HIKVISION DS-2CC102N User Manual

HIKVISION DS-2CC102N User Manual

Day/night color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
Day/ Night Color Camera
User Manual
V 2.1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CC102N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION DS-2CC102N

Summary of Contents for HIKVISION DS-2CC102N

  • Page 1 All manuals and user guides at all-guides.com Day/ Night Color Camera User Manual V 2.1.0...
  • Page 2 All manuals and user guides at all-guides.com Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to DS-2CC102/112/192P(N)(-A), DS-CC502/512P(N)(-A), DS-2CC592P(N), DS-2CC532P(N), DS-2CC502/572P(N)-M, DS-2CC102/112/192P(N)-MM, DS-2CC132P(N), DS-2CC511/591P(N)-A, DS-2CC502/512/592P(N)-FB, DS-2CC502/512/572P(N)-FD1/FD2 Day / Night Color Camera.

  • Page 3: Safety Instructions

    All manuals and user guides at all-guides.com Safety Instructions These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may cause if any of the warnings is neglected. Cautions: Injury or equipment damage may cause if any of the cautions is neglected.
  • Page 4 All manuals and user guides at all-guides.com Cautions： Make sure the power supply voltage is correct before using the camera. Do not drop the camera or subject it to physical shock. Do not touch CCD (Charge Coupled Device) modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently.

  • Page 5: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Chapter 1 Introduction ..............1 1.1 Features................... 1 1.2 Functions ................. 1 1.3 Description of Box Camera..........2 1.3.1 Side Panel of Box Camera ..........2 1.3.2 Rear Panel of Box Camera ..........3 1.3.3 Description of Dome Camera ........
  • Page 6 All manuals and user guides at all-guides.com DS-2CC502/512P(N)(-A)/DS-2CC592P(N) ......13 Specifications ................13 Dimensions ................13 DS-2CC511/571P(N)-A .............. 14 Specifications ................14 Dimensions ................14 DS-2CC502/512/592P(N)-FB............15 Specifications ................15 Dimensions ................15 DS-2CC532P/N ................16 Specifications ................16 Dimensions ................16 DS-2CC502/512/572P(N)-FD1/FD2...........

  • Page 7: Chapter 1 Introduction

    All manuals and user guides at all-guides.com Chapter 1 Introduction 1.1 Features This series of the camera adopt high performance sensor and advanced print circuit board design technology with high resolution, low distortion and low noise, etc. The key features as following: High performance image sensor CCD, high resolution, capable of providing clear images.

  • Page 8: Description Of Box Camera

    All manuals and user guides at all-guides.com 1.3 Description of Box Camera 1.3.1 Side Panel of Box Camera Figure 1.1 Side Panel of Box Camera Iris Lens Plug: The camera provides an iris lens plug in negative pattern with four square holes, and the definition of pins is shown above.

  • Page 9: Rear Panel Of Box Camera

    All manuals and user guides at all-guides.com 1.3.2 Rear Panel of Box Camera Figure 1.2 Rear Panel of Box Camera ① Level Adjusting： The level adjusting is valid for iris adjusting in DC drive mode, while invalid for video drive mode. ②...
  • Page 10 All manuals and user guides at all-guides.com Normal AGC: Normal automatic gain control. The gain is about 30dB with this function NAGC turned on. Super AGC: Super automatic gain control. The gain is about 60dB with this function turned SAGC Use it to avoid the spot caused by different circuit power.

  • Page 11: Description Of Dome Camera

    All manuals and user guides at all-guides.com 1.3.3 Description of Dome Camera Bubble Camera Drive Side Cover Back Box Figure 1.4 DS-2CC502/512/592P(N)(-FB), DS-2CC532P(N),DS-2CC502/572P(N)-M Figure 1.5 DS-2CC511/591P(N)-A Figure 1.6 DS-2CC502/512/572P(N)-FD1/FD2...

  • Page 12: Chapter 2 Installation

    All manuals and user guides at all-guides.com Chapter 2 Installation Prior to mounting, please make sure that the device in the package is in good condition and all the assembly parts are complete. 2.1 Box Camera Mounting Note: The lens must be the CS assembly type with the weight less than 1kg. The outshoot part behind the mounting surface must be less than 5mm.
  • Page 13 All manuals and user guides at all-guides.com Figure 2.1.2 Install the Camera Adjust the camera to the desired monitoring location, and then tighten the screws on the mounting bracket to secure the camera in position. Install the lens into the camera, and fasten the lens after having adjusted the focus. Figure 2.1.3 Install the Lens...

  • Page 14: Dome Camera Mounting

    All manuals and user guides at all-guides.com 2.2 Dome Camera Mounting The following section has described the DS-2CC511/591P(N)-A series dome camera installation as the example. Note: the mounting wall must be with certain thickness and capable of supporting three times the weight of dome camera.
  • Page 15 All manuals and user guides at all-guides.com Figure 2.2.3 Adjust Lens Rotate the bubble in clockwise direc tion to replace it to the dom e camera. Figure 2.2.4 Replace the Bubble The installation of DS-CC502/512P(N)(-A) , DS-2CC592P(N), DS-2CC50 2/512/592P(N)-FB, DS-2CD502/512 P(N)-FD1 /FD2, DS-2CC532P(N) and DS-2CC502/572P(N)-M series dome camera keep the same with the instructions described above.

  • Page 16: Appendix

    All manuals and user guides at all-guides.com Appendix DS-2CC102/112/192P(N)(-A) Specifications Model DS-2CC102P(N)(-A) DS-2CC112P(N)(-A) DS-2CC192P(N)(-A) Parameter Image Sensor 1/3 inch SONY CCD Signal System PAL / NTSC Effective Pixels PAL: 500 (H) × 582 (V) PAL: 752 (H) × 582 (V) PAL: 752 (H) ×...

  • Page 17: Ds-2Cc102/112/192P(N)-Mm

    All manuals and user guides at all-guides.com DS-2CC102/112/192P(N)-MM Specifications Model DS-2CC102P (N) -MM DS-2CC112P (N) -MM DS-2CC192P (N) -MM Parameter Image Sensor 1/3 inch SONY CCD Signal System PAL / NTSC Effective Pixels PAL: 500 (H) × 582 (V) PAL: 752 (H) × 582 (V) PAL: 752 (H) ×...

  • Page 18: Ds-2Cc132P(N)

    All manuals and user guides at all-guides.com DS-2CC132P(N) Specifications Parameter Model DS-2CC132P/ DS-2CC132N Image Sensor 1/4 inch CMOS Signal System PAL / NTSC Effective Pixels 640 (H) × 480 (V) Min. Illumination 0.1Lux @ F1.2 Electronic Shutter 1/25 s to 1/15,000 s Auto Iris Lens ---- Lens Mount...

  • Page 19: Ds-2Cc502/512P(N)(-A)/Ds-2Cc592P(N)

    All manuals and user guides at all-guides.com DS-2CC502/512P(N)(-A)/DS-2CC592P(N) Specifications Parameter Model DS-2CC502P (N)(-A) DS-2CC512P (N)(-A) DS-2CC592P (N) Image Sensor 1/3 inch SONY CCD Signal System PAL / NTSC Effective Pixels PAL: 500 (H) × 582 (V) PAL: 752 (H) × 582 (V) PAL: 752 (H) ×...

  • Page 20: Ds-2Cc511/571P(N)-A

    All manuals and user guides at all-guides.com DS-2CC511/571P(N)-A Specifications Parameter Model DS-2CC511P (N)-A DS-2CC591P (N)-A Image Sensor 1/3 inch SONY CCD Signal System PAL / NTSC Effective Pixels PAL: 752 (H) × 582 (V) NTSC: 768 (H) × 494 (V) Min.

  • Page 21: Ds-2Cc502/512/592P(N)-Fb

    All manuals and user guides at all-guides.com DS-2CC502/512/592P(N)-FB Specifications Parameter Model DS-2CC502P (N)-FB DS-2CC512P (N)-FB DS-2CC592P (N)-FB Image Sensor 1/3 inch SONY CCD Signal System PAL / NTSC PAL: 500 (H) × 582 (V) PAL: 752 (H) × 582 (V) PAL: 752 (H) ×...

  • Page 22: Ds-2Cc532P/N

    All manuals and user guides at all-guides.com DS-2CC532P/N Specifications Parameter Model DS-2CC532P/N Image Sensor 1/4 inch CMOS Signal System PAL / NTSC Effective Pixels 640 (H) × 480 (V) Min. Illumination 0.1Lux @ F1.2 Electronic Shutter 1/25s to 1/15,000s Lens 3.6mm @ F2.0 (6mm, 8mm, 12mm, 16mm optional) Horizontal Resolution 480TVL...

  • Page 23: Ds-2Cc502/512/572P(N)-Fd1/Fd2

    All manuals and user guides at all-guides.com DS-2CC502/512/572P(N)-FD1/FD2 Specifications DS-2CC502P / DS-2CC512P / DS-2CC572P / Model 502N-FD1 / FD2 512N-FD1 / FD2 572N-FD1 / FD2 Parameter Image Sensor 1/3" SONY CCD Signal System PAL / NTSC PAL:500 (H) × 582 (V) PAL:752 (H) ×...

  • Page 24: Dimensions

    All manuals and user guides at all-guides.com Dimensions...

  • Page 25: Ds-2Cc502/572P(N)-M

    All manuals and user guides at all-guides.com DS-2CC502/572P(N)-M Specifications Model DS-2CC502P(N)-M DS-2CC572P(N)-M Parameter Image Sensor 1/3"SONY CCD Signal System PAL/NTSC PAL: 500 (H) × 582 (V) PAL: 752 (H) × 582 (V) Effective Pixels NTSC: 510 (H) × 492 (V) NTSC: 768 (H) ×...
