- Page 1 EDGE LIT RAZOR LED LCD HDTV ™ E320VT / E370VT / E420VT – QUICK START GUIDE...
-
Page 2: Package Contents
PACKAGE CONTENTS VIZIO LCD HDTV with Base Remote Control with Cleaning Cloth RF Adapter User Manual and Batteries Quick Start Guide... -
Page 3: Using The Remote
USING THE REMOTE Power/Standby: Turn the TV on or off. Input: Change the input device. A/V Controls: Control USB photo slideshow. Info: Display the Info Window. Input Power/Standby CC: Open the Closed Captioning menu. A/V Controls Menu: Display the on-screen menu. Info Exit: Close the on-screen menu. -
Page 4: Installing The Base
INSTALLING THE BASE Place the TV screen-down on a clean, flat surface. To prevent Place the base against the back of the TV as shown. scratches or damage to the screen, place the TV on a soft surface, such as carpet, rug, or blanket. - Page 5 Using a philips-head screwdriver, attach the base to the TV by Move the TV with attached stand into an upright position and inserting and tightening the 4 included screws. place on a flat, level, and stable surface.
-
Page 6: First Time Setup
FIRST-TIME SETUP Remove the battery cover by pressing gently and Connect the power cord to the back of the TV. pushing it away from the remote. Plug the power cord into an electrical outlet. Insert the batteries. The + and - symbols on the batteries must correspond to the + and - symbols inside the battery compartment. - Page 7 Initial Setup Welcome Allow the VIZIO setup Wizard to help you tune your channels. Next Exit EXIT Turn the TV on by pressing the Power/Standby button on the If you have an external antenna or a cable connection that extends from a wall outlet, connect it to the TV with an remote or on the side of the TV.
- Page 8 Initial Setup Language Initial Setup Mode Setting Please select your language: English Please select your input location: Home Français Retail Español Back Select Next Exit EXIT Back Select Next Exit EXIT Press the Up/Down Arrow buttons on the remote to highlight Press the Up/Down Arrow buttons on the remote to highlight your preferred language.
- Page 9 Initial Setup Initial Setup Tuner Channel Scan Please select your input source: Antenna Please connect your cable or Scan antenna to the DTV/TV input Cable Skip Scan Back Select Next Exit Back Select Next Exit EXIT EXIT Press the Up/Down Arrow buttons on the remote to highlight If the TV is connected to an external antenna, select Antenna, then press Right Arrow and go to step 7.
-
Page 10: Connecting Your Devices
HDMI Component To get the best high-resolution picture and sound on your new VIZIO TV, connect your devices with an HDMI cable. VIZIO High Speed HDMI Cables are manufactured to produce the best picture on VIZIO TVs and feature: Composite AV • 1080p and for full HD video and future Ultra-HD video... - Page 11 Blu-ray/DVD Player, Game Console, or other Device Back of TV CHOOSE ONE: High Speed HDMI Cable* HDMI HDMI Best Picture Component Video Cable* CB/PB CB/PB CR/PR CR/PR Better Picture Audio Cable* Composite AV Cable* Good Picture VIDEO VIDEO *Not Included...
-
Page 12: Vizio Recommends
VIZIO RECOMMENDS Add home theater surround sound without the excess clutter of wires! The VIZIO 5.1 Surround Sound Home Theater with Wireless Subwoofer delivers big home theater sound in a sleek design that’s perfect for your TV: • Universal 5.1 soundbar with rear satellite speakers and wireless subwoofer turns any TV into a home theater • Wireless subwoofer uses Wireless HD Audio... - Page 13 AVAILABLE AT VIZIO.COM Complete your home theater experience! The VIZIO Blu-ray Player with Wireless Internet Apps delivers full 1080p HD video, 7.1 surround sound and has built-in 802.11n dual-band wireless for easy access to movies, TV shows, music and more from the Internet.
-
Page 14: Help Topics
For technical assistance contact our VIZIO Technical Support Department via email or phone. Hours of operation: Monday - Friday: 6 am to 9 pm (PST) Please have your VIZIO model number, serial number, and date of purchase available before your Saturday - Sunday: 8 am to 4pm (PST) call. - Page 15 I cannot return to • The on-screen menu has guided setup. Press MENU, then select Help > System Reset > the Setup App. Start Setup Wizard. Enter your PIN (default is 0000). Select Yes. • Set the TV to Wide or Zoom Mode. There are black/gray • Adjust the video settings of your external device (Blu-ray or DVD player). ™ bars on the top/bottom/ • If using the RGB (computer) input, ensure you are using a supported desktop resolution. sides of the picture.
- Page 16 TRADEMARKS SHOWN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. VIZIO, THE V LOGO, WHERE VISION MEETS VALUE, AND OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
