- Page 1 QUICK CHECK COMMERCIAL ® Alignment and tread inspection for HD OPERATIONS MANUAL HD Quick Check Drive Quick Tread Heavy ® see Form QM07959-00 Form QM07936, 07-24 Supersedes QM07936, 02-24 Operations Manual...
- Page 2 Approach straight and centered between sensor towers Steering OK Center Hold steering wheel straight ahead as vehicle approaches towers Do not steer Approach 2-8 mph (3-13 kph) Drive straight through at constant speed Do not steer Maintain speed Do not brake Do not brake or accelerate or accelerate...
- Page 3 HD Generic Alignment Inspection Specifi cation Hunter’s HD Generic Alignment Inspection Specifi cation enables autonomous pass/fail results without the need to manually select OEM axle specifi cations. It is based on Hunter research and actual OEM specifi cations. Due to the dynamic nature of QCHD alignment inspection and differences between generic and OEM specifi cations, a small percentage of QCHD pass/fail results may not correlate exactly to measurements taken on a Hunter HD Alignment system.
-
Page 4: No Fly Zones
No Fly Zones Tires passing through the GREEN fi elds should deliver a complete scan of the wheel for the QCHD and generate complete results. Passing into the YELLOW No Fly Zones will result in incomplete readings. The center area between the Green zones is also a No Fly Zone. Tires Passing through this center zone will also result in incomplete readings for the wheels passing through this area. -
Page 5: For Your Safety
Caution – Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Do not operate equipment with a damaged cord or equipment that has been dropped or damaged until a Hunter Service Representative has examined it. -
Page 6: Decal Information And Placement
Decal Information and Placement Front View Decals 128-1787-2 indicates the locations of laser apertures. Decal 128-1565-2 indicates laser radiation is present. The Class 3R laser apertures are located at the front faces. Rear View FDA standards for Class 3R laser compliance are shown on Decal 128-1786-2-08. LASER LIGHT AVOID DIRECT EYE EXPOSURE CLASS 3R LASER PRODUCT... - Page 7 A manufacturer’s identifi cation label is also on the rear of each tower. MODEL NO. PART NO. AMPS SERIAL NO. PHASE HERTZ SERIAL Specific Precautions/Optical Scan Laser The Optical Scan Laser is a class 3R laser designed to measure wheel alignment. The laser is not a fi eld serviceable part.
- Page 8 Because of continuing technological advances, specifi cations, models and options are subject to change without notice. PowerSlide and WinAlign are registered trademarks of Hunter Engineering Company. The PowerSlide logo is a trademark of Hunter Engineering Company. Copyright © 2024, Hunter Engineering Company...
