Summary of Contents for techtron EVP3

Page 1 EVP3/3+ Instruction Manual...
Page 2 Ethos Welcome to techtron®. By combining passion, drive and intellect with market leading research and cutting-edge technology, we innovate and deliver premium quality products that excite, inspire and challenge the sector. Striving for perfection, embracing new ideas and investing in the future is our ethos.
Page 3: Table Of Contents
Contents Product and Accessories Product Overview Installation Instructions User Precautions Instructions For Use Display Panel Function techtron® Smart App Technical Data Warning Warranty Troubleshooting Guidelines IMPORTANT! Read carefully and keep for future reference.
Page 4: Product And Accessories
Worldwide Compatibility Quick & Convenient Schedule Premium Charging Time Carrying Case Complete Control Ultra Durable 2.4” Display Stylish Wall Screen Mounting Kit Crystal Clear Wall Mount & Gun Holder Smart Intelligent Connectivity SmartApp WiFi / Bluetooth EVP3+ Only EVP3+ Only...
Page 5 Product And Accessories Charging Gun x 1pc Gun Holder x 1pc Self-Tapping Screws x 4pc Wall Mount Plastic Expansion Bracket x1pc Tube x 4pc...
Page 6: Product Overview
Product Overview Status Display Screen Set Current Button Lighting Indicators Set Time Button Working Status Indicator Status Power Cable Not Connected Blue Light Charging Cable Charging Completed Green Light Charging Multi Colour Light Control Box Fault Red Light...
Page 7: Temperature Monitoring
Product Overview Temperature Monitoring Monitor the working temperature of the charger in real time, if it exceeds the safe temperature, it will stop working immediately. After the temperature returns to normal, it can automatically resume charging. Automatically Repair Faults The smart chip can automatically repair common charging failures to ensure stable operation of the product.
Page 8: Installation Instructions
Installation Instructions Location Planning • Mount the unit on a vertical surface that will support its weight (e.g., a finished wall). The maximum weight of this product is approx 10.5kg. • Ensure the installation is suitable to reach your charging position and to avoid stretching or excessive bending/twist of cables.
Page 9 Installation Instructions • Place the connector holder in a suitable place. Note: The connector holder should be positioned within the bendable range of the wire. To avoid the risk of fire or electric shock, do not use this product with an extension cord.
Page 10: User Precautions
User Precautions Precautions • When using a power plug adapter, please adjust the charging current below the rated current of your socket. • If the charging device is damaged due to the wrong use, you will not enjoy the Guarantee service. •...
Page 11: Instructions For Use
Instructions For Use How to Start Charging Insert the plug into power-supply socket firmly. Ensure power-supply socket is compliant with national standard, and the rated current is 16A. Press the button 'Current Adjustment' to switch charging current mode. Press the button 'Schedule Charging' to schedule time for charging.
Page 12 Instructions For Use How to Stop Charging Disconnect the charging connector from the vehicle inlet. Unplug the connector and put it back in connector holder. Disconnect the plug from the power-supply socket. Some models will lock the charging connector when the power is on, and you need to power off before pulling out the charging connector.
Page 13 Instructions For Use Current Mode Switching • Please insert the power-supply plug into the power-supply socket firmly and disconnect the vehicle, then current mode can be switched by pressing the switch button 'Current Adjustment' Please don't touch while charging. • The 13A device supports four current switching modes of 6A , 8A, 10A and 13A (Only for UK 3 pin power plug EV Charger) •...
Page 14: Display Panel Function
Display Panel Function Starting Screen Future Tech. Today Home Screen 00:00:10 Ready Power Voltage (V) Current (A) 240 V 0.0 A 0.0 kW Plug Temp Energy Main Temp 0 kW/h 27.5 °C 26.0 °C Not Connected 00:59:59 Delay Charging Voltage (V) Current (A) Power 240 V...
Page 15 Display Panel Function Charging Voltage (V): 240V Delay Charging 01:00:00 Charging Voltage (V) Current (A) Power 239 V 16 A 3.8 kW Energy Main Temp Plug Temp 3.8 kW/h 46 °C 46 °C Error Error A A1: Over Temperature Protection 1 Hour : 38 Min : 46 Sec...
Page 16: Techtron® Smart App
Smart App The techtron® EVP3/3+ EV Charger App provides a user-friendly interface to monitor and manage your electric vehicle charging process efficiently. Key functionalities include: EVP3+ 0.00 Total Forward Energy Charge Delayed Charging 3 Hour Voltage (V) Current (A) Power (kW) 0.000V...
Page 17: Startup Screen
Smart App Startup Screen Home Screen Charge Button: A large, easily accessible Setting button labeled "Charge" allows users to start or stop the charging session with a single tap. Current (A) Delayed Charging: Allows you to set a specific delay (e.g., 1 hour, 2 hours, Current Temp 40°C...
Page 18: Technical Data
Technical Data EVP3 ev-Charger Models Type 1 USA Type 2 UK Type 2 EU Tesla USA GB/T China Areas of Application Portable Home Portable Home Portable Home Portable Home Portable Home EV Charging: EV Charging: EV Charging: EV Charging: EV Charging:...
Page 19 Rated Output Adjustable Adjustable Adjustable Adjustable 8A/10A/13A/16A Current 6A-16A current up to current up to 16A 6A-16A Adjustable (GB/T) (EVP3 EU) Input Current Single Phase Single Phase Rated Power 1.8kW 3.2kW 3.6kW 1.8kW 3.6kW (Plug and Play) (Plug and Play)
Page 20 Technical Data EVP3 ev-Charger Models Type 1 USA Type 2 UK Type 2 EU Tesla USA GB/T China General Characteristics Plastic PC9330: Plastic PC9330: Plastic PC9330: Plastic PC9330: Plastic PC9330: Material A high A high A high A high A high...
Page 21 Technical Data Models Type 1 USA Type 2 UK Type 2 EU Tesla USA GB/T China Smart Features Bluetooth / WiFi 3G/4G Waterproof IP67 IP67 IP67 IP67 IP67 SmartApp Certification And Standards Safety and • EN 55032: 2015 + • EN 55032: 2015 + •...
Page 22 Technical Data EVP3+ ev-Charger Models Type 1 USA Type 2 UK Type 2 EU Tesla USA GB/T China Areas of Application Portable Home Portable Home Portable Home Portable Home Portable Home EV Charging: EV Charging: EV Charging: EV Charging: EV Charging:...
Page 23 Rated Output Adjustable Adjustable Adjustable Adjustable 8A/10A/13A/16A Current 6A-16A current up to current up to 16A 6A-16A Adjustable (GB/T) (EVP3 EU) Input Current Single Phase Single Phase Rated Power 1.8kW 3.2kW 3.6kW 1.8kW 3.6kW (Plug and Play) (Plug and Play)
Page 24 Technical Data EVP3+ ev-Charger Models Type 1 USA Type 2 UK Type 2 EU Tesla USA GB/T China General Characteristics Plastic PC9330: Plastic PC9330: Plastic PC9330: Plastic PC9330: Plastic PC9330: Material A high A high A high A high A high...
Page 25 Bluetooth / WiFi 3G/4G Waterproof IP67 IP67 IP67 IP67 IP67 SmartApp techtron® SmartApp techtron® SmartApp techtron® SmartApp techtron® SmartApp techtron® SmartApp Certification And Standards Safety and • EN 55032: 2015 + • EN 55032: 2015 + • EN 55032: 2015 + •...
Page 26: Warning
Warning Warning • Do not submerge the control box in water. • Do not step on, pull, fold or knot the cable. • Do not drop the control box or place heavy object on it. • Do not place the charging cable near high temperature object when charging. •...
Page 27: Product Registration
(including negligence) or other legal or equitable theory, even if techtron® knew or should have known of the possibility of such damages. In no event will techtron®'s cumulative liability for all claims relating to the Electric Vehicle Supply Equipment exceed the price you paid for the Electric Vehicle Supply Equipment.
Page 28: Troubleshooting
Troubleshooting Error Codes And What They Mean Faults with techtron® ev-Charger rarely happen, but if you’re unfortunate enough to encounter a problem, just cross reference the error code shown on the ev-Charger’s display panel with the ones listed in the table opposite.
Page 29 Troubleshooting Error Code Description Solution Over-Temperature • Check the load current if too large. Protection • Remove the EV charger connector and the power plug, Then try again after cooling, if there is still Error -A, contact the customer service team. CP Short Circuit •...
Page 30: Guidelines
Guidelines Safety Guidelines Use a Dedicated Power Source – Ensure the power outlet meets the required voltage and amperage. Avoid using extension cords or adapters. Inspect Before Use – Check the charger, cables, and connectors for any damage before plugging in. Keep Dry –...
Page 31 Notes Notes:...
Page 32 For further information and advice you can find us at: e: info@techtron.co w: techtron.co UK: techtron® Future Tech Ltd. EU: Multibrands® techtron® Ltd, Dublin Ireland. techtron® is a Registered Trademark. V01. 01.2025...
