Original Instruction Manual
RPMS-R-MK2
Heavy Cast Router Table
with Sliding Table
Version 3.1
November 2014
It is important to register your product as soon as possible in order to receive efficient after sales
support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
Kg
Always wear safety glasses when
using woodworking equipment.
To register this product please visit
www.recordpower.info
Please see back cover for contact details.
Important
i
For your safety read instructions carefully before
assembling or using this product.
Always read the instructions
provided before using
Save this manual for future reference.
woodworking equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RPMS-R-MK2 and is the answer not in the manual?

Questions and answers

Related Manuals for Record Power RPMS-R-MK2

Summary of Contents for Record Power RPMS-R-MK2

  • Page 1 Original Instruction Manual RPMS-R-MK2 Heavy Cast Router Table with Sliding Table Version 3.1 November 2014 To register this product please visit www.recordpower.info It is important to register your product as soon as possible in order to receive efficient after sales support and be entitled to the full 5 year guarantee.

  • Page 2: Table Of Contents

    Contents Explanation of Symbols General Health & Safety Guidance Record Power Guarantee Getting to Know Your Router Table Specifications Contents of the Package Assembly Fitting a Router to the Router Table Operation 10 Dust Extraction 11 Parts Lists & Diagram 1.

  • Page 3: General Health & Safety Guidance

    2. General Health & Safety Guidance Ensure that you carefully read and fully understand the are of adequate specification. instructions in this manual before assembly, installation and use 6. The machine should be level and stable at all times of this product. Keep these instructions in a safe place for future •...
  • Page 4 2. General Health & Safety Guidance • Never leave the machine running unattended. Turn the power supply off damaged, replace it immediately. and do not leave the machine unattended until it comes to a • Use extra supports (roller support stands etc.) for any work pieces large complete stop.

  • Page 5: Record Power Guarantee

    Guarantee guarantee must be reported to the Authorised Dealer from which it Record Power guarantees that for a period of 5 years from the date was purchased within 48 hours of receipt. of purchase the components of qualifying Products (see clauses 1.2.1 to 1.2.9) will be free from defects caused by faulty construction...

  • Page 6: Getting To Know Your

    4. Getting to Know Your Router Table Floor stand Dust hood outlet Sliding table Table retention knob Dust hood Pressure pad Cast iron table Work clamps Sliding table push plate Fence lock knob Right fence No volt release switch Left fence Sliding table work clamp Shelf 5.

  • Page 7: Contents Of The Package

    6. Contents of the Package Ensure all loose items are present as listed in the manual. Remove the rust prevention oil thoroughly. Use a soft cloth moistened with white spirit or other degreaser. Do not use gasoline or lacquer thinner to remove the rust prevention oil as these may damage the paint surface. Table assembly 10 RPMS-CX Collet Extension 20 Fence assembly bracket...

  • Page 8: Assembly

    7. Assembly With a 14 mm wrench use the carriage bolts, nuts and washers, to attach Fig. 7.1 the stand legs to the stand shelf, using the square holes in the legs and stand. Ensure the washers are placed behind the nuts, on the insides of the legs.
  • Page 9 7. Assembly Attach the reinforcing struts to the rear of the stand, Fig. 7.6, with the Fig. 7.6 upper parts positioned on the inside of the stand legs as shown in Fig. 7.7. Attach the gas spring struts to the sides of the stand, ensuring the circular hole in each strut is positioned closest to the front of the stand, Fig.
  • Page 10 7. Assembly Attaching the Table to the Stand Fig. 7.11 To aid with assembly, attach both lifting handles to the holes on the edge of the cast iron table using a 5 mm hex wrench, Fig. 7.11. The table assembly has the table mounts already attached to each side. At the side of the assembly that features the aluminium sliding table are two sets of pre-installed securing nuts, bolts and washers, and at the side featuring the cast iron table are two sets of rubber supports, nuts and...
  • Page 11 7. Assembly Fitting the Gas Springs Fig. 7.16 The gas springs are supplied with nylon locking nuts, bolts and washers attached and these must be removed prior to installation. To allow free movement of the gas springs, do not fully tighten the fixings.
  • Page 12 7. Assembly Attach the left and right hand fences to the fence assembly bracket using Fig. 7.22 the pre-installed nuts, bolts and washers as shown in Fig. 7.22 with a 10 mm wrench. Ensure the fixings are positioned as in Fig. 7.23. To make sure the fences are parallel, align the front of the fence assembly bracket with the fronts of the fence mounts, Fig.
  • Page 13 7. Assembly Attach the work clamp mounts to the fence assembly bracket using the Fig. 7.26 two nuts pre-installed to the work clamp mounts and securing into the two holes on top of the fence assembly bracket with a 19 mm wrench, Fig. 7.26.
  • Page 14 7. Assembly Assembly of the Sliding Table Work Clamp Work clamp mount Fig. 7.31 With the push plate positioned face down and the knobs uppermost, fit the sliding table work clamp mount to it by engaging the flat edged bolts beneath the clamp mount to the push plate, Fig.
  • Page 15 7. Assembly Fitting the Fence Assembly, Sliding Table Clamps & Pressure Pad Fig. 7.34 to the Router Table The cast iron table has three sets of two tapped holes on either end. To Mounting attach the fence assembly place it so the required holes are visible through the mounting slots at either end as in Fig.

  • Page 16: Fitting A Router To The Router Table

    8. Fitting a Router to the Router Table To gain access to the underside of the table, remove the table retention Fig. 8.1 Clamp locking knobs. levelling bolt and Clamping The gas springs can push the table up with considerable force. flange Apply downward pressure to the table before fully removing the knobs to control the table's movement.
  • Page 17 8. Fitting a Router to the Router Table Place the router on the mounting plate with the router bit positioned centrally in the table opening, Fig. 8.5. Once the clamps are positioned Fig. 8.5 over the router base as shown in Fig. 8.6 tighten them by hand to hold the router in position then tighten further using a 14 mm wrench on the hexagonal shafts of the clamps.

  • Page 18: Operation

    9. Operation WARNING: Before attempting to make adjustments to any settings make Fig. 9.1 sure that the power supply to the machine is switched off and the Work clamps supply cord is removed from the outlet. Serious injury may occur if the router is started while making adjustments.
  • Page 19 9. Operation Using the Sliding Table Fig. 9.7 Before using the sliding table the lock tabs on either side of the table must be disengaged by rotating them 180º to be clear of the table assembly, Fig. 9.7. When larger workpieces are being machined, it is recommended that Lock tabs the sliding table be used.
  • Page 20 9. Operation Using the Cast Iron Table Fig. 9.12 When machining small workpieces use of the sliding table may be unnecessary and use of the cast iron table may be preferable. The fence assembly can be turned around and re-fixed to two holes closer to the sliding table as shown in Fig.

  • Page 21: Dust Extraction

    Record Power Extractors be switched off for 20 minutes every hour. 0.5 micron filtration Record Power offer a range of high quality dust extractors, we offer both drum and bag type extractors which filter down 0.5 micron providing CX2000 Compact Chip Extractor protection from harmful fine dusts.

  • Page 22: Parts List And Diagram

    11. Parts List & Diagram...
  • Page 23 11. Parts List & Diagram Part No. Description Quantity Part No. Description Quantity Fence extrusion Slide rail Sliding screw M6 x 20 mm Table left support Micrometric adjustment rod Fix piece Fence mount Gas spring Fence mount guard Table right support Micrometric adjustment rod 60 mm insert plate Hold-down holder...
  • Page 24 Woodworking Machinery & Accessories United Kingdom Eire Australia New Zealand Record Power Ltd Record Power Ltd Tools 4 Industry Tools 4 Industry Centenary House, 11 Midland Way, Centenary House, 11 Midland Way, Po Box 3844 Po Box 276079 Barlborough Links, Chesterfield,...
