Image transmission Module M240958S
1. Overview
M240958S is an image transmission module designed and manufactured by Autel Robotics
LTD., CO.
The module is developed based on the 4G TD LTE technology platform and is suitable for
point-to-point image and data bidirectional transmission. The module provides the function
of automatically and manually selecting frequency bands, and has super anti-interference
ability.
2. Characteristics
Single power supply, wide voltage input
USB+2 serial ports
Support four-frequency automatic selection, adaptive frequency point
Support wireless upgrade
Automatic network repair
Encrypted transmission
Full industrial grade components to meet the harsh working environment
Product size is small and easy to integrate Specification
Parameter
System
MCU
eMMC/Flash
Frequency
Bandwidth
Output Power
Connector/Definition
Antenna Port
DC Power
Power Consumption
Work Temperature
Humidity
Operation Instruction
Description
Linux/Android
LC1881
16GB/16Gb
900MHz：902-928MHz
2.4GHz：2400-2483.5MHz
5.2GHz：5150-5250MHz
5.8GHz：5725-5850MHz
1.4MHz/10MHz/20MHz
FCC
CE
BM15B-GHS-TB：
12VDC
USB2.0
UARTx2，Baud rate：115200
GPIOx2
IPEX one gen.
18-26V
≤8W@FCC
≤6W@CE
-30℃~85℃
99% No condensation
Version 1.0
Comments
Can support 64GB eMMC
1. Work in one frequency band and
frequency at the same time.
2. Can manually set frequency point.
FCC：≤30dBm
CE：≤20dBm
GPIO customizable
Support less than 5dBi antenna
12V typ.
Advertisement
Summary of Contents for Autel Robotics M240958S
- Page 1 Operation Instruction Version 1.0 1. Overview M240958S is an image transmission module designed and manufactured by Autel Robotics LTD., CO. The module is developed based on the 4G TD LTE technology platform and is suitable for point-to-point image and data bidirectional transmission. The module provides the function of automatically and manually selecting frequency bands, and has super anti-interference ability.
- Page 2 Storage Temperature -40℃~85℃ 3. External dimension FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna.
