Summary of Contents for CeoTronics CT-WirelessPTT MIL
- Page 1 CT-WirelessPTT MIL Bluetooth® LE Product instructions...
-
Page 2: Table Of Contents
Contents Contents Safety notices........................ General ......................... Mounting options......................Identification ........................Pairing ........................... Power supply and operating time.................. Displaying the battery capacity ..................Changing the battery..................... Maintenance and care....................10 Inspecting devices......................10 Cleaning ........................10 Accessories........................11 2 / 12 dok1962-en-00-1124... - Page 3 dok1962-en-00-1124 3 / 12...
-
Page 4: Safety Notices
1 Safety notices Safety notices DANGER Immediate hazardous situation. Results in death or serious injury. WARNING Potentially hazardous situation. May result in death or serious injury. CAUTION Potentially hazardous situation with minor or moderate injury. NOTICE Indicates a situation that, if not avoided, may cause damage to the product or other prop- erty. -
Page 5: General
CT-WirelessPTT MIL receiver. This can interrupt the connection! Mounting options Mounting options for one and two CT-WirelessPTT MIL devices are available as a wrist strap mount and a Picatinny rail adapter. dok1962-en-00-1124... -
Page 6: Identification
2 General Identification Contains IC: 216Q-1740 article number frequency Contains FCC ID: XXXXXXX T7V1740 serial number 6 / 12 dok1962-en-00-1124... -
Page 7: Pairing
A green LED indicates that the devices are successfully paired. The LED goes out after a set time – the CT-WirelessPTT MIL is ready to use. If pairing fails, the LED lights up red. In this case, repeat the pairing process and delete any saved pairings in the other device. -
Page 8: Power Supply And Operating Time
3 Power supply and operating time Power supply and operating time Power is supplied by a commercially available 3V battery (type CR2032) in the battery com- partment of the device. We recommend using a battery with a capacity of at least 210mAh. With this type of battery, operating times of up to 6 months can be achieved, depending on the ambient temperature and the intensity of use. -
Page 9: Changing The Battery
3 Power supply and operating time Changing the battery CAUTION Equipment damage! Ensure the correct polarity! Open the cover – change battery – check correct positioning "+" dok1962-en-00-1124 9 / 12... -
Page 10: Maintenance And Care
4 Maintenance and care Maintenance and care Inspecting devices Routinely inspect your CeoTronics device for damage and wear and have them repaired, if necessary. Cleaning Do not use alcohol or other solvents for cleaning. Clean the device with a suitable cloth moistened with clean water. -
Page 11: Accessories
5 Accessories Accessories Description Part no Wrist strap with mount for two CT-WirelessPTT MIL 4008090 Wrist strap with mount for one CT-WirelessPTT MIL 4008098 Picatinny mount for two CT-WirelessPTT MIL 4008095 Picatinny mount for one CT-WirelessPTT MIL 4008102 dok1962-en-00-1124 11 / 12... - Page 12 CeoTronics AG Audio · Video · Data Communication Adam-Opel-Str. 6 63322 Rödermark (Deutschland) Tel: +49 6074 8751-0 Fax: +49 6074 8751-676-265 E-Mail verkauf@ceotronics.com...
