R E D O N B E S T M I L L
USER MANUAL
redon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BESTMILL and is the answer not in the manual?

Questions and answers

Summary of Contents for Redon BESTMILL

  • Page 1 R E D O N B E S T M I L L USER MANUAL redon.com...
  • Page 2 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 redon.com...

  • Page 3: Table Of Contents

    USER INTERFACE / MAGAZINE -------------------------------------- 33-39 USER INTERFACE / SETTINGS ---------------------------------------- 40-41 MAINTENANCE / DAILY MAINTENANCE ------------------------ 42-43 MAINTENANCE / WEEKLY MAINTENANCE --------------------- 44-54 ATTACHMENTS -------------------------------------------------------------- 55-57 USER INTERCAFE / SETTINGS / CALIBRATION ---------------- 58-61 USER INTERCAFE / SETTINGS / TOOL LIST redon.com...

  • Page 4: Technical Specifications

    DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 TECHNICAL SPECIFICATIONS REDON BESTMILL Country of Origin Türkiye Axis Motor Technology Dijital A C Servo Motor Spindle Speed Spindle Speed 60.000RPM 60.000RPM Spindle Power 3700 W Number of Axis 5 Axes +360 / -360 Degree (A Axis) Max.
  • Page 5 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 TECHNICAL SPECIFICATIONS REDON BESTMILL Zirconia Machining Preform Machining Plastic Machining PEEK Machining Composite Machining Alumina Machining Reference Process Voltage / Frequency 110v-230v / 5 0 -6 0 Hz Power Consumption 300W - 4 0 0 W Air Consumption (L / Min.) Compressed Air Pressure (Bar) Volume (m³)

  • Page 6: Work Environment

    Absence of sintering or other heat-emitting devices near the installation location of the machine The temperature of the installation area for the device should be between 22-24 degrees Celsius. The rear of the device should be accessible for service and user intervention at the location where it is positioned. redon.com...

  • Page 7: Warnings And Labels

    DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 WARNINGS AND LABELS DEFINITIONS OF WARNINGS AND LABELS MOVING PARTS WARNING LABEL ELECTRICAL WARNING LABEL INSTRUCTION LABEL...
  • Page 8 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 WARNINGS AND LABELS OTHER LABELS DEVİCE OTHER LABELS...

  • Page 9: Case Opening

    DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 CASE OPENING The images show the top cover of the shipping case. The top cover has 4 lateral surfaces. Each lateral surface has 2 assembly connections, making a total of 8 connections. To dismantle the top cover, position the "top cover joining connections"...
  • Page 10 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 CASE OPENING Removing the cover with the top cover assembly joints in the upright posıtıon. The disassembly of the side cover assembly connections is demonstrated. To disassemble the side covers, all side assembly connections must be eliminated.

  • Page 11: Unpacking

    The front and side panels of the shipping panel is opened. crate have been opened. The foam has been removed from The Redon box and the foam in the upper the right side section. section are removed. In the final section, only the machine The foam on the left side, front, and back cover is left.

  • Page 12: Contents Of The Product

    DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 CONTENTS OF THE PRODUCT 8mmx7.5mt 3m Network Air gun One Pneumatic Hose Cable...

  • Page 13: Options

    DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 OPTIONS Glass Ceramic and Premill Holder Table Compass Digit Holder M4 x 10 mm Allen key A3 bolt - 6 pieces M5 x 12 mm Allen key A3 bolt - 6 pieces Cutting Oil...

  • Page 14: Important Considerations

    If the machine is to be placed on a table other than its own, the table must be strong enough to support a weight of 250 kg. The dimensions of the table should not be smaller than those of the machine. redon.com...

  • Page 15: Processable Materials And Prosthesis Types

    DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 MACHINABLE MATERIALS AND TYPES OF PROSTHESES Abuments Full Anatomical Crown Complete Denture Hybrid Abutment Inlay, Onlays, Veneer Partial Denture Occlusal Screw Retained Nıght Plate Model Prosthesis Surgical Guide Telescopes Telescope Premill Abutments İmplant Bar redon.com...

  • Page 16: Connection Points

    1 Piece of 8mm x 7.5m Pneumatic Hose Air Conditioner Indicator: Ensure that Side Connection Panel the air is dry and clean. Otherwise, components that operate with air, including the spindle motor, may be damaged. Rear Panel Air and Water Hose Inlets redon.com...
  • Page 17 Vacuum Unit Power Connection Vacuum Ethernet Port Socket (DIN 49440) Power Cable Inlet Water Hose Inlet Connection Socket. The socket (IEC-320-C14) where the 10 mm diameter hose from the water tank is connected. RJ45 CAT6 Network 6 Bar Air Inlet Connection Connector redon.com...

  • Page 18: User Interface

    DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 USER INTERFACE REDON BestMill features a touchscreen. Initial Startup Screen Air Pressure (Bar) Indicator User Menu Job Information (job sequence, job name, job duration) Indicator Block Information Start/Stop Button Block Holder Open/Close Button Door Open/Close Button redon.com...
  • Page 19 Job Loading Menu Tool Change Menu Calibration Menu Maintenance Menu Locked functions are displayed in dark color. The machine locks the function buttons for safety purposes according to the operation it is performing. Available functions are displayed in a lighter color. redon.com...
  • Page 20 Job file runtime If the job is interrupted due to power outages or similar situations during processing, this button becomes active. Pressing this button will resume the job from the last tool change procedure recorded in the job file. redon.com...

  • Page 21: Program Loadi̇ng And Execution

    This is the copy button used to transfer programs from the Programs folder to the Job List. Tap on the program you want to use in the Programs folder and press the button. The program will be copied to the Job List. redon.com...
  • Page 22 Start Job Butonu This is the start button for the Job List. To begin processing the job files in the Job List, press the 'Start Job' button. The list will start processing the job files in the specified order redon.com...
  • Page 23 Insert the USB drive into the rear panel. Ensure that the USB drive is properly connected. Follow the steps provided on the next page. Step 1: Insert the USB drive containing the job file into the USB port located on the side panel of the BestMill. redon.com...
  • Page 24 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 PROGRAM LOADİNG AND EXECUTİON Job Loading Screen Step 1: Press the user menu button. Step 2: From the opened menu, press the 'Job Loading Menu' button to navigate to the job loading menu. redon.com...
  • Page 25 Step 3: Tap the 'USB' tab to view and select files on the USB drive. Step 4: Tap on the job file you want to run from the USB list. Step 5: Tap the copy button to add the selected job file to the Job List. redon.com...
  • Page 26 List. Step 7: After reviewing the job file, tap the 'Start Job' button to begin processing the job file. Step 8: To remove a file from the Job List, tap the 'Delete' button to remove it from the list. redon.com...

  • Page 27: Uploadi̇ng A Program Using Filezilla

    An Ethernet cable with no connection issues should be plugged into the Ethernet port as shown in the example Vacuum triggering Ethernet port. Ethernet port for file access. The logo is displayed on the left. The filezilla.exe executable file is executed. redon.com...
  • Page 28 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 UPLOADİNG PROGRAMS WİTH FİLEZİLLA Enter the machine's IP address in the Enter (yrm) in the (Password) tab. (Server) tab. Enter (yrm) in the (Kullanıcı Adı) Click the (Quick Connect) button to establish the tab. connection. redon.com...
  • Page 29 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 UPLOADİNG PROGRAMS WİTH FİLEZİLLA Step 1: Right-click on the .prg file. Step 2: Click on the 'Upload' button in the dropdown menu. redon.com...
  • Page 30 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 UPLOADİNG PROGRAMS WİTH FİLEZİLLA In the end, it will be seen that the program.prg file has been transferred to the right-hand tab. redon.com...

  • Page 31: User Interface / Run

    - If dry operation will be performed, the connection between the air outlet at the back of the machine and the vacuum should be checked. - Tool lifetimes on the TOOL MAGAZINE page should be checked before starting the job. redon.com...
  • Page 32 Step 4: If you want to open the door when the job file operation is paused, touch the DOOR button. Job Sequence. Displays the sequence of the currently running job file. Job file name. Job File Runtime Job File Progress Percentage redon.com...

  • Page 33: User Interface / Magazine

    U S E R IN TE R FAC E / MAGAZ INE MAGAZINE Main Menu (Tool Change) Step 1: Press the User Menu button. Step 2: From the opened menu, press the Magazine Menu button to navigate to the magazine menu. redon.com...
  • Page 34 •If the tool is broken, the background is highlighted in red. If you want to open the machine door, touch the DOOR button. To open or close the ATC, use the ATC Open/Close button. To return to the previous menu, use the BACK button. redon.com...
  • Page 35 To send the tool in the spindle for measurement, use the «Measure» button. To open or close the ATC, use the «ATC Open/Close» button. To open the machine door, touch the «DOOR» button. To navigate to the previous menu, use the «BACK» button. redon.com...
  • Page 36 U S E R IN TE R FAC E / MAGAZ INE MAGAZINE Main Menu (Tool Change) To retrieve a tool from the magazine, use the «Pick Tool» button. It will pick up tool T1 from position P1 and then move to the park position. redon.com...
  • Page 37 Tab where the status of the tool in the magazine is changed and monitored. Tab where the twin tool number is changed. Tab where the remaining tool life is monitored and the tab where the tool life is reset. Tab where the tool life is entered. redon.com...
  • Page 38 The tool should be inserted into the collet so that the segment's upper surface rests against it. Press the COLET button on the magazine page again to close the spindle collet. The tool loading process is complete. The same procedure is followed for worn or broken tools. redon.com...
  • Page 39 After manual tool loading, first set the Tool Status to « OK ». Then set the Place Status to « In Spindle ». Next, click the « MEASURE » button. Once the tool measurement is complete, the tool can be used. redon.com...

  • Page 40: User Interface / Settings

    • It should be cleaned once a week. WARNING! Tools should be reinserted into the same pocket from which they were removed. AXIS LUBRICATION: Lubrication of the machine axes. This should be performed by authorized service personnel. ● It should be done once a year. redon.com...
  • Page 41 WATER: Use the « WATER » button to activate or deactivate the water outlet during machine cleaning. PARK: Use the « PARK » buttons to move the machine axes to predefined parking positions. redon.com...

  • Page 42: Maintenance / Daily Maintenance

    While the vacuum device is operating, dust on the machine should be cleaned with a brush. The vacuum device should be turned on during the cleaning process. After completing the brushing phase of cleaning, use a clean, damp cloth to wipe the area. redon.com...
  • Page 43 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BAKIM / SETTING S CLEANING / DRY CLEANING No air should be held inside the workbench! Cleaning inside the workbench should be done with a clean, damp cloth.

  • Page 44: Maintenance / Weekly Maintenance

    The collet is cleaned with the help of a brush. Collet Disassembly •The collet should be opened, and any tool at its end should be removed. •Hold the 13 mm wrench steady while turning the 10 mm wrench clockwise to unscrew and remove the collet from its place. redon.com...
  • Page 45 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S SPINDLE CLEANING Cleaning The spindle collet pocket is cleaned with a wire brush.. The collet is removed using a wrench from the spindle maintenance kit while the collet is open. Periodically, a thin layer of oil (grease) should be applied to the collet.
  • Page 46 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING ATC Cleaning WARNING! It is recommended to perform ATC cleaning on a weekly basis. Press the ATC button from the magazine menu to open the magazine. redon.com...
  • Page 47 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING The screw is removed by turning it counterclockwise.
  • Page 48 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING The magazine is removed by pulling it out.
  • Page 49 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING The tools on the magazine are removed from their pockets.
  • Page 50 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING The tools on the magazine and the tool pockets are cleaned of dust, chips, oil, and other debris using compressed air.
  • Page 51 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING After the magazine is cleaned, each tool is placed back into its original pocket, and the magazine is reattached to the machine. WARNING! Tools should be reinserted into the same pocket from which they were removed.
  • Page 52 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING The screw is tightened by turning it clockwise.
  • Page 53 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 BA KIM / SETTING S ATC CLEANING The magazine is pushed back into place, and then the magazine is closed by pressing the ATC button from the magazine menu.
  • Page 54 WARNİNG! Each machine has its own ATC. The machine number is written on the back of the ATC as shown. Care should be taken to ensure that the ATC removed from a machine is reinstalled in the same machine. redon.com...

  • Page 55: Attachments

    The ATC cover should be cleaned with a damp microfiber cloth to prevent scratching, damage to the inscriptions, and deformation. If cleaned with liquids such as alcohol or thinner, these issues will occur. Therefore, it should not be wiped with liquids like alcohol or thinner. redon.c om...
  • Page 56 The workpiece is secured by bringing the lower and upper rings together and fastening them with screws. Ensure that there is no dirt or debris between the lower and upper rings, and then assemble them as shown. redon.com...
  • Page 57 When fastening the workpiece, secured with the lower and upper rings, to the block holder, ensure that the bolts are seated properly on the contact surface. The bolts should be tightened evenly. redon.com...

  • Page 58: User Intercafe / Settings / Calibration

    The air hose attachment is shown sequentially in Figures 3 and 4. This attachment is used when connecting the vacuum device to the machine. After dry operation, the interior of the machine is cleaned using the vacuum device. If switching to wet operation, the interior of the machine should be thoroughly cleaned before starting. redon.com...
  • Page 59 ±5°C requires recalibration for accuracy. Calibration is performed by measuring a specially processed part with a digital caliper and entering the values on the screen. DRY CALIBRATION: Dry calibration process. WET CALIBRATION: Wet calibration process. CALIBRATION VALUES: Menu for entering calibration values. redon.com...
  • Page 60 If performing dry calibration, ensure that the vacuum connection is made at the back of the machine. If performing wet calibration, ensure that the water drain connection is made at the back of the machine. START: Begin calibration process. CANCEL: Cancel the calibration process. redon.com...
  • Page 61 Ensure that the caliper is fully closed and that there is no dust or debris between the fixed and movable jaws. The caliper is then zeroed. The final state should be as shown on the left, with the screen zeroed. redon.com...
  • Page 62 •The entered values should be reviewed again. •Remember! An incorrect value entered can cause the machine to crash into the workpiece or any other part. After entering the values, press the CONFIRM VALUES button. If you wish to cancel the operation, press the CANCEL button. redon.com...
  • Page 63 Ø1 mm Flat - Metal MEB1-8-N Ø1 mm Ballmill - Metal T 3 0 MEB0.6-3-N Ø0.6 mm Ballmill - Metal MEF0.5-3-N Ø0.5 mm Flat - Metal MEB0.3-2-N Ø0.3 mm BallMill - Metal MEF0.3-1.5-N Ø0.3 mm Flat - Metal redon.c om...
  • Page 64 2018 205-265-5-22S TBR Octagon 2019 205-265-5-15S SynOcta® WN 6,5 2020 190-265-5-15S Dyna 2021 185-260-5-35S B E G O Semados® 2022 145-220-5-30S Thommen Medical® 3,5 2023 165-240-5-30S Thommen Medical® 4,0 -5,0 2024 205-265-5-60S Megagen 2001 45 240 165 8S Alphatech redon.c om...
  • Page 65 DN: KLV-11/RD:13.10.2023/Rev.D:10.10.2024/Rev.N: Rev.02 NOTES redon.com...
