- Page 1 Stirling Gas Conditioner App K APEX INSTRUMENTS, INC. SGC-4000 Stirling Chiller Operator’ s Manual Issue 9-22-08...
-
Page 2: Table Of Contents
Temperature Controller Instructions..................... 12 Reset Configuration ........................12 Temperature Configuration....................... 14 Temperature Configuration....................... 14 Tuning Procedure........................14 SGC-4000 Controller Board Connections and Settings ............... 15 Images ............................17 Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... -
Page 3: Introduction
The SGC-4000 system is a low energy, environmentally-friendly (Stirling Cooler) gas cooling unit. It is designed to accommodate two heated sample lines and condition the sample gases to a user selectable temperature. Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... -
Page 4: Cooler System Information
Cooler system. Operational Summary The SGC-4000 unit is based around a Free Piston Stirling Cooler (FPSC). The FPSC constantly cools the input gas flow path through a common aluminum manifold (heat exchanger). Using an integrated block heater and a temperature controller the output gas temperature can be accurately controlled. -
Page 5: Components
• Watlow SD31 Temperature Controller • Stirling FPSC Cooler • Chiller Logic Board • Aluminum Manifold • Block Heater • Glass Condensate Collector • Glass Filtration Unit Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... -
Page 6: Stirling Fpsc Cooler
P I S T O N S T I R L I N G C O O L E R Stirling FPSC Cooler Figure 1 Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... -
Page 7: Sample Flow Schematic
C O O L E R Sample Flow Schematic This section contains the flow schematic of the SGC-4000 Stirling Cooler system used in conjunction with the XC-6000 MercSampler. Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail:... -
Page 8: Fpsc Controller Schematic
F R E E P I S T O N S T I R L I N G C O O L E R FPSC Controller Schematic Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... -
Page 9: Sgc-4000 Electrical Connections And Controls
SGC-4000 Electrical Connections and Controls The SGC-4000 connects to a 110V/15A circuit at the back of the unit and is controlled by a switch labeled Main on the front panel. The Main switch is also a circuit breaker. In the event the circuit breaker is tripped it can be reset by turning off then back on. -
Page 10: Sgc-4000 Plumbing Connections
BLUE. This color scheme is followed throughout the SGC-4000. The sample lines from the Probe to the SGC-4000 are connected to the Input A and Input B connectors, following the RED-BLUE color coding, which internally are connected to the chiller and the condensate bottles before passing to the ALUMA-SORB canisters/bottles. -
Page 11: Sgc-4000 Interconnection Schematic
F R E E P I S T O N S T I R L I N G C O O L E R SGC-4000 Interconnection Schematic Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... -
Page 12: Sgc-4000 Setup
Setup the test profile on the XC-6000 and perform the Pre-leak test, correct any leaks if required. Select Set Probe and verify the SGC-4000 temperature is correct. Refer to the XC-6000 MercSampler Operators Manual for information setting up the XC-6000 and running tests. - Page 13 F R E E P I S T O N S T I R L I N G C O O L E R 16. Release 17. Press Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com...
-
Page 14: Temperature Configuration
S T I R L I N G C O O L E R Temperature Configuration This section will describe how to specify the desired maintenance temperature on the SGC-4000 Cooler system. 1. Power on the unit 2. Press and hold 3. -
Page 15: Sgc-4000 Controller Board Connections And Settings
P I S T O N S T I R L I N G C O O L E R SGC-4000 Controller Board Connections and Settings Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... - Page 16 1001 1010 1011 1100 1101 1110 1111 Temp. Limit 151ºF/ 154ºF/ 158ºF/ 162ºF/ 165ºF 169ºF/ 172ºF/ 176ºF/ 66ºC 68ºC 70ºC 72ºC 74ºC 76ºC 78ºC 80ºC Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com...
-
Page 17: Images
P I S T O N S T I R L I N G C O O L E R Images Cover Removed Power Supply Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com... - Page 18 P I S T O N S T I R L I N G C O O L E R Temperature Controller Heat Exchanger and Installed Controller Board Apex Instruments, Inc. | Phone: 919.557.7300 | Fax: 919.557.7110 | Web: www.apexinst.com | e-mail: info@apexinst.com...
