IOGear GMP1001B Quick Manual

Warranty

IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION EXCEED THE PRICE
PAID FOR THE PRODUCT.
The direct vendor makes no warranty or representation, expressed, implied, or
statutory with respect to the contents or use of this documentation, and especially
disclaims its quality, performance, merchantability, or fitness for any particular
purpose.
The direct vendor also reserves the right to revise or update the device or
documentation without obligation to notify any individual or entity of such revisions,
or updates. For further inquiries please contact your direct vendor.
Contact
Toll Free 866-9-IOGEAR (USA)
Phone: 949-453-8782
23 Hubble
Irvine, CA 92618 USA
www.iogear.com
support@iogear.com

Overview

Start Here!
LED indicator
Mini USB Input/Output
Check button

Requirements / Pre-Cautions

Computer:
Available USB connectivity
Make sure the Voltage of your device ranges between 5V to 6V
Before using this product, please read the following precautions carefully and
follow them. Incorrect use of Lithium-Ion batteries may lead to dangers such as
heating, cracking, fuming, and catching fire. Such as battery heating, cracking,
fuming, and catching fire. The battery performance may also be damaged.
• This product is a precise electronic product. Do not disassemble, refit or
re-combine it by yourself
• Please do not throw, knock, shake or strike the Mobile Pocket Power
• Please do not put the Mobile Pocket Power in water
• Please do not place or carry inflammable, explosive and hazardous articles near
the Mobile Pocket Power
• Only use the special power re-charger provided by the manufacturer otherwise
battery damage can occur
• Please place the Mobile Pocket Power at room temperature
• Keep reach away from children
• Do not connect the positive pole (+) to the negative pole (-)
• When you choose to discard this product and its accessories, do so in
accordance with your local environmental protection laws and regulations
About Us About Us
FUN
IOGEAR offers connectivity solutions that are innovative, fun, and
stylish, helping people enjoy daily life using our high technology
products.
GREEN
IOGEAR is an environmentally conscious company that emphasizes
the importance of conserving natural resources. The use of our
technology solutions helps reduce electronic waste.
HEALTH
IOGEAR supports healthy and fit lifestyles. By integrating products with
the latest scientific developments, IOGEAR's solutions enhance the life of
end-users.
© 2007 IOGEAR, INC.

Operating Procedures

Charging Mobile Pocket Power

1. Connect the Mini USB connection end of the USB charging cable to the
GMP1001B.
2. Plug the USB type A connector to the female port of the USB charging cable.
3. Connect the USB type A connector end to any available USB port of your
computer.
4. When the GMP1001B starts to recharge, the LED on the device will flash blue
light and all four blue lights will remain ON when GMP1001B is fully charged.
Desktop or laptop
GMPT075UM

Using Mobile Pocket Power to charge device

1. Connect the Mini USB connection end of the charging cable to GMP1001B.
2. Select the appropriate connector that fits in your mobile device and plug it into
the female port of the USB charging cable, as shown below.
3. Press the Check button to activate the charging process.
Some models may require the use of
a different connector available at
www.iogear.com
Quick Start Guide
Mobile Pocket Power
GMP1001B
PART NO. Q0343

Charging your iPod and iPhone

1. Connect the Apple USB 2.0 charging cable to your iPod or iPhone.
2. Plug the USB type A female connector to the female port of the USB charging
cable and connect the mini USB end to the GMP1001B as shown below.
3. Connect the Apple USB 2.0 charging cable to the GMP1001B charging cable
4. Press the Check button to activate the charging process. Your iPod or iPhone
will start to recharge and display the charging status.
GMPT076UF

Checking charge of Mobile Pocket Power

Press the Check button to see the energy level left in the Mobile Pocket Power.

Performance Parameters

• Type of battery: Lli-Polymer
• Rated input: 1000mAh max.
• Input power: 4.5V ~ 6.5V
• Rated output: 600mAh max.
• Output power: DC 5.3 ± 0.2V
• Cycle life: 800 times
• Overall size: 3.86 x 2.05 x 0.35 (inch)
• Product weight: 0.13 lb

Package Contents

- 1 x Mobile Pocket Power
- 1 x USB charging cable
- 1 x Mini USB connector
- 1 x USB type A connector
- 1 x USB type A female connector
- 1 x Samsung connector
- 1 x LG connector
- 1 x QSG
- 1 x Warranty/Registration Card
Connector IOGEAR Part No.
1. Motorola / Blackberry / Mini-B USB GMPT003MU
2. USB Type A GMPT075UM
3. USB Type A Female GMPT076UF
GMPT059SS
4. Samsung Phone*
5. LG Phone* GMPT075UM

Product Features

• Works with iPhone and most iPod products
• Designed to fully charge PDAs, mobile phones, Bluetooth headsets,
MP3'as and more
• Charges iPod nano 2nd generation or newer, iPod 4th generation or
newer, iPod Touch, and iPhone
• Charges your device up to two times** with one fully charged Mobile
Pocket Power
• Supplier up to 1600 charges
• Automatically adjusts voltage for efficient charge time
• LED battery capacity indicator
*Some models may require the use of a different connector available at www.iogear.com
**It depends on the battery capacity of specific models

FAQ

Problem Description Possible Cause Solution
A. No response after 1. Need to activate 1. Press the Check button
device connected. charging to activate charging
2. Voltage not supported process
by device 2. Refer to the device QSG
3. Improper connection 3. Check the connection;
between Mobile Pocket make sure connector
Power and your device inserts correctly
4. Wrong connector 4. Make sure the connector
5. Damaged charging matches your portable
cable or connector device
6. Circuit problem in 5. Change charging cable
Mobile Pocket Power or connector
6. Contact local retailer for
repair or exchange
B. Mobile Pocket 1. Improper connection 1. Check the connection and
Power can not between charging reconnect
be charged. Mobile Pocket Power 2. Contact local retailer for
2. Charger is damaged repair
C. Mobile Pocket 1. Electricity of the Mobile 1. Charge the Mobile Pocket
Power can not Pocket Power is too low Power
supply the device
with power and the
indicator light is off
when the 'check'
button is pressed.
1. Mobile Pocket Power
D. Electricity of the 1. Charge the Mobile Pocket
not charged before use
Mobile Pocket Power according to the
2. Original charger not
Power runs out manual until the charging
being used
quickly. LED turns solid
2. Use the original charger
otherwise it may damage
your Mobile Pocket Power
