability of the same in model MTS200R also configuration for the same. TER T-Sync model MTS200Rcan generate different no of digital as well as analog signals as described in this section.
Page 117: Irig-B Ieee 1344 Extension
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Figure 11-1 IRIG-B waveforms 11.2.2.4 IRIG-B IEEE 1344 Extension: IEEE 1344 protocol has two versions available of which model MTS200R supports is IEEE 1344-2005 which defined in IEEE 1344.C37.118TM-2005 document. IEEE 1344.C37.118TM-2005 extends the Range Commanders Council document by using CF bits of IRIG 200-04.
Page 118: Generated Irig-B Time Codes
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 BCD 8 Position Identifier #7 Time Zone Offset 0.5 Hour 0 = none, 1=additional 0.5 hour time-zone offset Time Quality 4-bit code representing approx. clock time error. 0000 =MTS200R Locked, maximum accuracy Time Quality 1111 =MTS200R failed, data unreliable Time Quality...
Page 119: Connecting Irig-B Time Code
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 IRIG-B DCLS time codes (IRIG-B 00x) and IRIG-B AM time codes (IRIG-B 12x) are always generated simultaneously. Using telnet if we configure the IRIG-B output for IEEE 1344 protocol than both IRIG- B00x and IRIG-B12x gives IEEE 1344 protocol CF bits output.
Page 120: Timing Output - Ntp
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 11.3 Timing Output – NTP 11.3.1 NTP Introduction: NTP (Network time protocol) is a common method for synchronization of hardware clocks in local and global Ethernet networks. The software package NTP is an implementation of the actual version 3, based on the specification RFC-1305.
Page 121 Model: MTS200R (1U) Doc. Ref. no. : Doc. Ref. no. : - m08A/om/101 Issue no.: 01 User should change the stratum level of device carefully, after having knowledge of its NTP Server User should change the stratum level of device carefully, after having knowledge of its NTP Server User should change the stratum level of device carefully, after having knowledge of its NTP Server-Client network hierarchical level architecture.
Page 122: Ntp Server Installations And Configurations
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 FUNCTIONALITY If the stratum level of TER T-Sync Model MTS200R device is configured at 15 under Unlock conditions, no NTP client will synchronize its time with NTP server output as level 15 is the last limit of stratum as per NTP standard 11.3.3 NTP Server Installations and Configurations: 11.3.3.1 NTP General Settings NTP Settings through front panelkeypad:...
Page 123: Ntp Local Clock
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Figure 11-3NTP Settings Menu on Console based utility NTP Settings through Webserver Mode: Figure 11-4NTP Settings Menu on Webserver 11.3.3.2 NTP Local Clock MTS200R is capable to operate on internal local clock whenever there is no GPS Antenna connected to the unit.
Page 124: Ntp Broadcast / Multicast
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 value range. Local clock cannot be disable in GPS Unlock conditions because in unlock conditions, unit is running on its internal clock. Note: The stratum of local clock should be configured as required stratum – 1 because ntp driver always transmit stratum as configured + 1 value.
Page 125 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 User can configure NTP broadcast Authentication via console based utility in Symmetric key mode only and in Symmetric and Autokey authentication via webserver mode. Broadcast Authentication – Symmetric key: Before configuring NTP Broadcast Authentication, user need to configure NTP main Authentication mode to required Broadcast Authentication mode (SYMM / AUTO) for symmetric key and Autokey because ntp driver can be configured only in one authentication mode either Symmetric key or Autokey, at a time for...
Page 126 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 User have to do below changes in client ntp.conf file for receiving ntp broadcast packets. # disable auth keys /etc/ntp/ntp.keys #symmetric key file trustedkey 1 2 8 10 # total trusted keys list broadcastclient key 8 # 8 is key id number required from trusted keys broadcastdelay 0.01...
Page 127: Ntp Authentication
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 6. For multicast with Autokey authentication : User have to do below changes in client ntp.conf file for receiving ntp broadcast packets. # disable auth crypto pw password #Autokey keysdir /etc/ntp # public keys directory path...
Page 128 1 to 9999 key ID values in MTS200R and key string of max. 20 characters only. Factory default key id will be set at ID number 1 and Key string “masibus”. ntp driver will authenticate the ntp messages with symmetric key for only those keys which are defined as trustedkey in ntp.conf file.
Page 129 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Figure 11-5NTP Security Setings on Webserver 2. Now, to configure any key in ntp.keys file as trustedkey in ntp.conf file, go to menu NTP-> NTP Configurations. If trusted key field is to be modified, then user have to ensure the NTP filed “Authentication Type” should be already set as “SYMMETRIC”.
Page 130 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Autokey involves public and private key in which public key cryptography is based on a private key known only to creator or trusted server and a public key known to all participants. NTP client can verify the originator has the private key using the public key and any of several digital signature algorithms.
Page 131 Model: MTS200R (1U) Doc. Ref. no. : Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Figure 11-6NTP Autokey NTP Autokey – PC Scheme Settings on Webserver PC Scheme Settings on Webserver Step 2: After password is entered, click on “Submit Password”. This option will configure the crypto : After password is entered, click on “Submit Password”.
Page 132 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Step 4: PC scheme generates two different Autokey files i.e. Private key file and Certificate file. After : PC scheme generates two different Autokey files i.e. Private key file and Certificate file. After : PC scheme generates two different Autokey files i.e.
Page 133 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 The keys generated in PC scheme in MTS200R are as follows: PC Private key: “ntpkey_host_MTS200R” PC Private Certificate: “ntpkey_cert_MTS200R” • Procedure to use Autokey PC Scheme as ntp associations between MTS200R and ntp clients : Step 1:User should transfer the generated key and certificate to all other ntp clients using secure means such as SCP or HTTPS (using download section) or doing copy &...
Page 134 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 ln –s /etc/ntp/ntpkey_host_MTS200R ntpkey_host_ubuntu ln –s /etc/ntp/ntpkey_cert_MTS200R ntpkey_cert_ubuntu Step 2:Once, key is transferred to ntp clients and links made as per step1, user should configure ntp client ntp.conf file for NTP Autokey PC scheme as explained below. First, add below lines in ntp.conf file.
Page 135 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Step 5: Now, select the option of “Private key” in field “Contents Of” -> copy the contents of “ntpkey_host_MTS200R” file in Dialog box -> click “ADD” option. Similarly, select the option of “Certificate” in field “Contents Of” -> copy the contents of “ntpkey_cert_MTS200R”...
Page 136 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 /home/root/ntp/ntpkey_cert_MTS200Rroot@192.168.100.154:/etc/ntp /home/root/ntp/ntpkey_host_MTS200Rroot@192.168.100.154:/etc/ntp /home/root/ntp/ntpkey_cert_MTS200Rroot@192.168.100.154:/home/root/ntp /home/root/ntp/ntpkey_host_MTS200Rroot@192.168.100.154:/home/root/ntp Where, user = is the username of remote Host PC where keys are to be transferred, 192.168.100.154 = IP address of Server MTS200R where keys are to be transferred /etc/ntp = it is the destination folder where ntp keys are copied.
Page 137 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Now, the IFF parameters key has to be copied to ntp clients machine using secure means. Without a private key, a client cannot masquerade a TA and hence, could not create threat to TA NTP server response.
Page 138 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Figure 11-7NTP Autokey – IFF Scheme Settings on Webserver Step 2: After password is entered, click on “Submit Password”. This option will configure the crypto password in MTS200R ntp configuration file automatically. “Generate NTP Autokey” option will only be enable after “Submit Password”...
Page 139 Model: MTS200R (1U) Doc. Ref. no. : Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Page 139 of 201 User’s Manual...
Page 140: Using Webserver
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 The keys generated in PC scheme in The keys generated in PC scheme in MTS200R are as follows: IFF Parameter key: “ntpkey_iffkey_MTS200R” IFF Private key: “ntpkey_host_MTS200R” IFF Private Certificate: “ntpkey_cert_MTS200R”...
Page 141 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Open MTS200R webserver and go to “Security Page” and download “NTP Autokey IFF Group Key” downloads section in local drive. Now copy this group key in folder where previous keys were generated.
Page 142 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 ln –s /etc/ntp/ntpkey_iffkey_MTS200R ntpkey_iffkey_ubuntu Step 2:Once, key is transferred to ntp clients and links made as per step1, user should configure ntp client ntp.conf file for NTP Autokey IFF scheme as explained below. First, add below lines in ntp.conf file.
Page 143 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Step 3: Now select the IFF scheme and Server mode in field “Certificate Type”. Enter the password used to generate the Server IFF keys in password field and then select “Submit Password” option. The password can be different from the MTS200R trusted Server password.
Page 144: Ntp Service & Status
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 For establishing SSH connection, ssh root@192.168.100.153 Then, remove old autokeys files if any ntp folder, rm –rf /etc/ntp/ntpkey* Now, create MTS200R server ntp IFF private and public key using below command in ntp keys folder as given below.
Page 145 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 • Whenever ntp service is started or restarted, the internal system re- configures the gps receiver using ntp driver which takes few seconds for internal clock to synchronize with gps receiver. As a result, whenever ntp is restarted, display seconds update, serial, event and IRIG output may see some jump in output for 3 to 4 seconds.
Page 146 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 • remote = list of all ntp and time servers available as per defined in /etc/ntp.conf file. • refid = reference name as per individual time servers • st = current stratum value of the ntp server •...
Page 147: Ntp Client Synchronization
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Figure 11-9NTP Server Statistics plot on Webserver User can also download the plotted Graph in jpg or png or pdf format by selecting option on right side corner of graph as shown in below figure. 11.3.4 NTP Client Synchronization: TER T-Sync Model MTS200R NTP output port can be used to synchronize of Windows PC or Unix/Linux based PC in networks.
Page 148: Ntp Hierarchical Time Distribution
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 masTER T-Sync Model MTS200R is available with NTP Utility software which can be used to synchronize Windows PC as NTP client device. If NTP Utility software is used, there is no need to do regedit settings in Windows PC for NTP client configuration.
Page 149 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Figure 11-10 NTP Time distributions in Hierarchical Arrangement As shown in figure 11.3, TER T-Sync receives time form GPS Satellites. According to NTP protocol, GPS satellites are considered to be operating at stratum level 0 as most accurate time source. As the devices passes down to other levels of network architecture, stratum level increases by 1.
Page 150 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 INFORMATION • I.P. address of two NTP ports in GPS should not be same if both NTP ports are to be used in same network domain. • It is recommended that NTP output in network should be used only when once device is Lock after being power UP.
Page 151: Relay And Pulse Outputs
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 12 Relay and Pulse Outputs 12.1 Relay Contact Outputs TER T-Sync Model MTS200R device is equipped with 3 Relay contact outputs for indication of POWER failure alarm, WATCHDOG alarm and GPS LOCK status alarm on back panel of unit. Factory set configuration for relay contacts for all three mentioned outputs is C-NO terminal.
Page 152: Pulse Outputs
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 12.2 Pulse Outputs 12.2.1 1PPS Output TER T-Sync Model MTS200R device provides 1PPS output at every 1 second through its BNC terminal on rear panel of unit. This is TTL signal of 0(low level) to 5V (high level) value. The Pulse width of 1PPS signal is 20% duty cycle i.e.
Page 153: Ethernet Communications: Telnet, Snmp
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 13 Ethernet Communications: Telnet, SNMP 13.1 Telnet Telnet is a session layer protocol to provide bilateral communication using command line interface with remote host. MTS200R support telnet protocol (PORT: 23) for its own configuration of device. User can connect with MTS200R device using telnet command from windows or unix/linux based systems.
Page 154: Snmp
OID (Object Identifier). The address fragment 1.3.6.1.4.1 is fixed by the IANA (Internet Assigned Number Authority) and is the address of the SNMP Private Enterprise MIB’s. The 38306 is the address assigned by IANA to masibus or our Enterprise MIB’s. masibus assigns the addresses after that at our discretion and design.
Page 155: Snmp Operation
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 iv) Get-Bulk-Request: This PDU is optimized version of Get-Next-Request, used to request multiple iteration of Get-Next-Request. It allows the caller to specify – non-repeaters, range of variables which are single valued, max-repetition, no of values to be returned by the call. v) Response: Agent returns this PDU in response to above all PDUs.
Page 156 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 To get/walk variables from TER T-Sync on unlix/linux based SNMP Manger systems: Command for SNMP v1 1. snmpwalk -v 1 -c public 192.168.100.121 .1.3.6.1.4.1.38306 on IPv4 2. snmpwalk -v 1 -c public udp6:[fdc2:7142:77b7:0:1eba:8cff:fee5:bb52] .1.3.6.1.4.1.38306 on IPv6 3.
Page 157 = STRING: "passphrase222" iso.3.6.1.4.1.38306.6.23.0 = STRING: "DES" iso.3.6.1.4.1.38306.6.24.0 = STRING: "passphrase222" iso.3.6.1.4.1.38306.6.25.0 = STRING: "masibus" iso.3.6.1.4.1.38306.6.26.0 = STRING: "Sector" iso.3.6.1.4.1.38306.6.27.0 = INTEGER: 0 TER T-Sync device can be configured by multiple modes such as front panel keypad, SSH, Telnet, HTTP/HTTPS and SNMP Managers.
Page 158 .1.3.6.1.4.1.38306.6.25.0 is the OID of the agent variable which is to be configured, s indicates string and i indicated integer depending on variable data type, “masibus” indicated value of OID in string format. User can use IPv6 address to set string variable as well as multiple variables.
Page 159 To set single string variable: user@ubuntu:~$ snmpset -v 3 -n "" -u usernamesnmp -l authPriv -a MD5 -A passphrase -x DES -X passphrase -e 0x12345678912345 192.168.100.121 .1.3.6.1.4.1.38306.6.25.0 s "masibus" To set multiple variables: user@ubuntu:~$ snmpset -v 3 -n "" -u usernamesnmpv33333 -l authPriv -a MD5 -A passphrase222 -x DES -X passphrase222 -e 0x123456789123456789 192.168.100.121 .1.3.6.1.4.1.38306.6.25.0 s...
Page 160 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 OID of TER T-Sync device is 1.3.6.1.4.1.38306. TER T-Sync SNMP Main branches are given below: Branch Description masibusGPSProductInfo .1.3.6.1.4.1.38306.1 Device basic Information masibusGPSStatus .1.3.6.1.4.1.38306.2 Status of run time device parameters masibusGPSGeneral .1.3.6.1.4.1.38306.3 GPS general parameters...
Page 161 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 masibusGPSTime .1.3.6.1.4.1.38306.2.1.0 String Current Device display time [read only] (will be according to system configurations) [format: minute:hour:seconds] masibusGPSDate .1.3.6.1.4.1.38306.2.2.0 String Current Device display Date [read only] (will be according to system configurations) [format: dd/mm/yyyy] masibusGPSlockstatus...
Page 162 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 type [1] Note: fix value [read-write] masibusGPSCOM2TxFrame .1.3.6.1.4.1.38306.3.7.0 Integer COM2 port serial time string type [1 / 2 / 3 / 4] [read-write] Note: 1=ngts / 2=tformat / 3=GPZDA / 4=GPGGA string masibusGPSStandardEvent .1.3.6.1.4.1.38306.3.8.0 Integer...
Page 163 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Mm(month): 01 <= mm <= 12, w(week): 1 to 5, D(day of week): 0 to 6 Day 0 is a Sunday. e.g.:05.2.4 as Thursday of 2 week of May month. masibusGPSDSTStartTime .1.3.6.1.4.1.38306.3.22.0 string...
Page 164 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 [read-write] Format: xxx.xxx.xxx.xxx masibusGPSEth0v4GTY .1.3.6.1.4.1.38306.4.3.0 string Eth0 v4 gateway address Max chars: 16 [read-write] Format: xxx.xxx.xxx.xxx masibusGPSEth0v4MASK .1.3.6.1.4.1.38306.4.4.0 string Eth0 v4 subnet mask address Max chars: 16 [read-write] Format: xxx.xxx.xxx.xxx masibusGPSEth0v6AUTOCONF .1.3.6.1.4.1.38306.4.5.0 Integer...
Page 165 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 masibusGPSHTTPSopt .1.3.6.1.4.1.38306.4.21.0 Integer To stop/start https service in device. [0 / 1] [read-write] Note: 0=stop, 1=start masibusGPSSNMPSopt .1.3.6.1.4.1.38306.4.22.0 Integer To stop/start snmp service in device. [read-write] [0 / 1] Note: 0=stop, 1=start masibusGPSIPv6opt .1.3.6.1.4.1.38306.4.23.0...
Page 166 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Note: stratum applicable on ntp output will be stratum+1 during unlock. masibusGPSNTPAuthType .1.3.6.1.4.1.38306.5.3.0 string NTP authentication type [read-write] [NONE / SYMM / AUTO] Note: Autokey settings can be done only by webserver. masibusGPSNTPBCTEnable .1.3.6.1.4.1.38306.5.4.0 Integer...
Page 167 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 masibusGPSNTPBCTkey2 .1.3.6.1.4.1.38306.5.8.0 Integer NTP broadcast key id value if broadcast is configured for SYMM broadcast [read-write] address 2. [1 to 9999] Note: keyid entered should be a valid key in ntp.keys file of GPS Clock unit.
Page 168 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 masibusGPSSNMPMngr1v3engin .1.3.6.1.4.1.38306.6.9.0 string SNMPv3 engineid value with Manager1. [read-write] min chars: 4, max chars: 40 Note: String must start with 0x format. masibusGPSSNMPMngr1v3Auth .1.3.6.1.4.1.38306.6.10.0 string SNMP Authentication Type Type for Manger1. [NONE / MD5 / SHA] [read-write] max chars: 4...
Page 169: Snmp Traps
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 masibusGPSSNMPMngr2v3User .1.3.6.1.4.1.38306.6.21.0 string SNMPv3 username Manager2. [read-write] min chars: 4, max chars: 30 masibusGPSSNMPMngr2v3engin .1.3.6.1.4.1.38306.6.22.0 string SNMPv3 engineid value with Manager2. [read-write] min chars: 4, max chars: 40 Note: String must start with 0x format.
Page 170: Webserver
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Message: “ NTP Sync.” or “NTP Not Sync.” Description: Whenever ntpd daemon in device loses sync with internal gps receiver, TER T- Sync will generate this alarm on every change of state. This may happen at every power up of device or ntp service restart of stop/start or internal accuracy loss or manual change of internal system clock.
Page 171 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 TER T-Sync Model MTS200R device can be configured remotely using Serial port, SSH, Telnet and Webserver mode. However, the configuration through Serial port, SSH and telnet is done by running “start”...
Page 172 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Figure Figure 13-1MTS200R webserver login page User need to enter the username and password in login page to gain access to other web pages of User need to enter the username and password in login page to gain access to other web pages of User need to enter the username and password in login page to gain access to other web pages of MTS200R.
Page 173 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Home page is updated only at every loading or refresh of page. This can be done either by selecting menu option in menu index or by pressing refresh button on web browser. Home page display top menu line have link to Home page, General Settings menu, Network Settings, NTP options, SNMP menu, Security page, Device Administration page and logout index.
Page 174 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Figure 13-3MTS200R webserver General page User’s Manual Page 174 of 201...
Page 175 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 As shown in above figure, user can configure general settings of device in webserver. Please refer section 9.1 for each parameter description. Once user modify the required data, click on “Save” options provided at end of page.
Page 176 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Figure 13-5MTS200R Webserver Network Configuration with IPv6 To configure network parameters of eth0 and eth1 of MTS200R, user need to enter respective data in mentioned field in network webpage. In order to configure network settings of eth0 and eth1, first select the tickbox of respective eth interface and then settings of that eth can be edited.
Page 177 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Figure 13-6MTS200RWebserver Network Status Page User can configure syslog server1 and syslog server2 IP address in their respective filed. For further explanation, refer section 13.5. Once user modify the required data, click on “Save” options provided at end of page. This will save the changed parameters in MTS200R.
Page 178 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 For MTS200RNTP settings and internal ntp driver satus, user need to navigate and select the “NTP -> NTP Configurations” for ntp configurations and “NTP->NTP Status” for ntp driver status in menu index. For detailed explanation, refer section 11.3.3.
Page 179 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 For Detailed understanding of each parameter, refer section 13.3. Also, SNMP Traps can be made enabled or disabled for each SNMP Manager, refer section 13.3.4. Once user modify the required data, click on “Save” options provided at end of page. This will save the changed parameters in MTS200R.
Page 180 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 Figure 13-8MTS200RWebserver Security Page HTTPS Certificate: MTS200R can be remotely configured using secured HTTP service i.e. HTTPS with remote PC Web browser. HTTPS security certificate in MTS200R are self-signed SSL security certificate of X509 type. Remote PC can connect with MTS200R using https with address: https://192.168.100.153 or the IP...
Page 181 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 After all fields are entered, “Generate SSL Certificate” tab will be highlighted. Now, click on the “Generate SSL Certificate” will save entered parameters. Now, click on “Save” will start generating SSL certificate for HTTPS communication. This process will take some while and while generating certificate, background will be disabled as shown in below figure.
Page 182 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 SSHv1/v2 keys: MTS200R can be configured and monitored using console based configuration utility. This utility can be executed through SSH communication mode with MTS200R. MTS200R supports SSHv1 and SSHv2 protocol.
Page 183 Model: MTS200R (1U) Doc. Ref. no. : Doc. Ref. no. : - m08A/om/101 Issue no.: 01 When user communicate with MTS200R MTS200R using ssh for first time or when new keys are generated, user using ssh for first time or when new keys are generated, user will be prompt to accept new keys, which should be acc will be prompt to accept new keys, which should be accepted by user to start ssh communication with epted by user to start ssh communication with...
Page 184 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 System Configurations: Process list shows the current process running in MTS200R device. The process list is only refreshed on the loading of webpage. User need to refresh this webpage to see current list of process running in system.
Page 185 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 : MTS will be reboot after clicking submit button Device Configurations: Using Device configurations, user can view the current applicable settings for General settings, Network settings, NTP settings, SNMP settings, ntp.conf file, snmp.conf file and NTP symmetric keys values. User need to select the option and click on “Submit”...
Page 186 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 webserver or console based program. But, Administrator do not have access to console of MTS200R through SSH or Telnet or serial mode. If Administrator tries to have SSH, Telnet or serial session with MTS200R, console based configuration utility “start”...
Page 187: Syslog
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Provides Details regarding “Masibus Automation And Instrumentation Pvt. Ltd.” Contact details. 13.5 Syslog MTS200R is capable to send internal logging messages of /var/log/messages file to configured two remote syslog servers.
Page 188: Auto Configuration
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 • DHCP network for both the interface eth0 and eth1 must be different. If both the interfaces are connected in the same DHCP server than eth0 and eth1 comes in same network which is only supported via bonding option.
Page 189: Options
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 this device, at Power ON conditions in unlock conditions; all outputs of device will have factory set time value and not the correct time. Once unit gets locked, all outputs will get proper time data. TER T-Sync Model MTS200R device enter Holdover mode, when unit goes into Unlock condition from Lock condition and thereafter provides time output depending on the internal clock crystal accuracy.
Page 190: Optional Input Power Supply
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 15.1 Optional Input Power Supply TER T-SyncMTS200R model is available with optional power input connects to Plug in screw terminal. For AC supply operation connect LINE to (L) terminal, Neutral to (N) terminal and safety ground earth to “E”...
Page 191: Appendix List
Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 16 Appendix List Below is the list of mas Model MTS200R supported manuals. TER T-Sync Appendix C – Procedure to configure Windows / Linux PC as NTP Client Appendix D –...
Page 192: Troubleshooting
1) Check Power input cable connected properly 2) Check Power input cable connected to respective terminal. 3) Check Input power is available. 4) Check fuse is melted or not, if fuse is melted please contact masibus support department. 17.2 Wrong time at Unit Power ON If the unit was kept in Power OFF conditions for the duration more than 15 days, as per mentioned in section 8.2, the battery back of internal RTC will get discharged completely.
Page 193 Sync Model MTS200R unit. If antenna cable used for installation is other than provided with masTER T-Sync Model MTS200R unit, please contact Masibus Service department for assistance. 2) GPS Antenna must be installed properly as per suggested in section 5.1.1 and 5.1.2.
Page 194 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 1) masTER T-Sync Model MTS200R is shipped with factory set Ethernet configuration (IP, gateway and subnet address) or DHCP. For DHCP to work properly there should be DHCP server available in network. 2) Check the connection route from masTER T-Sync Model MTS200R Ethernet port to end device and configuration of intermediate Ethernet switches and gateways.
Page 195 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 17.14 Cannot establish telnet communication 1) IP address of GPS ethernet port and telnet device should be same network domain. 2) Please verify the Ethernet connection between GPS ethernet port and telnet device by pinging the IP address of GPS ethernet port.
Page 196 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 17.18 Cannot establish SSH communication 1) IP address of GPS ethernet port and telnet device should be same network domain. 2) Please verify the Ethernet connection between GPS ethernet port and telnet device by pinging the IP address of GPS ethernet port.
Page 197 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 17.22 NTP Client Not synchronized with MTS200R using Symmetric Key Authentication 1) ntp.keys file of MTS200R and ntp client should have same Keyid-string pair at both sides. The required keyid-pair should be configured in ntp.conf file at MTS200R and client side. 2) ntp service at server and client side, should be restarted after configuring ntp.keys and ntp.conf file.
Page 198 Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 1) Autokey password used to generate autokey files at client side should be added in client ntp.conf file. This password can be different from autokey password of MTS200R trusted server.
Page 199 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 3) Authentication type should be same at MTS200R and client side if ntp authentication is used for ntp broadcast/multicast. 4) Multicast frames may be blocked by network IT routers or gateways. 17.29 Not able to create ntp autokey files in MTS200R.
Page 200: Abbreviations
Model: MTS200R (1U) Doc. Ref. no. : m08A/om/101 Issue no: 01 18 Abbreviations 1PPS 1 Pulse per Second Amplitude Modulation Alternate Current Bayonet Neill–Concelman Connector Binary Coded Decimal BCDYR Binary Coded Decimal Year BCDTOY Binary Coded Decimal Time of Year Conducted Emission CISPR International special committee on Radio Interference...
Page 201 Model: MTS200R (1U) Doc. Ref. no. : - m08A/om/101 Issue no.: 01 Personal Computer Parts per million Pulse Per Hour Pulse Per Minute Precision Time Protocol Coordinated Universal Time User Datagram Protocol Range Commanders Council Real Time Clock Request For Comments Radiated Emission RG-6/RG-8 : Radio Grade - 6...
