Summary of Contents for Calca CS-FEF-JS100
- Page 1 ADVANCED SYSTEM & SUPPLIES CALCA 440W Universal Fume Extractor Filter 250m³/h for DTF Powder Shakers and Sublimation Heater CS-FEF-JS100 User Manual Please read this manual carefully before operation...
- Page 2 ADVANCED SYSTEM & SUPPLIES Thank you very much for choosing our CALCA brand series Fume Extractor Filter, please read the manual carefully, including the operation and maintenance to ensure the best output and the lifetime of the machine. Direct Transfer Printing is a revolutionary new printing technique that’s more affordable and accessible compared to DTG, screen printing, sublimation or laser white toner transfers.
-
Page 3: Table Of Contents
ADVANCED SYSTEM & SUPPLIES CONTENT I. Notice On Safety Using ................4 1. -
Page 4: Notice On Safety Using
For your safety. Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. 3.2 Other prohibitions (dangerous procedures) Using any parts other than genuine CALCA approved manufactured parts can void the warranty. Improper installation, adjustment, alteration, service or maintenance can cause property damage or major injury. -
Page 5: Notice Before Starting It
ADVANCED SYSTEM & SUPPLIES 4. Notice Before Starting It: This machine is a high voltage equipment, in order to use the machine better please be aware of following specification. Equipment installation instructions Installation and placement ❶ The equipment should be placed in a dry and ventilated environment ❷... -
Page 6: Functional Description
Great for mid-sized 24in roll to roll DTF powder shakers. Features: 1. The components used in the CALCA fume extractor are of high quality, the filter element is thicker, the filtration capacity is stronger, and the product is more durable 2. -
Page 7: Component And Installation
Recommended for customers to use. WARNING: WORK IN A WELL VENTILATED AREA and use Protective Equipment when working with DTF products and processes as fumes may be hazardous. Data Sheet: CALCA Brand: USA registered ● Energy consumption: 150~440W ●... -
Page 8: Equipment Operation
ADVANCED SYSTEM & SUPPLIES 2.2 Connection of The Smoke Outlet Shaker Purifier Outdoor III. Equipment Operation 1. Equipment Operation process 1.1 Move the fume extractor filter to the left of the powder shaker, connect the connecting pipe on the smoke outlet of the powder shaker to the air inlet of the fume extractor filter. -
Page 9: Installation Method
ADVANCED SYSTEM & SUPPLIES 2. Installation Method Smoke outlet Main power Air volume control Smoke inlet Oil drain outlet Make sure that the door of the fume extractor filter is closed and there is no smoke leakage. CAUTION IV. Equipment Maintenance 1. -
Page 10: Warranty Card
Notes The warranty card should be filled out by seller and kept by buyer. Alterations are prohibited. ii. 24 Month Warranty - CALCA DTF shaker includes a 24 month warranty, consumable parts are excluded from the warranty. iii. No free repair is available for any damages caused by the improper use.
