HIGH PRESSURE
WASHER
User Manual
GMGPW3200-LT
WARNING: SAVE THIS MANUAL FOR FUTURE REFERENCE
This manual contains important information regarding safety. Operation,
maintenance and storage of this product. Before use, read carefully and
understand all cautions, warnings, instructions and product labels. Failure to
do so could result in serious personal injury and/or property damage.
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMGPW3200-LT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GENMAX GMGPW3200-LT

Summary of Contents for GENMAX GMGPW3200-LT

  • Page 1 HIGH PRESSURE WASHER User Manual GMGPW3200-LT WARNING: SAVE THIS MANUAL FOR FUTURE REFERENCE This manual contains important information regarding safety. Operation, maintenance and storage of this product. Before use, read carefully and understand all cautions, warnings, instructions and product labels. Failure to...

  • Page 2: Table Of Contents

    CONTENTS PRODUCT SPECIFICATIONS ....................1 SAFETY Safety Symbols And Meanings ................... 2 Operating Instructions and Precautions ................3 SETUP Know Your Pressure Washer ....................9 Assembly .......................... 11 General Information ......................12 OPERATION Pre-start Checks ....................... 14 Starting The Engine ......................16 Pressure Washer Operation .....................

  • Page 3: Product Specifications

    PRODUCT SPECIFICATIONS Model GMGPW3200-LT Pump Swash Plate Pump MAX Pressure (PSI) 3200 MAX Fiow (GPM) High Pressure Hose (ft) 25' (7.6m) Nozzle Type 0°,15°, 25°, 40°, Soap Model 170F/P Displacement (cc) Engine Type Single Cylinder 4-Stroke OHV Starting Mode Recoil Start...

  • Page 4: Safety

    SAFETY This Operating Manual has been designed to instruct you on the correct operation of your product. Your satisfaction with this product and its safe operation is our ultimate concern. Therefore， please take the time to read the entire manual， especially the safety symbols and instructions They will help you to avoid potential hazards that may exist when working with this product.

  • Page 5: Operating Instructions And Precautions

    SAFETY Important Operation Instructions and Precautions: DANGER: POISONOUS GAS HAZARD Engine exhaust contains carbon monoxide, a poisonous gas that WILL kill you in minutes. You CANNOT smell it, see it, or taste it. Even if you do not smell exhaust fumes, you could still be exposed to carbon monoxide gas. Some chemicals or detergents could also be harmful if inhaled or ingested, resulting in death, serious injury, nausea, fainting or poisoning.
  • Page 6 SAFETY WARNING: READ AND UNDERSTAND ALL SAFETY INSTRUCTIONS • Keep guards in place and in working order. Never operate this product with any guard or cover removed. Make sure all guards are intact and operating properly before each use. • Remove adjusting tools and wrenches.
  • Page 7 SAFETY WARNING: Fire / Hot Surface Hazard Exhaust could ignite combustibles, resulting in death or serious injury. Contact with muffler area could cause burns resulting in serious injury. • DO NOT touch hot parts and AVOID hot exhaust gases. • Allow equipment to cool before touching. •...
  • Page 8 SAFETY WARNING: Fire / Explosion Hazard Fuel and its vapors are extremely flammable and explosive which could cause burns, fire or explosion resulting in death or serious injury. Risk of fire and serious burns: Never remove fuel cap when unit is running. Shut off engine and allow the unit to cool at least five minutes.
  • Page 9 SAFETY WARNING: Fluid Injection WARNING: Moving parts hazard Starter and other rotating parts The high-pressure water that could entangle hands, hair, this equipment produces could clothing or accessories, resulting in cut through skin and its underlying serious injury. tissues, resulting in serious injury and possible amputation.
  • Page 10 SAFETY WARNING: Chemical Burn WARNING: Electrical Shock Chemicals could cause burns Contact with power source could resulting in death or serious cause electric shock or burn injury. resulting in death or serious injury. • DO NOT use caustic liquid with pressure washer.

  • Page 11: Setup

    SETUP CAUTION: Read Manual Read the entire SAFETY section at the beginning of this manual including all text under subheadings therein before set-up or use of this product. High pressure washer component identification...
  • Page 12 SETUP A - 25' High Pressure Hose L - Wheel B - Fuel Tank and cap M - High Pressure Hose Outlet C - Choke N - Water Inlet D - Fuel Valve Lever O - Nozzle Cleaner E - Soapbox P - Red Nozzle 0°...

  • Page 13: Assembly

    SETUP ASSEMBLY: 2. Align the panel with the four holes in the frame where the panel is to be placed. Install Handle 3. Insert the bolted connection panel. Tighten with a wrench until the frame Install upper frame (handle) onto the lower tube is slightly compressed.

  • Page 14: General Information

    SETUP Wand Spray Gun Tip Connecting Nozzles Attach the Nozzle to the Wand by pulling Connecting Method of Spray Gun: back the quick connect collar and Attach high pressure hose(D) to the pushing the Nozzle onto the end of the gun(A),Connect the spray gun connector Wand.
  • Page 15 SETUP GENERAL INFORMATION: Water Use only cold water. Do not operate pressure washer with clogged or missing water inlet filter screen. Do not operate pressure washer without adequate water supply. Pressure Pressure setting is pre-set at factory. Adjustment For lowering pressure, refer to“Pressure Adjustment". High Pressure There are no serviceable parts to the high-pressure pump.

  • Page 16: Operation

    OPERATION CAUTION: Read Manual Read the entire SAFETY and SET UP sections at the beginning of this manual including all text under subheadings therein before operation of this product. Improper use or treatment of Pressure Washer can damage internal components and shorten the life of unit.
  • Page 17 OPERATION Pre-Start Checks (Continued) WARNING: Fire / Explosion Hazard Fuel and fuel vapor are extremely flammable and explosive. Fire or explosion from misuse of fuel can cause severe burns and even death. • Fill the fuel tank in a well-ventilated area away from ignition sources. If the engine is hot from use, shut the engine off and wait for it to cool before adding fuel.

  • Page 18: Starting The Engine

    OPERATION Starting the Engine CAUTION: Read Manual Read the entire Pre-Start Checks section of this manual before attempting to start the engine. Be sure to inspect the equipment and engine for any missing or loose guards or parts. Check both the fuel and oil levels of the engine before starting. •...

  • Page 19: Pressure Washer Operation

    OPERATION Pressure Washer Operation WARNING: Eye protection / Fluid Injection hazard ALWAYS wear approved safety glasses when operating Pressure Washers. Spray can splash back or propel objects, including incorrectly attached accessories. The high-pressure stream of water that this equipment produces can cut through skin and its underlying tissues, leading to possible amputation.
  • Page 20 OPERATION HI PRESSURE, NO SOAP INJECTION SOAP 0° RED 15° YELLOW 25° GREEN 40° WHITE 65° BLACK AGGRESSIVE GENTLE 0° Nozzle . Red: This nozzle delivers a pinpoint stream of pressurized water and is extremely powerful. Use it for the toughest cleaning jobs, although It covers only a small area.
  • Page 21 OPERATION 3. Using the Spray Gun. 4.6 For most effective cleaning, keep spray nozzle from 8 to 24 inches away from cleaning surface. If you WARNING: get spray nozzle too close, you may • To prevent accidental discharge of high- damage surface being cleaned.

  • Page 22: Stopping The Engine And Pressure Washer

    OPERATION barb near the high-pressure hose Stopping the Pressure Washer connection area of the pump. 6.7 Submerge the strainer end of the To stop the engine in an emergency, turn siphon tube in the soap/detergent the Engine Switch to the off position. solution bottle or bucket.

  • Page 23: Maintenance

    MAINTENANCE NOTICE: Regular maintenance will improve the performance and extend the life of your Pressure Washer. Service should be done by a qualified person or technician. Pressure Washer's warranty does not cover items that have been subjected to operator abuse or negligence. Only by maintaining Pressure Washer in accordance with instructions in this manual will the full value of the warranty be honored.

  • Page 24: Pump Maintenance

    MAINTENANCE Pump Maintenance Cleaning Pressure Washer NOTICE: The pressure pump is Daily or before use inspections should maintenance free. If you notice any sign of include areas around and underneath oil leakage in and around the pump, DO Pressure Washer looking for signs of fuel NOT operate the pressure washer.

  • Page 25: Adding Engine Oil

    MAINTENANCE 1. Remove the drain plug and, if possible, Spark Plug Maintenance: tilt the crankcase slightly to help drain the 1. Disconnect spark plug cap from end of oil out into the pan. Recycle used oil. plug. Clean out debris from around spark 2.

  • Page 26: Air Filter Maintenance

    MAINTENANCE Air Filter Maintenance: to form in the fuel system or crucial carburetor parts. To keep fuel fresh, add 1. Remove the Air Filter Cover and the air fuel stabilizer to the fuel tank. Draining filter(s) and check for dirt. Clean as gasoline is unnecessary if the fuel described below.
  • Page 27 MAINTENANCE Storing Accessories Storage Area The pressure washer is equipped with Cover and store in a dry, level, well- a place to store accessories. ventilated area out of reach of children. Storage area should also be away from ignition sources, such water heaters, 1.

  • Page 28: Trouble Shooting

    MAINTENANCE Trouble Shooting Problem Possible Causes Possible Solutions Engine will No fuel in tank or fuel valve is in Fill fuel tank with fresh 87 + octane not start. “OFF” position. unleaded stabilizer-treated gasoline and turn fuel valve to “ON” position. Do not use gasoline with more than 10% ethanol (E15, E20, E85, etc.).
  • Page 29 MAINTENANCE Troubleshooting continued Problem Possible Causes Possible Solutions Engine will Loose or broken spark plug. Tighten spark plug. If that does not not start. (Hissing noise will occur when work, replace spark plug. (cont). trying to start.) If problem persists, may have head gasket problem.
  • Page 30 MAINTENANCE Engine Defective fuel tank cap creating Test/replace fuel tank cap. suddenly vacuum, preventing stops proper fuel flow. (cont). Faulty magneto. please submit to an authorized dealer. Disconnected or improperly Secure spark plug cap. connected spark plug cap. Engine Dirty air filter Clean or replace filter element.
  • Page 31 MAINTENANCE Troubleshooting continued Problem Possible Causes Possible Solutions Output Not enough water supply. Check water supply hose for kinks, pressure leaks, or blockage. Open faucet all varies the way. Water inlet screen is clogged. Remove and clean filter screen. Nozzle is clogged. Clean Nozzle (See “Cleaning Nozzle”).
  • Page 32 6800.W18.GEM.02.01 V1...
