INSTALLATION INSTRUCTIONS
•
Carefully open the packaging, remove contents and lay out parts on a protective surface to avoid damage.
•
Check package contents against the Supplied Parts List in the next page(s) to assure that all components were received
undamaged. Do not use damaged or defective parts.
•
Carefully read all instructions before attempting installation.
Install mount with care. Please read these instructions before beginning this installation, and carefully follow all
instructions contained herein. Use proper safety equipment and protocol during installation.
Please consult PerfectVision for help if you:
•
Don't understand these directions or have any doubts about the safety of the installation.
•
Are uncertain or unfamiliar with the nature of the existing structure to be reinforced.
For questions and consulting please call PerfectVision at 1-800-205-8620. Ask for Wireless Sales & Product Support.
Note: Please leave instructions in shelter or cabinet on site for future reference.
Do not use this product for any purpose or in any configuration not explicitly stated in this instruction. We hereby disclaim
any and all liability for injury or damage arising from incorrect assembly, incorrect mounting, or incorrect use of this product.
UNPACKING INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
GUARDIAN SERIES- CLIMBING MAST ACCESSORY
REVISION
DATE
4/14/2023
DOCUMENT #: LPP-GS-ACC5-INS-01-R0
EF-M01
0
IPT-002
PAGE NUMBER
DRAWN BY
INT
1 OF 8
Advertisement
Summary of Contents for Perfect Vision GUARDIAN Series
- Page 1 Do not use this product for any purpose or in any configuration not explicitly stated in this instruction. We hereby disclaim any and all liability for injury or damage arising from incorrect assembly, incorrect mounting, or incorrect use of this product. DOCUMENT #: LPP-GS-ACC5-INS-01-R0 GUARDIAN SERIES- CLIMBING MAST ACCESSORY REVISION EF-M01...
- Page 2 Supplied Parts List NOTE: DRAWINGS NTS PV-LPP-GS-ACC5 GUARDIAN SERIES CLIMBING MAST ACCESSORY WEIGHT: 138 LBS W097-151-01 P597-315-05 HK1-1070-12 GS CLIMBING MAST WELDMENT CLIP PLATE 5/8" X 7" BOLT KIT QTY: 1 QTY: 1 QTY: 2 WEIGHT: 121 LBS EACH WEIGHT: 4 LBS EACH WEIGHT: 0.90 LBS EACH...
- Page 3 PRE-INSTALLING THE GS CLIMBING MAST WELDMENT WITH STEP BOLT KITS Before installing this Climbing Mast Accessory to a Guardian Series' tube arm or Collar Mount, it is important to attach the Step Bolt kit in (9) locations as shown below. See Detail C for more specific installation instructions.
- Page 4 INSTALLING TO GUARDIAN SERIES PLATFORM: TUBE ARM (OPTION A) STEP 2A ATTACHING CLIP PLATE TO CLIMBING MAST The Clip Plate is used only for instances where the Climbing Mast Accessory is being installed to the Platform Tube Arm (not needed for Collar Mount installation).
- Page 5 INSTALLING TO GUARDIAN SERIES: COLLAR (OPTION B) STEP 2B ATTACHING CLIMBING MAST TO COLLAR MOUNT After Step 1 has been completed, proceed to install the GS Climbing Mast Accessory to the Collar Mount as shown below. Note: Clip Plate (P597-315-05) included in PV-LPP-GS-ACC5 Kit, will not be used for Climbing Mast to Collar Installation...
- Page 6 NOTES www.perfect-vision.com 1-844-887-6723 6 OF 8 LPP-GS-ACC5-INS-01-R0...
- Page 7 NOTES www.perfect-vision.com 1-844-887-6723 7 OF 8 LPP-GS-ACC5-INS-01-R0...
- Page 8 NOTES www.perfect-vision.com 1-844-887-6723 8 OF 8 LPP-GS-ACC5-INS-01-R0...
