Summary of Contents for ALLIANCE Avimore
- Page 1 Installation Guide alliancefencesupply.com (+1) 801-852-8542...
- Page 2 Installation Guide alliancefencesupply.com (+1) 801-852-8542...
- Page 3 Installation Guide Quick Reference - Installation correct length for the section Step 1: Familiarize yourself with Avimore Fence • Basic styles and fill options Step 6: Install bottom rail or • Post types and components picket • Determining body height/width •...
-
Page 4: Disclaimer
Fence installation should always be conducted by or under the supervision of an experienced and responsible professional. Follow all local building and zoning codes when installing Avimore fence. Do not install Avimore fence in an area where you do not have permission to do so. alliancefencesupply.com... -
Page 5: Table Of Contents
11 Step 6: Install bottom rail or picket 12 Step 7: Add remaining fill material and top picket or rail 13 Step 8: Install gates 13 Step 9: Install gap fillers and post caps 14 Appendix: Avimore Parts List alliancefencesupply.com (+1) 801-852-8542... -
Page 6: Step 1.1: Basic Styles And Fill Options
Installation Guide Step 1.1: Basic styles and fill options The frame + fill design of Avimore fence allows for a wide variety of aesthetic configurations. The two main styles are Avimore Breeze, which uses Avimore Breeze aluminum pickets between posts, and Avimore Modern, which uses pocket rails between posts to hold a horizontal or vertical privacy infill. -
Page 7: Step 1.2: Post Types And Components
Installation Guide Step 1.2: Post types and components There are two types of Avimore posts – aluminum channeled line posts, and steel gate posts. Both have a profile of 3”x3”. Steel gate posts will be needed on either side of any gate, and anywhere else a smooth blank post is required. -
Page 8: Step 1.3: Determining Body Height And Rail Or Picket Width
For Horizontally Oriented Pickets: Breeze pickets are available in lengths of 72” or 96”. T&G slats for Avimore Modern are available at 64” long, and can be cut shorter as needed. For the body height in inches corresponding to each picket count, refer to the chart below:... -
Page 9: Step 1.4: Determining Post Height
Installation Guide Step 1.4: Determining post height All Avimore posts have dimensions of 3”x3” square. Posts are sold in heights of up to 12’. Plan on keeping at least 25% of the post secured below ground for in-ground posts, and ensure that your above-ground post height is greater than the desired body height of the fence. -
Page 10: Steps 2 And 3: Space Posts And Dig Holes
Installation Guide Steps 2 and 3: Space posts and dig holes To calculate center-to-center post spacing, begin with the pocket rail or Breeze picket length, and add ⅛” for each interior post channel connection, and 1⅝” for each exterior u-channel connection. -
Page 11: Step 5.1: Position Posts
Installation Guide Step 5.1: Position posts Insert each post in its hole and fill the hole around the post with concrete mix up to 2”-4” below grade. Tamp concrete to reduce air pockets, and level and square the post. Step 5.2: Verify post spacing Before fully allowing posts to set, slide a rail or Breeze picket of the correct section length into the post channels on either side to ensure the posts are set to the correct spacing. -
Page 12: Step 7: Add Remaining Fill Material And Top Picket Or Rail
Installation Guide Step 7: Add remaining fill material and top picket or rail Once the bottom picket (for Avimore Breeze) or the bottom rail (for Avimore Modern) is secured, the rest of the material should slide easily into the post channel above it. -
Page 13: Step 8: Install Gates
Installation Guide Step 8: Install gates Ensure that the space between gate posts is approximately 2” more than the width of the gate itself. If spacing is too narrow, the gate can be disassembled to cut the rails and pickets to a smaller size. -
Page 14: Appendix: Avimore Parts List
Installation Guide Appendix – Avimore Parts List Part Picture Details Used with: • Max 12’ Length Aluminum • Avimore Breeze • 3”x3” Outer Dim. • Avimore Modern Channeled Post • 1 3/16 7/16 ”x1 ” Channel • Max 12’ Length •... - Page 15 Installation Guide Appendix – Avimore Parts List Part Picture Details Used with: • 0.5”, 1”, or 1⅜” 1-Hole U-Channel • Spaces Breeze • Avimore Breeze Bracket Pickets in U-Channel Avimore Breeze • 72” or 96” Length • Avimore Breeze • 1”x3.5” Profile Picket •...
- Page 16 alliancefencesupply.com (+1) 801-852-8542...
