Summary of Contents for Master Chef 18MCMHR-2422
- Page 1 MASTER CHEF OPTIMO COUNTERTOP STOVE 18MCMHR-2422 18MCMHR-3631 PIEZOELECTRIC AUTOMATIC PIEZOELECTRIC AUTOMATIC BURNER IGNITION. DRIP PAN. HIGH CALORIFIC BURNER. DURABLE CAST-IRON GRATE. CAST-IRON BODY, HEAD ANTI-SLIP RUBBER LEG ◎ ◎...
-
Page 2: Table Of Contents
Product feature Thanks for purchasing our product. Please read this manual carefully and keep it for future reference. If the information in this guide is not followed exactly, a fire or explosion may result in property damage, personal injury or death. 1.Convenient to use Easy to control flame size like Hi-Medium-Low (3step flame control) according to cooking type or quantity. -
Page 3: Safety Warning
Safety Warning Warning, Caution and Important safety instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating this appliance. Recognize each symbol and then read this manual carefully. -
Page 4: Safety Caution
Safety Caution Caution Keep away flammable materials Let in some air often Do not store or use flammable vapors All the gas Burners consume oxygen in (Gasoline, Benzene or other flammable the air, so let in some air often by vapors) near this appliance. -
Page 5: Each Part Name
Each part name Model : 18MCMHR-2422 Grate Burner Head Drip pan Main body Control knob Accessory User's Guide... -
Page 6: How To Install
How to Install Install Intermediate valve on a convenient place This appliance is for low gas supplying pressure Intermediate valve should be away from the Use only the gas regulator whose gas supplying burners or any other heating resources or hot pressure is indicated on the rating label. -
Page 7: Before Use
Before Use Check if the indicated gas on the Rating Label is correct. Use only the gas indicated on the Rating Label. If the using gas is different from that indicated on the Rating Label, it may result in malfunctions or diasters. Be sure all Control Knobs are set to the OFF positions Check if Food Garbage Receiver is Be sure to check it before... -
Page 8: Care And Cleaning
Care and Cleaning Before cleaning, make sure Intermediate valve is closed and all controls are off and the appliance is cool Put on gloves not to suffer a burn or injury. Be sure all dispensable things like detergent or cleaning pad are removed from the appliance after cleaning or care. Do not repair, disassemble and modify. - Page 9 Care and Cleaning Exterior Surface Usable Unusable Nylon pad Metal pad Cooking oil Sponge pad Soft cloth Neutral detergent Abrasive Thinner,Benzene Acid/Alkali detergent Top Plate Surface of this appliance may be damaged if clean it with metal(steel-wool) pads. It may be extremely difficult to clean it if you neglect boiling over for a long time. Burners Make sure to put on gloves before cleaning.
-
Page 10: Before Call For Service
Before Call for Service Check List Solution Problem If Intermediate Open Intermediate valve. No gas valve is closed Turn the burner off, and Backfire "Cracking" or re-light it after a while. "Popping" sound Same problems hold out, call for service. Poor gas piping. -
Page 11: Product Specifications
Product Specification Dimension Dimension : inch Description MASTER CHEF OPTIMO COUNTERTOP STOVE Model 18MCMHR-2422 Width 23 15/32" Dimension Depth 20 43/64" Height 6 1/2" 35.3 lbs Weight Total 41,000 20,500 20,500 LPG (BTU) consumption Gas connecting PT 3/4"(20A) - Page 12 Product Specification Dimension Dimension : inch Description MASTER CHEF OPTIMO COUNTERTOP STOVE Model 18MCMHR-3631 Width 35 9/32" Dimension Depth 20 43/64" Height 6 1/2" 52.9 lbs Weight 61,500 20,500 20,500 20,500 Total LPG (BTU) consumption Gas connecting PT 3/4"(20A)
- Page 13 Memo...
- Page 14 Memo...
- Page 15 Memo...
