Save This Manual for Future Reference
Dust Collector
OPERATOR'S MANUAL
MODEL NUMBER
SC0075
SERIAL NUMBER
PURCHASE DATE
Both model number and serial
number may be found on the
main label. You should record
both of them in a safe place for
future use.
WARNING
Carefully read and understand this entire operator's manual before installing and using this product.
Pay attention to all the cautions and warnings.
Your Tools. Your Shop.
™
Advertisement
Table of Contents
Summary of Contents for SHOPMAX SC0075
- Page 1 Save This Manual for Future Reference Dust Collector OPERATOR’S MANUAL MODEL NUMBER SC0075 SERIAL NUMBER PURCHASE DATE Both model number and serial number may be found on the main label. You should record both of them in a safe place for future use.
-
Page 2: Table Of Contents
Shopmax Tools and Machines for your Shop MAX Performance, MAX Value, MAX Support Shopmax manufactures a full line of rugged, long-lasting √ Backed by decades of proven manufacturing expertise shop tools in several categories, including band saws, Enhanced design features come standard √... -
Page 3: California Proposition 65 Warning
WARNING Cancer and Reproductive Harm. www.P65Warnings.ca.gov. SUPPORT ENVIRONMENTAL Have questions about your SHOPMAX equipment? Call us at 847-327-0566 or 844-YARDMAX, email Recycle unwanted materials instead of disposing of them as waste. All tools, hoses, and packaging us at info@shopmax.com for a replacement. -
Page 4: Specifications
SPECIFICATIONS Model Number SC0075 Motor 120V Power 0.74HP Maximum Air Flow Capacity 677 CFM Interior Hose Diameter 3.94“ Tank Capacity 20 Gal. Decibel(Sound) Rating 79.20 dB(A) Product Depth 37.8“ Product Width 20.08” Product Height 59.84“ Weight 55 lbs SYMBOLS The rating plate on your machine may show symbols. These represent important information about the product or instructions on its use. -
Page 5: Safety
Personal Safety Transporting or performing maintenance or service on a machine with its switch on invites accidents. If the machine should start Do not permit children to operate this machine at any time. www.shopmax.com... - Page 6 • Disconnect tool when changing the filter cartridge or filter connected to the mains supply. bag. • Have damaged switches replaced by a customer service • Avoid accidental start-up. Make sure that the tool is in the OFF workshop. position before plugging in. www.shopmax.com...
- Page 7 If the supply cord is damaged, it must be replaced by the • There is an electrical hazard when improper electrical manufacturer, its service agent or similarly qualified persons in connecting cables are being used. order to avoid a hazard. www.shopmax.com...
-
Page 8: Contents Supplied
Qty. Part Description Quantity Undercarriage Tray of Undercarriage M8 X 40 Housing Complete with Motor M5 X 40 Support Bar Shavings Bag Locking Strap Wheel Cover Suction Hose Support Pipe Filter Bag Hose Adapter V Operator's Manual Hardware Bag www.shopmax.com... -
Page 9: Assembly
Plug the hose coupling onto the suction inlet on the housing. Secure it in place with the supplied hose clamp. Attach the hose coupling to the other end of the hose using a hose clamp. ( See Figure 4 ) Wrench Figure 2 Figure 4 www.shopmax.com... -
Page 10: Know Your Machine
KNOW YOUR MACHINE FEATURES AND CONTROLS Support Bar Filter Bag Housing Complete with Motor Hose Adaptors House Coupling Hose Coupling Shavings Bag Support Pipe Undercarriage with Wheels www.shopmax.com... -
Page 11: Operation
Damaged filters and bags must be immediately changed in order to keep the amount of dust that escapes into the work PPull the mains plug before any adjustments, maintenance or environment as low as possible. repair.Have any work on the device that is not described in this www.shopmax.com... -
Page 12: Transport
Store the equipment and accessories in a dark and dry place at above freezing temperature. The ideal storage temperature is between 5 and 30°C. Store the electric tool in its original packaging. Cover the electric tool in order to protect it from dust and moisture. www.shopmax.com... -
Page 13: Troubleshooting
4. The lumber is wet and dust is from dust collector not flowing through the hose 4. Process lumber with less than 20% moisture smoothly content 5. There is a leak in the hose 5. Inspect and replace hose www.shopmax.com... - Page 14 2. Incorrect fuses or circuit breakers Motor stalls 3. Turn off other machines and retry 3. Overloaded circuit 4. Check the power line for the proper voltage. 4. Low Voltage Use another circuit or have a qualified electrician upgrade the service www.shopmax.com...
-
Page 15: Parts Diagram
20 Gal. Dust Collector Operator’s Manual » PARTS DIAGRAM www.shopmax.com... -
Page 16: Parts List
Hose Coupling 1 Undercarriage Base Plate Hose Coupling 2 Lower Housing Cover Bolt M6x16 Undercarriage U Shape Support 1 Spring Washer 6 Support Block Big Flat Washer 6 Flange Lock Nut M5 Protection Cover Motor Screw ST 4.2x13 Support Bar Switch www.shopmax.com... -
Page 17: Warranty
The customer may have other rights not disclosed herein; and they may vary from state to state. Have questions about your SHOPMAX equipment? Call us at 847-327-0566 or 844-YARDMAX, email us at info@shopmax.com www.shopmax.com... - Page 18 www.shopmax.com...
- Page 19 20 Gal. Dust Collector Operator’s Manual » www.shopmax.com...
- Page 20 Your Tools. Your Shop. ™ 847-327-0566 info@shopmax.com...
