Eleven Engineering SKAA PL5564-S User Manual

for SKAA OS v2.1 Lightning connector Tx, Model PL5564-S
Each SKAA® receiver uses a Green List to keep track of your favorite transmitters. Using a
favorite transmitter as well as hunting through your favorite transmitters is signaled by a Green
LED. Your receiver can also explore to find new, unknown transmitters. Exploring is signaled by
an Amber LED. If your product has two or more wireless receivers—for example, a left speaker
and a right speaker—that's called a Cluster and all of its pieces act as one. The SKAA Button on
your receiver lets you control which transmitter you're listening to (button with
Essentials
Click Favorites Hunt for your favorite transmitters ...
Click again to switch between hunting for all
transmitters on your Green List and only the
current one
2 Clicks Explore Hunt for new, unknown transmitters
(not favorites)
Hold Add / Delete Manually add / delete the current
(a few seconds) transmitter to / from your Green List
- Auto Add SKAA adds the current Amber
transmitter to your Green List if you listen to it
for 30 minutes
More Commands
3 Clicks Play / Pause Sends
source device (example: computer or iPod
4 Clicks Swing Mode Bond to any transmitter on your
Green List (hint: have just one powered on)
6 Clicks Clear the Green List Start over!
Hold during Make a Cluster of receivers:
power on 1. Make sure the transmitter is powered off
2. Power on the Master receiver while holding
down its SKAA Button—hold the button
down until the Red LED begins to flash
3. With the remaining receivers within 3
meters of the Master receiver, power on
the first one, wait for its Red LED to flash
and then power on the second one.
Continue until all of them are powered on.
4. Once all of the LEDs stop flashing (turn
solid Red), power off all of the receivers
SKAA USER'S GUIDE
Command
Command
/ command to the
 
LED Meaning
(dim)
(flash) = Next one
(solid) = Bonded
(dim)
(solid) = Bonded
to
(flash) = Deleted
to
LED Meaning
or (1 flash) = command
® )
(dim) = Hunting
(solid) = Bonded
(flash) = Green List cleared
(flash) = Master receiver
has entered
'Cluster Up' mode
(solid) = The Cluster has
been successfully
made
logo).
= Hunting
= Hunting
= Added
= Added
sent
