- Page 1 Pure & Easy ASSEMBLY INSTRUCTIONS FTPLSS-4072 FTPLSS-4073 FTPLSS-4074 FTPLSS-4075 TZAB-V1...
- Page 2 NOTICE IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY WICHTIG, FÜR SPÄTERE NACHSCHLAGE AUFBEWAHREN: SORGFÄLTIG LESEN IMPORTANTE, GUARDAR PARA REFERENCIA FUTURA: LEER ATENTAMENTE IMPORTANTE, CONSERVARE PER RIFERIMENTI FUTURI: LEGGERE ATTENTAMENTE IMPORTANT, À CONSERVER POUR RÉFÉRENCE FUTURE : LIRE ATTENTIVEMENT Assemble on a flat, clean and soft surface. Auf einer flachen, sauberen und weichen Oberfläche zusammenbauen.
- Page 3 It is recommended that multiple people assemble this product. Es wird empfohlen, dass mehrere Personen dieses Produkt zusammenbauen. Il est recommandé que plusieurs personnes assemblent ce produit. Si raccomanda che più persone assemblino questo prodotto. Se recomienda que varias personas ensamblen este producto. Please have the following auxiliary tools ready:...
- Page 4 PARTS Item no. Item no. Reference Image Reference Image Qty. Qty.
- Page 5 Item no. Item no. Reference Image Reference Image Qty. Qty.
- Page 6 Item no. Item no. Reference Image Reference Image Qty. Qty. X388 X108 X100 X344...
- Page 7 Item no. Item no. Reference Image Reference Image Qty. Qty.
- Page 8 EXPLODED VIEW...
- Page 9 ASSEMBLY 2pcs 8pcs...
- Page 10 2pcs 2pcs 2pcs 8pcs...
- Page 11 8pcs...
- Page 12 4pcs 16pcs...
- Page 13 4pcs...
- Page 14 2pcs 2pcs 8pcs...
- Page 15 2pcs 2pcs 2pcs 2pcs 8pcs...
- Page 16 4pcs...
- Page 17 4pcs 8pcs NOTES: When assembling the beam: 1.Make sure parts (7B 8R) have the sides with closely spaced holes facing outward and the sides with widely spaced holes facing upward. 2.Ensure parts (6L 6R) have the sides with rectangular latch lock slot facing downward. Part 6L should be on the left side and part 6R on the right.
- Page 18 4pcs 24pcs 24pcs Leave the two screws at the edges unfastened. Leave the two screws at the edges unfastened.
- Page 19 36pcs 6pcs 6pcs 42pcs 4pcs ASSEMBLY INDEX DIAGRAM When fixing the screws, leave the screws on both sides of the component unfastened. Wait until the adjacent component is installed, and then once the two components are overlapped, secure the screws. Fasten the screws according to the numerical order.
- Page 20 36pcs 6pcs 6pcs 42pcs 4pcs ASSEMBLY INDEX DIAGRAM When fixing the screws, leave the screws on both sides of the component unfastened. Wait until the adjacent component is installed, and then once the two components are overlapped, secure the screws. Fasten the screws according to the numerical order.
- Page 21 4pcs 40pcs 6pcs 6pcs 46pcs When fixing the screws, leave the screws on both sides of the ASSEMBLY INDEX DIAGRAM component unfastened. Wait until the adjacent component is installed, and then once the two components are overlapped, secure the screws. Fasten the screws according to the numerical order.
- Page 22 2pcs 2pcs 20pcs 4pcs 4pcs 24pcs ASSEMBLY INDEX DIAGRAM When fixing the screws, leave the screws on both sides of the component unfastened. Wait until the adjacent component is installed, and then once the two components are overlapped, secure the screws.
- Page 23 6pcs 2pcs 2pcs 8pcs...
- Page 24 2pcs 2pcs 2pcs 2pcs 4pcs 4pcs...
- Page 25 20pcs...
- Page 26 2pcs 6pcs 4pcs...
- Page 27 4pcs 4pcs 4pcs 24pcs 24pcs...
- Page 28 12pcs 12pcs 12pcs...
- Page 29 8pcs 4pcs 86pcs 86pcs When fixing the screws, leave the screws on both sides of the component unfastened. Wait until the adjacent component is installed, and then once the two components are overlapped, secure the screws.
- Page 30 Pay attention to the placement of the fastening screws at the overlap joints when nstalling corrugated roofing.
- Page 31 2pcs 2pcs 4pcs 16pcs 6pcs 4pcs 22pcs 2pcs...
- Page 33 56pcs After fixing the screws, there will be some exposed screw parts on the component. Please use the provided plastic protective covers to protect the exposed screw parts, to avoid scratches during use.
- Page 34 2pcs 2pcs 8pcs 2pcs 2pcs 6pcs...
- Page 35 2pcs 6pcs 6pcs 4pcs 1pcs Install part 16 to the side of part M1 (front side panel) with the longer distance from the center screw hole to the edge, and part 22 to the side with the shorter distance.
- Page 36 2pcs 8pcs 8pcs...
- Page 37 10pcs 4pcs 4pcs 2pcs 2pcs 4pcs...
- Page 38 2pcs 10pcs 4pcs 4pcs Install part 16 to the side of part M1 (front side panel) with the longer distance from the center screw hole to the edge, and part 23 to the side with the shorter distance.
- Page 39 2pcs 8pcs 8pcs...
- Page 40 4pcs 4pcs 4pcs 4pcs...
- Page 41 12pcs 12pcs...
- Page 42 4pcs To improve the wind resistance, please be sure to complete this installation step. If expansion bolts or ground stakes are not installed, strong winds may cause the tool shed to collapse. Expansion bolts are crucial for the stability on concrete surfaces, and ground stakes are used for grassy areas.
- Page 43 Installation Completed Installation Abgeschlossen Installation Complétée Installazione Completata Instalación Completada...
- Page 44 HELP CENTER Inquiry Assembly issue Missing parts Returns&Refunds If you encounter any difficulties during assembly, please contact us. Wenn Sie während der Montage auf Schwierigkeiten stoßen, kontaktieren Sie uns bitte. Si vous rencontrez des difficultés lors du montage, veuillez nous contacter. Se incontri difficoltà...
