- Page 1 GREYSTONE Microwave Oven MODEL (LIPPERT PN) P100D48AL-JC (2022302271) OWNER'S INSTRUCTIONS Please read these instructions carefully before installing and operating the oven. Please save sales receipt for warranty.
- Page 2 CCD-0009770 Rev. 03-27-25...
- Page 3 CCD-0009770 Rev. 03-27-25...
- Page 4 CCD-0009770 Rev. 03-27-25...
- Page 5 CCD-0009770 Rev. 03-27-25...
-
Page 6: Grounding Instructions
GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. -
Page 7: Information You Need To Know
INFORMATION YOU NEED TO KNOW ABOUT YOUR OVEN NEVER use the oven without the turntable and support nor turn the turntable over so that a large dish could be placed in the oven. The turntable will turn both clockwise and anticlockwise. The shelf gives you the option to reheat more than one dish of food at the same time. - Page 8 CCD-0009770 Rev. 03-27-25...
- Page 9 CCD-0009770 Rev. 03-27-25...
- Page 10 CCD-0009770 Rev. 03-27-25...
-
Page 11: Specifications
SPECIFICATIONS 1 20V 20AC 60 H z Single phase Power Supply Power Consumption 1500W Microwave Output Power 1 000W Frequency 2450MHz Outside Dimensions "( H ) x 2 9 "( W ) x 17 "( D ) Cavity Dimensions "( H )x 21 "( W ) x 1 4 "( D ) / 16... -
Page 12: Control Panel Features
CONTROL PANEL FEATURES Your microwave oven control panel lets you select the desires cooking function quickly and easily. All you have to do is touch the necessary command pad. The following is a list of all the command and number pad located on the control panel. For more information on these features, see the operation section. - Page 13 CCD-0009770 Rev. 03-27-25...
-
Page 14: Basic Controls
BASIC CONTROLS Learn about your microwave oven. CAUTION • To avoid risk of personal injury or property damage, do not operation the microwave oven empty. • To avoid risk of personal injury or property damage, do not use stoneware, aluminum foil, metal utensils, or mental trimmed utensils in the microwave oven. -
Page 15: Multi-Stage Cooking
Use number pad to select cooking power level Number pad Percent (Name) Number pad Percent (Name) 100% (High) 40% (Medium Low) 90% (Saute) 30% (Defrost) 80% (Reheat) 20% (Low) 70% (Medium High) 10% (Warm) 60% (Simmer) 0% (No Power) 50% (Medium) For example, suppose you want to cook at 80% power level for 10 minutes. -
Page 16: Special Features
Vent/2 Speed In standby mode, the vent fan is manual control, press pad to select the vent speed by manual: Vent/2 Speed Display Press Working Mode Vent .L Once Low Speed Vent .H Twice High Speed Put Out 3 times Turn off NOTE: When cooking is started, the vent fan automatically works into a low wind gear. - Page 17 Reheat 1 oz-37 oz Veggies 1 oz-48 oz Example, you want to cook 10 oz meat. Place meat into the oven and close the door. Meat Press pad once. Press number pad enter weight. Start/Add 3OSec Press pad to start cooking. ➔...
-
Page 18: Weight Defrost
KIDS MEALS Category Press number pad Weight Power level Chicken nuggets PL-6 8 oz Hot dogs 1 serving PL-6 PL-6 Fresh fries 8 oz Frozen Sandwiches 1 serving PL-8 Weight Defrost The oven allows you to defrost food based on the weight entered by user. The defrosting time and power level are automatically set once the food category and the weight are programmed. -
Page 19: Other Convenient Features
NOTE: • During defrost, the oven will pause and sound beep to remind user to turn the food over, Start/ Add 30Sec after that, press pad to resume. • Please remember to place the food on a microwave-safe dish not in a plastic container OTHER CONVENIENT FEATURES Add 30Sec Start/Add 30Sec... -
Page 20: Clear And Care
CLEAR AND CARE Exterior The outside surface is pre-coated steel and plastic. Clean the outside with mild soap and water; rinse and dry with a soft cloth. Do not use any type of household or abrasive cleaner. Door Wipe the window on both sides with a damp cloth to remove any spills or spatters. Metal parts will be easier to maintain if wiped frequently with a damp cloth. -
Page 21: Turntable/Turntable Support
Turntable/Turntable Support The turntable and turntable support can be removed for easy cleaning. Wash them in mild, sudsy water; for stubborn stains use a mild cleanser and non-abrasive scouring sponge as described above. They are also dishwasher-proof. Use upper rack of dishwasher. The turntable motor shaft is not sealed, so excess water or spills should be wiped up immediately. -
Page 22: Oven Light
• Pull the louver away from the unit. • Change the charcoal filter. • Carefully push the louver back into place and replace the screw remove in step 2. Louver Screw - - - �,-::::--.. - -- - --- -:::..., '-,, 'lCharcoal Piller Louver... - Page 23 CCD-0009770 Rev. 03-27-25...
- Page 24 Furrion Ltd. and Furrion, LLC (Furrion) are wholly owned subsidiaries of Lippert Components, Inc. (Lippert) Furrion Ltd. et Furrion, LLC (Furrion) sont des filiales en propriété exclusive de Lippert Components, Inc. (Lippert) Furrion, LLC: 52567 Independence Ct., Elkhart, IN, 46514 Furrion Innovation Center &...
