Summary of Contents for Hahn & Sohn Cedrus CEDLM40LiX2
- Page 1 Keep manual for future reference. HAHN A SYN s.r.o. Hahn & Sohn GmbH Janahof 53 Lelkova 186/4 93413 Cham 747 21 Kravaře Deutschland CZECH REPUBLIC hahn@hahn-sohn.de info@hahn-profi.cz User manual Cordless Brushless Lawn Mower CEDLM40LiX2...
- Page 2 Identification Battery cover Front grip Handle height adjust button Twist switch Upper handle Lower handle Grass basket Mowing height adjusting lever Switch lever Switch button Rear cover Battery Cartridge Button of Battery Cartridge Idler wheel...
-
Page 3: Specifications
SPECIFICATIONS Model: CEDLM40LiX2 Mowing width (blade diameter) 400 mm Moving Height 25-75mm (with 6 position height adjustments) Capacity of Grass basket Dimensions (L x W x H) 780mm x 480mm x480mm (Bare tool without grass basket) Rated voltage D.C. 2 x 20V Net weight(Bare Tool) 16.5 kg Protection degree... -
Page 4: Safety Warnings
Vibration The vibration total value (tri-axial vector sum) deter- mined according to EN60335-2-77: Model:CEDLM40LIX2 Vibration emission (a) : 2.5 m/sor less Uncertainty (K) : 1.5 m/s2 NOTE: The declared vibration total value(s) has been measured in accordance with a standard test method and may be used for comparing one tool with another. - Page 5 Keep hands and feet away from rotating Do not start the mower when standing in front blades. Caution - Blades coast after the mower of the discharge opening. is switched off. Do not put hands or feet near or under rotating Use only the manufacturer genuine blades parts.
- Page 6 When washing the machine, be sure to remove A battery short can cause a large current the battery and lock key and close the battery flow, overheating, possible burns and even a cover, and pour water toward the bottom of the breakdown.
-
Page 7: Functional Description
3. Hook the grass basket on the rod of the mower ASSEMBLY body as shown in the figure. WARNING: Always be sure that the lock key and battery cartridge are removed before carrying Failure to remove the out any work on the mower. lock key and the battery cartridge may result in seri- ous personal injury from accidental start-up. - Page 8 CAUTION: Always switch off the tool before installing or removing of the battery cartridge. CAUTION: Hold the tool and the battery car- tridge firmly when installing or removing battery Failure to hold the tool and the battery cartridge. cartridge firmly may cause them to slip off your hands and result in damage to the tool and battery cartridge and a personal injury.
-
Page 9: Adjusting The Mowing Height
►1. Switch button 2. Upper handle 3. Switch lever 4. Release the switch button as soon as the motor ►1. Indicator lamps 2. Check button starts running. The mower will continue to run until you release the switch lever. Press the check button on the battery cartridge to indi- 5. -
Page 10: Adjusting The Handle Height
NOTE: The mowing height figures should be used WARNING: Before mowing, clear away just as a guideline. Depending on the conditions of sticks the lawn or the ground, the actual lawn height may and stones from mowing area. Furthermore, clear become slightly different from the set height. -
Page 11: Emptying The Grass Basket
Do not try to cut long grass all at once. Instead, mow Maintenance the lawn in steps. Leave a day or two between mowings until the lawn becomes evenly short. 1.Remove the lock key and battery cartridges, and then close the battery cover. NOTE: Mowing long grass to a short length all at once may cause the grass to die. - Page 12 2. Press down a little bit and then turn the twist switch and then fold the upper handle.Clockwise to unlock(1) and anticlockwise to lock on(2). Lock(2) Unlock(1) Turn the bolt counter anticlockwise with the wrench. ►1. Mower blade 2. Hex Bolt 3. Lumber 4. Wrench 4.Remove the bolt, fan, mower blade in order.
-
Page 13: Troubleshooting
TROUBLESHOOTING Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to dismantle the tool. Instead, ask Cedrus Authorized Service Centers, always using Cedrus replacement parts for repairs. State of abnormality Probable cause (malfunction) Remedy...
