Shark StainStriker PX225 Series Manual

PX225
SERIES
PARTS
A CarpetXpert Tank F Reversible Bristles
B Dirty Water Tank G 6 oz. Deep Clean
C StainStriker Tank Pro Formula
D Crevice Tool H 12 oz. OXY Multiplier
E 3.5" Hand Tool I Spray Trigger
N
A
E
C
K
I
D F G H
Crevice Tool - Best for removing stains in tight spaces and spraying directly on the stain.
3.5" Hand Tool - Excellent for cleaning small stain areas on carpet and upholstery.
7" Hand Tool - Great for cleaning larger stain areas.
Pet Mess Tool - Collects pet messes and keeps them out of the interior of the unit.
NOTE: Not all accessories come with all units. Tools may vary by model. For additional accessories
available, please visit sharkaccessories.com
IMPORTANT SAFETY INSTRUCTIONS – FOR HOUSEHOLD USE ONLY
WARNING
To reduce the risk of fire, electric
shock, Injury, or property damage:
1. Do not put any object into openings. Do not use with any
opening blocked; keep free of dust, lint, hair, and anything
that may reduce air flow.
2. DO NOT modify the plug provided with the appliance. If the
grounded plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact qualified electrician.
3. DO NOT force into outlet or try to modify it.
4. DO NOT pull, close door, or wrap around sharp edges or
corners on the cord. To unplug, grasp the plug, not the cord.
Keep cord away from heated surfaces.
5. To reduce the risk of fire or electric shock due to internal
component damage, use ONLY Shark CarpetXpert/StainStriker
formula in the correct tanks, as intended for use with this
appliance. See Instructions below.
6. The areas around where you are cleaning may become wet,
use care to avoid slipping and falling.
7. Use care when removing and reattaching the hand tool to
the Spot Cleaner to avoid accidental activation of the cleaning
solution.
8. DO NOT spray solution on your skin or in your eyes.
IMPORTANT: Vacuum with traditional vacuum cleaner first before using Spot Cleaner.
J Power Button
K Detach Button
L 7" Hand Tool
M Pet Mess Tool
N Rinse & Go
J
1.
Lift CarpetXpert Tank by the handle to detach
it, then remove the cap.
B
L M
3.
Reattach the cap, then reinstall the tank until
it clicks into place.
Note: When assembling your StainStriker, there may be a little water in or around the water tanks.
This is because we test all units before shipping to ensure the highest quality.
Tip: For smaller stains, use the 3.5" Hand Tool Attachment. For larger areas, use the 7" Attachment.
9. DO NOT fill solution tanks while installed on the appliance. 19. DO NOT place Spot Cleaner on uneven surfaces.
Remove before filling. 20. DO NOT use to pick up:
10. DO NOT operate if there is any wetting of the exterior surfaces
of the appliance. If the appliance is wet, dry with a cloth
before use.
11. To reduce the risk of shock and unintended operation, turn
off and unplug Spot Cleaner before any adjustment, cleaning,
maintenance, or troubleshooting.
12. Before each use, carefully inspect each part for damage
or wear. If a part is damaged or worn out, immediately
discontinue use. DO NOT use if any part is damaged or if Spot
Cleaner is not working as it should, has been dropped, left 21. DO NOT use the following areas:
outdoors, or dropped into water.
13. DO NOT immerse or spray water on the body of the Spot
Cleaner. To clean the surface, wipe with a dry cloth.
14. DO NOT allow to be used by children or as a toy. Close
supervision is necessary when used near children.
15. DO NOT handle plug or Spot Cleaner with wet hands.
16. DO NOT use without the dirty water tank, clean solution tank, 22. Do not leave appliance when plugged in. Unplug from outlet
or filter in place.
17. Use only identical replacement parts. Only use Shark® 23. Keep hair, loose clothing, fingers, and all parts of the body
branded filters and accessories.
18. If plugging unit into extension cord, ensure cord is no more 24. Use extra care when cleaning on stairs.
25. GROUNDING INSTRUCTIONS: This appliance must be
than 50' to prevent damage to the motor.
SAVE THESE INSTRUCTIONS.
READ ALL INSTRUCTIONS BEFORE USING THIS SPOT CLEANER.
GETTING STARTED WITH YOUR SPOT CLEANER
1 2
2.
Add water to the CarpetXpert Tank up to the
Water fill line. Then add Shark Deep Clean Pro
Formula to the Concentrate fill line. Do not use
water hotter than 140°F (60°C).
3
4
4.
Lift StainStriker Tank by its sides to remove it, and
fill with Shark OXY Multiplier to the max fill line.
Replace the cap and tighten it. After cleaning is
complete, OXY Multiplier can be left in the tank.
grounded. If it should malfunction or break down, grounding
provides a path of least resistance for electric current to
a) Large objects reduce the risk of electric shock. This appliance's cord has an
b) Hard or sharp objects (glass, nails, screws, or coins) equipment-grounding conductor and a grounding attachment
c) Large quantities of dust (e.g., drywall dust).
plug. This appliance is for use on a nominal 120V circuit. Make
d) Smoking or burning objects (hot coals, cigarette butts, sure that the appliance is connected to an outlet with the
or matches) same configuration as the plug that is properly installed and
e) Flammable or combustible materials (lighter fluid, grounded in accordance with all local codes and ordinances. No
gasoline, or kerosene)
adapter should be used with this appliance.
f) Toxic materials (chlorine bleach, ammonia, or drain
cleaner)
a) Poorly lit areas
b) Outdoor areas
26. Do not store unit where temperatures reach freezing levels to
c) Spaces that are enclosed and may contain explosive or
avoid damaging internal parts.
toxic fumes or vapors (lighter fluid, gasoline, kerosene,
27. FIRST AID: Keep out of reach of children. Causes skin and
paint, paint thinners, mothproofing substances, or
serious eye irritation. If in eyes, rinse continuously with water
flammable dust).
for 15 minutes. Remove contact lenses if present and easy to
do so. Continue rinsing. If on skin, wash with soap and water.
when not in use and before servicing.
If skin and eye irritation persists, seek medical attention.
28. Please recycle container. Dispose of contents/container
away from openings and moving parts.
with licensed waste disposal site in accordance with the
requirements of the local waste disposal authority. Do not
dispose in drains or watercourses in concentrate form.
5 1
5. 6.
Reinstall theStainStriker tank until it clicks Attach hand tool of your choice to the crevice
into place. tool. Plug the power cord into an electrical outlet
and unwrap the hose. Turn ON unit to begin
cleaning. Combining both formulas will give you
the best stain cleaning results.
EXTRACT SPRAY
fig. 1 fig. 2
For WET stains: For DRY stains:
1. First extract the wet mess with the Crevice Tool. For 1. Spray the stain area and scrub it thoroughly
optimal suction, make sure the tool is tilted forward with the bristles on the selected attachment
(fig 1). (fig 2).
2. Spray the stain area and scrub it thoroughly with the 2. Extract across the stain area, applying
bristles on the selected attachment (fig 2). downward pressure and dragging the tool
3. Extract across the stain area, applying downward backwards across the stain (fig 3). Repeat as
pressure and dragging the tool backwards across the necessary.
stain (fig 3). Repeat as necessary.
Tips
1. For improved suction, tilt the angle of the tool forward (fig 1). More extracted liquid will appear
in the window on the tool as suction increases.
2. Use the rubber side of the reversible bristles to clean softer fabrics.
3.
To rinse carpet or upholstery after cleaning, remove or empty the StainStriker tank and fill the
CarpetXpert tank with water ONLY before spraying.
Grounded
Outlet
Grounded
Outlet Box
Grounding
Pin
AA200
6
SCRUB
fig. 3
