- Page 1 HYDRA USER MANUAL Models: HYDRA10 & HYDRA15 1800 790 915 pumpsaustralia.com.au...
-
Page 2: Important Safety Information
USER MANUAL Thank you for purchasing a quality Pumps Australia Hydrostatic (HYDRA). We reserve the right to make changes at any time without incurring any obligation. Owner/User Responsibility: The owner and/or user must have an understanding of the manufacturer’s operating instructions and warnings before using this pressure washer. - Page 3 18. Manufacturer will not be liable for any changes made to our standard machines or any components not purchased from Pumps Australia Pty Ltd. 19. The best insurance against an accident is precaution and knowledge of the machine.
-
Page 4: Before Starting
2. Connect water supply hose to the standard garden hose connector. The water source and supply hose must be capable of providing at least twice the output, for example an HYDRA10 uses 10LPM (Litres Per Minute), a water source of 20 LPM is highly recommended. -
Page 5: Troubleshooting
Cavitation or sucking air Check water supply is turned on Loud knocking noise in pump Pulley loose on crankshaft Check key and tighten set screw Broken or worn bearing Replace bearing PAGE PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915... - Page 6 Continue this process until the test is complete and the desired results have been achieved. (As Seen in Fig 4.) Step 5 Turn off the Hydra unit and Discharge water in pipe. PAGE PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915...
- Page 7 (As Seen in Fig 7.) Water Out Water In Note: Do Not Exceed the maximum pressure of your Hydra Unit! Doing so can and will destroy your unit. PAGE PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915...
- Page 8 PARTS BREAKDOWN USER MANUAL N 1450 ø 24x30 mm HYDRA10 / HYDRA15 44 45 47 48 UN003304-MR KIT RICAMBI / PART KITS UN003305-AS sp_00500_RK_N PUMPS AUSTRALIA PTY LTD PAGE PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.
-
Page 9: Parts Breakdown
11.14 (20630) 13.17 (20634) 15.15 (20637) 15.20 (20897) (FC) 18.20 H (20643) 21.15 (20645) 18.16 H (FP) HYDRA10 / HYDRA15 11.20 H (20631) 13.20 H (20635) 15.20 H (20638) 15.28 H (20640) 18.28 H (21467) 21.20 H (21129) 11.25 H (20632) 14.16 (20636) - Page 10 Pressure Cleaning (Hot, Cold and Steam) Custom Design & Builds powered by Petrol, Diesel, Electric and Hydraulic Driven. At Pumps Australia we pride ourselves on offering a wide range of durable and robust high-pressure cleaners, pumps and systems. All of our units are Australian made and fully assembled and tested at the Pumps Australia facility.
