Assembly and operating instructions for pedestal systems with plugin legs

from BÜTEC GmbH in 40822 Mettmann, Germany

Due to our comprehensive product range, which also includes various custom-made pro-

ducts, it is unfortunately not possible for us to offer a prefabricated manual for all our pro-

ducts. If you should miss certain products in this manual, then you find further instructions

also on our

Also discover

the video tutorials

on our

Youtube Channel.

This manual does not claim to be complete.

Youtube

Channel. Should you require further assistance

we are also personally available for you.

BÜTEC

Gesellschaft für bühnentechnische

Einrichtungen mbH

Industriestraße 41

Page 1

40822 Mettmann

Tel.: +49(0)2104-9501-0

Fax: +49(0)2104-9501-30

kontakt@buetec.com

www.buetec.com

Table of Contents

Need help?

Do you have a question about the Standard and is the answer not in the manual?

Questions and answers

Summary of Contents for B-TEC Standard

Page 1 Assembly and operating instructions for pedestal systems with plugin legs from BÜTEC GmbH in 40822 Mettmann, Germany Also discover the video tutorials on our Youtube Channel. This manual does not claim to be complete. Due to our comprehensive product range, which also includes various custom-made pro- ducts, it is unfortunately not possible for us to offer a prefabricated manual for all our pro- ducts.
Page 2: General Information
General information You have chosen one of our platform systems Standard, Compact, Eco1 or Flexible. For your safety and the safety of your guests, we would like to ask you to read these ins- tallation and operating instructions carefully and to observe our instructions and expla- nations.
Page 3: Table Of Contents
Table of contents • Cover page • General information • Inhaltsverzeichnis • Technical features • Explanations and safety instructions • Assembly instructions for plug-in and telescopic feet • Connecting the platforms to each other S.7-9 • Assembly of stairs and steps (aluminium) S.10 •...
Page 4: Technical Features
Technical features Dimensions: 200 cm x 100 cm Cover plate: 22 mm beech wood core board for interior use water-thinnable BÜTEC acrylic alkyd glaze 22 mm screen printing plate for outdoor use Leg intake: Square 40 mm to 60 mm Load assumptions: 500 Kg/m²...
Page 5: Explanations And Safety Instructions
Explanations and safety instructions The plug-in pedestal systems of BÜTEC GmbH can be used for the construction of sta- ges and grandstands in different designs. The single pedestal consists of an aluminium frame with an inserted, screwed 22 mm thick beech wood block board or a waterproof screen printing plate for outdoor use.
Page 6: Assembly Instructions For Plug-In And Telescopic Feet
Assembly instructions for plug-in and telescopic feet The pedestals have a so-called Leg fixing corner with a prism / pressure segment for fixing and locking the platform foot systems. Both, plug-in feet and telescopic feet, are inserted into the leg fastening corner provided for this purpose and then tightened hand-tight (~ 24 Nm) with the handwheel.
Page 7: Connecting The Platforms To Each Other
Connecting the platforms to each other The platforms are connected to each other via the frame profiles of the stage elements by means of platform connection clamps. The platform connection clamp made of plastic or zinc die-cast has the functionality of a screw clamp.
Page 8 Connecting the platforms to each other In order to ensure a neat and secure connection of the platforms, each new platform is equipped with two clamps on the long side and two clamps fixed and locked on the short side. Depending on the situation, the assembly should be done row by row.
Page 9 Connecting the platforms to each other 2-fold clamp 4-fold clamp legs 55 x 55 legs 60 x 60 legs 50 x 50 frame to frame frame to frame frame to frame legs 50 x 50 legs 55 x 55 legs 60 x 60 frame to leg frame to leg frame to leg...
Page 10: Assembly Of Stairs And Steps (Aluminium)
The BÜTEC Stage Staircase Alu consists of individual steps in the standard heights 20, 40, 60 and 80 cm. The steps are made of an aluminium profile, which is also used in our BÜTEC „stan- dard“ platforms. Depending on the application, the staircase elements are equipped with a beech wood core board or a waterproof screen printing board.
Page 11: Assembly Of Stairs And Steps (Steel
Assembly of stairs and steps (steel) The BÜTEC stage staircase / box staircase steel consists of individual steps in the stan- dard heights 20, 40, 60 and 80 cm. Alternatively, a theatre pitch of 16 2/3 cm can be selected. The steps are made of an epoxied tubular steel frame, which is designed as a welded structure.
Page 12 Assembly of stairs and steps (steel) Connect the last step to the stage pedestal using the supplied aluminium connector. To do this, insert the 8 mm hammer-head screw into the internal groove of the stage element and turn it 90 degrees. Now slide the aluminium flat material over the thread, place the washer on it and lightly screw the holder over the wing nut to the platform.
Page 13: Assembly Of Stair Railings
Assembly of stair railings A handrail / stair railing is inserted into the stair steps depending on the design. inserted from above or screwed to the side. It should be on all free sides that are not facing the audience, the defences can be mounted.
Page 14: Assembly Of Stage, Grandstand And Stair Railings (Compact)
Assembly of stage, grandstand and stair railings (compact) The railing is screwed to or onto the compact corner using foot plates. Guardrails should be mounted on all free sides not facing the audience. Please be sure to observe the regulations applicable to you in each case, which regula- te the design for the respective use (VstättVo, SchulbauR, DIN standards for temporary structures, LBO).
Page 15: Assembly Of Ramps
Assembly of ramps 1. Tighten ramp hinge 2. Screw the ramp hinge to the pedestal using the clamp brackets. Hinge connected to pedestal The tube is pushed into the bracket at the end (view from below) and has to be secured. 3.
Page 16: Assembly Of Wooden Panelling
Assembly instructions: Wood panelling* Assembly of wooden panelling Insert the fairing holder with the Twist the hammer-head bolt in the Hammer-head screw into the inner groove chan- groove channel and pull out the nel of the profile frame. Fixing nut. If necessary, correct the fit of the fairing brackets Fasten the platform fairing to the fairing brackets and check the tightness of the screw connec-...
Page 17: Storage, Cleaning And Safety Instructions
Storage, cleaning and safety instructions The platforms and accessories should be stored in a clean, dry place. In order to ensure speedy assembly, it is recommended that the platform elements with the cover plate pointing downwards. Legs and braces find their place in the insides of two stacked elements.
Page 19 State 11/18 Plug-in Leg Pedestals / Compact Pedestals Price/ piece (€) Article no. Designation O10068 Profile frame „BÜTEC Standard“, 22 mm, 1 m long without anodizing 25,00 O10067 with anodizing 28,70 O10070 Profile frame „BÜTEC Standard“, 22 mm, 2 m long without anodizing...
Page 20 Spare Parts List State 11/18 Plug-in Leg Pedestals / Compact Pedestals Price/ piece (€) Article no. Designation O10290 Leg fixing corner large complete Leg 40-60 mm 31,80 O10372 Leg fixing corner zinc die-cast large 19,80 O10426 Mounting knob M10 x 65 4,00 O10526 Fixing knob without screw, upper part...
Page 21 Spare Parts List State 11/18 Plug-in Leg Pedestals / Compact Pedestals Price/ piece (€) Article no. Designation 4700-011 Leg clamp - connection of 4 plug-in legs 25,50 4700-013 Version A Plug-in leg 50/50 mm frame to frame 25,50 4700-012 Version B Plug-in leg 50/50 mm frame to leg 25,50...
