Summary of Contents for ORANGE O
- Page 1 O Turntable User Manual...
-
Page 3: Compliance Information
Due to local laws, warranties may vary by country in which units are sold. Please contact your Orange retailer or distributor for warranty details. Your statutory rights are not affected. Please do not dispose of the product packaging. The original packaging must be used if returning a product to your dealer or distributor for 1.5 UKCA Mark... -
Page 4: Output Connections
6. Connect the power supply to the rear of the turntable. 7. Carefully remove the stylus guard from the cartridge (2). 8. Turn on the O Turntable via the on/off switch located on the underside of the plinth (5). 9. Change the speed by moving the drive belt from the 33 and 45 steps of the pulley (A). -
Page 6: Power Connection
6. Power connection Plug in the Orange O Turntable 350mA power supply into the wall socket. Set-up is now complete. Simply switch on, sit back and enjoy! WARNING: Only use the supplied mains adaptors with this product. - Page 7 7.1 O Turntable specifications Maximum output level (3.54cm/s RMS 45°CBS STR100 band 6a and 7a) 370-410mV Output impedance 1kΩ Frequency response (pre-amplifier only) 14Hz (-3dB Point) to 100kHz (-0.6dB Point) RIAA accuracy (pre-amplifier only) (100Hz to 20kHz) ±0.4dB typically better than ±0.25dB...
- Page 8 OMEC Consumer Products Ltd., Unit 2 Abbeymead Industrial Estate, Brooker Road, Waltham Abbey EN9 1HU Orange O Turntable User Manual | Version 1...
