- Page 1 HZ492900TX AG-ROLLING PAPER FILE CART For assistance with assembly, contact： Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Parts List
HZ492900TX AG-ROLLING PAPER FILE CART Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the Screw diagrams below. - Page 3 Quantity Quantity of 2 of 12 Foot with caster and stopper File folder Quantity Quantity of 4 of 4 Bolt : 1/4”x2” Nut : 1/4”x1/2” Quantity Quantity of 4 of 8 Bolt : 1/4”x1” ¢6*30mm Wood Dowel Quantity Quantity of 4 of 4 Wood plug PVC cover...
- Page 4 HZ492900TX AG-ROLLING PAPER FILE CART Assembly Instructions Unpack and lay parts on clean, padded surface like carpet blanket. Check that you have all parts indicated on the front page Insert nut (2) into predrilled holes on bottom panel (E). Attach post-left (C) & post-right(D)to bottom panel(E )&rail (F) &...
- Page 5 Attached foot (H)& foot(I) to pre-assembly unit on figure 2, turn foot by hand.. Figure3 Turn the pre-assembly unit on figure 3, Attached tray top (A) to top frame (B) inside as shown. Figure4...
- Page 6 Attached file folder (J) to pre-assembly unit in figure 4 as shown. Figure5 Now your rolling paper file cart is ready to use. Figure6...
- Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
