Toky HP Series User Manual

HP Series Timer Relay user Manual
Features:
Dual line 4 digit LED display;
⊙
High timing accuracy;
⊙
Range of setting time and delay time
⊙
can be setted freely (11 kinds);
Multi-mounting size can be choosed;
⊙
1. Model Illustration
HP 4 R B 4 0 W Design Code
Communication Function: 0: Without Communication
Display: 4: 4 Digit Display
Output Alarm: B: One Alarm
Output Type: R: Relay Output S: SSR Output
Power Supply: Blank: 220VAC F: 24VDC
Dimension： 4：48H*48W 6：96H*48W 7：72H*72W （Unit：mm）
HP Series Timer Relay
2. Ordering Code
Model Display Power Supply
Dimension (mm)
HP4-RB40W
4 48H*48W
AC 220V±10% 50Hz
HP6-RB40W 4 AC 220V±10% 50Hz 96H*48W
HP7-RB40W 4 AC 220V±10% 50Hz 72H*72W
3. Technical Specification
Power Supply AC220V±10％ 50Hz
Power Consumption ≤3VA
Mounting Mode
Panel Mount
0.01-99.99S、0.1-999.9S、1-9999S、1-99M59S、0.01-99.99M、0.1-999.9M、
Timing Range
1-99H59M、0.01-99.99H、0.1-999.9H、1-9999H
1-9999M、
Timing Accuracy ±0.1％±0.05sec
Reset Mode
Panel reset, External Connection reset, Auto Reset or Power OFF Reset can be choosed
Input Signal low level effective
Terminal Capacity 3A/250VAC or 6A/30VDC
±1.8KV
Pulse Interference (AC)
AC 1500V 1min
Dielectric
Insulation Impedance DC 500V ≥ 100MΩ
Ambient Humidity ≤85% RH
Ambient Temperature 0～50℃
Page 01 KKHPE02-A/0-20140313
4. Panel Instruction
:Timing Value Display Window
:Setting Value Display Window
:Hour (H), Minute (M), Second (S) Indicate Light
:Relay Output Indicate Light
: Function, SET Key
:Increase Key
:Right Shift Key
: Reset Key
5. Operation Sequence
Function Menu
Menu Sepuence
Menu Function
Under the condition of timing status, press SET more than 3S to enter into function menu, after
parameter modification, press SET for a long time to back to timing status. If there is
Timing Status
no any operation for more than 10S, the meter will return back to the timing status
按SET＞3S automatically (the modification will not be saved)
:Timing value range choose menu,
lower line LED display Max timing
value, H,M,S indicate light seperately
9999H
to show the relative units.
SET
:Delay time range choose menu,
lower line LED display Max delay
time value, H,M,S indicate light
seperately to show the relative units. 9999H
Alarm
SET (F,N mode without this menu)
One
Add Timing Mode: Timing count value increase
One
:Timing mode choose menu
One Minus Timing Mode: Timing count value decrease
SET
：1mS
: Effective pulse width of Input signal
choose menu.
：20mS
SET
: N Mode
: Output Mode choose menu
: C Mode
SET
: Start function
SET
: Power OFF data save choose menu
SET
: Lock key menu
SET
Page 02
Setting Value Modify Menu
Menu Sepuence
Under the condition of Timing status, press
Timing Status
to enter into setting value modify menu.
:Relay Timing value setting menu
When Timing value≥T.off
setting value, Relay ON.
SET
: Output delay setting menu, relay
will reset after Relay OFF
time≥T.on setting value.
SET (N,F mode without this menu)
Setting Range
6. Dimensions (mm)
Panel Size
99.99S 999.9S 9999S 99M59S 99.99M
A
999.9H 99.99H 99H59M 9999M 999.9M
99.99S 999.9S 9999S 99M59S 99.99M B
999.9H 99.99H 99H59M 9999M 999.9M
Model A B C
from 0 to setting value 4:(48*48)
48 48 97.5
6:(96*48) 48 96 97.5
from setting value to 0 7:(72*72) 72
72 97.5
7. Output Logic Table
: F Mode
F Mode
: R Mode
Power
: With start function, after power should press
Pause
or short connect PAUSE terminal, the meter
start to work.
Reset
: Without start function, the meter will work after
power on.
Output
: Power Off Data save function
Max Timing Value
: Without Power Off Data save function
Setting Value T.off
: Without Lock function UP
0
Setting Value T.off
: Lock Panel reset
DOWN
0
: Lock setting value menu + function menu
: Lock panel reset + setting value menu
+ function menu
KKHPE02-A/0-20140313
Setting Range
Menu Function
The parameter can be setting freely
between 0.01S-9999H according to Setting Value
the differnet timing range that you
choosed in function menu
Setting Value
DOWN
The parameter can be setting freely
between 0.01S-9999H according to
the differnet timing range that you
choosed in function menu
Mounting Size
Side Face Size
Setting Value
G +0.5 H
C
-0
Setting Value
D
E
UP
J +0.5
-0
Setting Value
K
F
DOWN
D E F G H(Min) J K(Min)
6.5 91 45 45.5 25 45.5 25
9 88.5 89.5 45 25 90 25
9 88.5 67 67.5 25 67.5 25
Setting Value
Setting Value
UP
Setting Value
DOWN
8. Connection Drawing
Timing Value continue to
increase or decrease,
output will be keeped
before input reset.
Page 03 KKHPE02-A/0-20140313
N Mode
Power
Pause
Reset
Timing value and
Output
output will be keeped
T.off before input reset.
UP
0
T.off
0
R Mode
Power
Pause After timing value
reached T.off setting
Reset
value, Relay ON,
display value will show
Output
T.on timing, relay will
T.off
reset and start the next
T.on
cycle T.off timing after
0
timing value reached
T.off
T.on setting value
0
C Mode
Power
After timing time
Pause
reached T.off setting
Reset
time, Relay ON,
display value reset and
Output
start next cycle timing.
T.off
Relay will reset after
T.on
reached T.on setting
0
value.
T.off
0
HP7
HP4
HP6
Note: If there is any change, please subject to the drawing on the meter!
