Parma ROLLAHARROW Owner's Manual & Parts Book

3-point model

Advertisement

Quick Links

ROLLAHARROW
3-Point Model
OWNERS MANUAL & PARTS BOOK
Manual Number 1162017-3RH
————————————————————————————————————————————
P.O. Box 190
PARMA, IDAHO 83660
PHONE (208) 722-5116 FAX (208) 722-6012
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROLLAHARROW and is the answer not in the manual?

Questions and answers

Summary of Contents for Parma ROLLAHARROW

  • Page 1 ROLLAHARROW 3-Point Model OWNERS MANUAL & PARTS BOOK Manual Number 1162017-3RH ———————————————————————————————————————————— P.O. Box 190 PARMA, IDAHO 83660 PHONE (208) 722-5116 FAX (208) 722-6012...
  • Page 2 www.parmacompany.com...
  • Page 3: Table Of Contents

    Index 1 OWNERS MANUAL ......... 1.1 INTRODUCTION .
  • Page 4: Owners Manual

    When it comes to service, keep in mind that your dealer knows your Rollaharrow well and is interested in your complete satisfaction. Your dealer invites you to call him for your service needs both during and after the warranty period.
  • Page 5: Safety Precautions

    1.2 SAFETY PRECAUTIONS TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGH OUT THIS MANUAL IS USED TO CALL YOUR ATTENTION TO INSTRUCTIONS INVOLVING YOUR PER- SONAL SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE IN- STRUCTIONS CAN RESULT IN INJURY OR DEATH. THIS SYMBOL MEANS -ATTENTION! -BECOME ALERT!
  • Page 6: Equipment Safety Guidelines

    EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
  • Page 7: Safety Sign Care

    REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts replaced without decals, new decals must be applied. New decals are available from your authorized dealer or manufacturer. SAFETY SIGN CARE - Keep safety signs clean and legible at all times. - Replace safety signs that are missing or have become illegible.
  • Page 8: Before Operating

    How to Install Safety Signs: - Be sure that the installation area is clean and dry. - Decide on the exact position before you remove the backing paper. - Remove the smallest portion of the split backing paper. - Align the decal over the specified area and carefully press the small portion with the exposed sticky backing in place.
  • Page 9: Following Operation

    - NO PASSENGERS ALLOWED Do not allow any passengers to ride on the equipment at any time. - Keep hands and clothing clear of moving parts. - Do not clean, lubricate or adjust your equipment while it is in motion. - When halting operation, even periodically, disengage the PTO, shut off the tractor engine and remove the ignition key.
  • Page 10: Performing Maintenance

    - Be observant of bridge loading ratings. Do not cross bridges rated lower that the gross weight at which you are operating. Be aware of the width of bridge and the width of the machine before crossing. - Watch for obstructions overhead and to the side while transporting. - Always operate equipment in a position to provide maximum visibility at all times.
  • Page 11: Customer And Dealer Checklist

    Have the dealer and customer sign the form. Explain warranty policy on the Warranty Registration Form. Return the factory copy of the form to Parma Company. Show the customer how to operate the Rollaharrow. Give the operators manual to him and ask him to familiarize himself with all sections of it.
  • Page 12: Daily Checklist

    DAILY CHECKLIST: Remove all debris from s-tines, leveling bar, and rollers. Lubricate (as instructed) all lubrication points (see pg.11). Check for loose or missing bolts or parts (especially on S-Tines). Check for undue or excessive wear of parts.
  • Page 13: Warranty Policy

    Operators Manual. All PARMA COMPANYS harvesting equipment products are warranted for 120 days from the first day of use or 800 acres, whichever occurs first. All PARMA COMPANY soil prepa- ration products are warranted for 120 days from first day of use or 1600 acres, whichever occurs first. All PARMA COMPANY water and waste pump products are warranted for one year from date of purchase.
  • Page 14: Maintenance And Field Adjustments

    1.5 MAINTENANCE AND FIELD ADJUSTMENTS 1.6 LUBRICATION The Rollaharrow flanged bearing units are factory pre-lubricated and do not require supplemental grease before service life begins. Re-lubrication, when administered correctly, can increase the life of a bearing substantially. Bearing manufacturers recommend that all these bearings be greased weekly, considering the environ- mental condition that these machines are exposed to.
  • Page 15: Bearings

    (Item A). When operating your Rollaharrow in the field, the safety snap pin (Item B) must be removed to prevent damage to the tine bars and linkages in the event the Rollaharrow is backed up with the S-Tines down (See the illustration on the next page).
  • Page 16: Roller Rings

    For the correct positioning of the S-Tines on the Rollaharrow, refer to pages 16. **Never lower and park the Rollaharrow on the S-Tines. Damage to the curl of the S-Tine will occur. 1.10 ROLLER RINGS After some usage of your machine, the side of roller rings will wear, creating a gap between the rings on the roller tube.
  • Page 17: Leveling Bar

    field at speeds up to 6mph. Recommended minimum air pressure is 70 PSI in the bias ply tires and 50 PSI in the Radial Tires. Do not use the tires and wheels on your Rollaharrow as gauge wheels while operating the machine in the field. They are designed for transporting the machine only.
  • Page 18: Bolt Torque

    BOLT TORQUE Checking Bolt Torque The table shown below gives correct torque values for various bolts and cap screws. Tighten all bolts to the torques specified in the chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. Replace hardware with the same strength bolt Bolt Size SAE 2 SAE 5...
  • Page 19: S-Tine Sapcing

    1.13 S-TINE SAPCING...
  • Page 20: Parts Book

    2 PARTS BOOK 2.1 S-TINE GROUP ITEM NO. QUANTITY PART NO. DESCRIPTION 521483 S-tine, HD 521485 S-tine Clamp 521484 Chisel Point 521560 Chisel Point, Heavy Duty (Optional) 530052 Cultivator Bolt, 3/8 x 1 ——– Hex Bolt, 1/2 x 3 1/2 ——–...
  • Page 21: Tine Bar Group 10'-14

    2.2 TINE BAR GROUP 10’-14’ ITEM NO. QTY 10’ QTY 12’ QTY 14’ PART NO. DESCRIPTION ——– ——– 525968 Tine Bar, 122 3/4 in. ——– ——– 522329 Tine Bar, 146 3/4 in. ——– ——– 521571 Tine Bar, 170 3/4 in. 524536 Mounting Bracket, Outer 524535...
  • Page 22: Tine Bar Group 16'-20

    2.3 TINE BAR GROUP 16’-20’ ITEM NO. QTY 16’ QTY 18’ QTY 20’ PART NO. DESCRIPTION ——– ——– 522082 Tine Bar, 128 1/8 in. ——– ——– 522092 Tine Bar, 140 1/8 in. ——– ——– 522125 Tine Bar, 152 1/8 in. ——–...
  • Page 23: 10" Roller Assemblies 10'-16

    2.4 10” ROLLER ASSEMBLIES 10’-16’ ITEM NO. QUANTITY PART NO. DESCRIPTION As Reqd4 523341 Roller Weldment, 10 ft. Standard As Reqd 523343 Roller Weldment, 12 ft. Standard As Reqd 523345 Roller Weldment, 14 ft. Standard As Reqd 523347 Roller Weldment, 16 ft. Standard As Reqd 523342 Roller Weldment, 11 ft.
  • Page 25: 12" Roller Assemblies 10'-16

    2.5 12” ROLLER ASSEMBLIES 10’-16’ ITEM NO. QUANTITY PART NO. DESCRIPTION As Reqd 523376 Roller Weldment, 10 ft. Standard As Reqd 523378 Roller Weldment, 12 ft. Standard As Reqd 523380 Roller Weldment, 14 ft. Standard As Reqd 523382 Roller Weldment, 16 ft. Standard As Reqd 523377 Roller Weldment, 11 ft.
  • Page 27: 10" Roller Assemblies 18'-20

    2.6 10” ROLLER ASSEMBLIES 18’-20’ ITEM NO. QUANTITY PART NO. DESCRIPTION As Reqd 523356 Split Roller Weldment, 18 ft. As Reqd 523358 Split Roller Weldment, 20 ft. As Reqd 523349 Roller Weldment, 18 ft. (Standard) As Reqd 523351 Roller Weldment, 20 ft. (Standard) As Reqd 523350 Roller Weldment, 19 ft.
  • Page 29: 12" Roller Assemblies 18'-20

    2.7 12” ROLLER ASSEMBLIES 18’-20’ ITEM NO. QUANTITY PART NO. DESCRIPTION As Reqd 523391 Split Roller Weldment, 18 ft. As Reqd 523393 Split Roller Weldment, 20 ft. As Reqd 523384 Roller Weldment, 18 ft. (Standard) As Reqd 523386 Roller Weldment, 20 ft. (Standard) As Reqd 523385 Roller Weldment, 19 ft.
  • Page 31: Crowfoot Roller Assemblies

    2.8 CROWFOOT ROLLER ASSEMBLIES ITEM NO. QUANTITY PART NO. DESCRIPTION As Reqd 524242 Crowfoot, 20 in. x 5 5/8 in. Hub Length As Reqd 524243 Crowfoot, 20 in. x 4 in. Hub Length As Reqd 524452 Spacer As Reqd 980827 Bearing, 2 3/16 in., 4-Hole Flanged 524451 Spacer (12 ft.
  • Page 33: Pipe Roller Assemblies

    2.9 PIPE ROLLER ASSEMBLIES ITEM NO. QUANTITY PART NO. 16” PART NO. 20” DESCRIPTION As Reqd 525987 525249 Pipe Roller, 10 ft. As Reqd 525989 525168 Pipe Roller, 11 ft. As Reqd 523808 523818 Pipe Roller, 12 ft. As Reqd 523872 523882 Pipe Roller, 13 ft.
  • Page 34: Leveling Bar & Lift Group (10'-16')

    2.10 LEVELING BAR & LIFT GROUP (10’-16’) ITEM NO. QUANTITY PART NO. DESCRIPTION 525969 Leveling Bar (10 ft.) 522046 Leveling Bar (12 ft.) 522052 Leveling Bar (14 ft.) 522079 Leveling Bar (16 ft.) 524761 Lifting Bar Weldment (Includes Bushings) 521375 Side Link 521374 Pull Link, Inner...
  • Page 35: Leveling Bar & Lift Group (18'-20')

    2.11 LEVELING BAR & LIFT GROUP (18’-20’) ITEM NO. QUANTITY PART NO. DESCRIPTION 522089 Leveling Bar (18) 522129 Leveling Bar (20) 524765 Lifting Bar Weldment (Includes Bushings) 521375 Side Link 521374 Pull Link, Inner 524764 Lift Bar Bracket 521488 Lift Link 522029 Lift Link Weldment 521391...
  • Page 36: Leveling Bar Rock Protection Kit

    2.12 LEVELING BAR ROCK PROTECTION KIT ITEM NO. QUANTITY PART NO. DESCRIPTION 521300 Link Assembly w/ Depth Indicator 521291 Link Assembly 522301 Decal Indicator Decal...
  • Page 37 HYDRAULIC SCHEMATIC (10’-16’) ITEM NO. QUANTITY PART NO. DESCRIPTION 267835 Hydraulic Cylinder, 3 x 8 w/ Hrdnd Clevis 2503-8-8 Straight Thread Elbow, 1/2 x 1/2 O-Ring ——– Hydraulic Hose, 1/2 x ?? w/ 1/2 MNPT & 1/2 JIC Female End ——–...
  • Page 38: Hydraulic Schematic (18'-20')

    2.13 HYDRAULIC SCHEMATIC (18’-20’) ITEM NO. QUANTITY PART NO. DESCRIPTION 267835 Hydraulic Cylinder, 3 x 8 w/ Hrdnd Clevis 2503-8-8 Straight Thread Elbow, 1/2 x 1/2 O-Ring 033T-8-8 Union Tee, 1/2 JIC ——– Hydraulic Hose, 1/2 x ?? w/ 1/2 MNPT & 1/2 JIC Female End ——–...
  • Page 39: Hydraulic Tine Bar Control

    2.14 HYDRAULIC TINE BAR CONTROL ITEM NO. QTY (12’ & 14’) QTY (16’-20’) PART NO. DESCRIPTION 998165 Hydraulic Cylinder, 3 x 10 524559 Cylinder Bracket 521260 Control Linkage 521495 Control Clamp 523157 Control Linkage 525262 Cylinder Bracket 523000 Cylinder Ear 521513 Control Clamp 295050...
  • Page 40: Decal Group

    2.15 DECAL GROUP ITEM NO. QUANTITY PART NO. DESCRIPTION 264797 Decal, Parma 100406 Decal, General Caution 100404 Decal, Block Machine 100311 Decal, Rotating Parts 100423 Decal, FEMA 100408 Decal, Hydraulics Pressurized 264515 Reflector, Yellow As Req’d* 264516 Reflector, Red As Req’d*...
