Page 1 User Manual EV AC Charger SUN-EVSE11K01-EU-AC SUN-EVSE22K01-EU-AC...
Page 2: Table Of Contents
Contents All Rights Reserved ......................01 About This Manual ......................01-02 1 Safe Introductions......................03 2 Introduction........................04-06 2.1 Introduction of installation methods 2.2 Model 2.3 Appearance and Dimensions 2.4 System Topology 3 Installation ........................07-10 3.1 Installation 3.2 Unpacking and Inspection 3.3 Installation Tools 3.4 Electrical Connection 3.4.1 Circuit Diagram 3.4.2 Recommended specification of AC cable and PE...
Page 3: All Rights Reserved
Software Licenses • It is prohibited to use data contained in firmware or so ware developed by DEYE, in part or in full, for commercial purposes by any means. • It is prohibited to perform reverse engineering, cracking, or any other operations that compromise the original program design of the so ware developed by DEYE.
Page 4 Please read this manual carefully before using the product and keep it properly in a place for easy access. All contents, pictures, marks, and symbols in this manual are owned by DEYE. No part of this document may be reprinted by the non-internal sta of DEYE without written authorization.
Page 5: Safe Introductions
• Never spray water or any other liquid directly onto the charger body or the charging connector. Store the charger in the connector socket to prevent unnecessary damage. • Do not attempt to disassemble, repair, tamper with or modify the charger. Contact DEYE for any repair or modification.
Page 6: Introduction
• Ease of Use EV drivers can start and stop charging via LCD screen of Deye hybrid inverter or App. When the vehicle is fully charged, the charging will stop. The charger also supports plug&play charging, which means the charging starts automatically as soon as the charging connector is plugged into the vehicle.
Page 7: Appearance And Dimensions
2.3 Appearance and Dimensions ① ② ⑦ ③ ④ ⑤ ⑥ 1:Function button 3:Alarm indicator 5:Lora indicator 7:Type 2 2:LED strip 4:Normal indicator 6:WIFI indicator �m �� .�m �� - 05 -...
Page 8: System Topology
2.4 System Topology AC cable DC cable Wi-Fi Service Solar Hybrid Inverter Backup Load Charger Battery Home Load Grid - 06 -...
Page 9: Installation
3. Installation 3.1 Introduction • Location Requirements Select an optimal mounting location for safe operation, long service life and expected performance. • Environment Requirements • There must be no flammable hazards or ignition risks. • The mounting location must be inaccessible to children. •...
Page 10: Installation Tools
RCD and a miniature circuit breaker. 3.4.2 Recommended speciﬁcation of AC cable and PE Model Wire Size Cross section SUN-EVSE11K01-EU-AC 14AWG 1.5mm SUN-EVSE22K01-EU-AC 10AWG Recommended Size for AC Cable and PE...
Page 11: Single Phase Connection
3.4.3 Single phase connection LOAD ➀Type-A Note： ��mA RCD The bending angle LOAD should not be too large to avoid cable damage caused by long-term stress. GRID ➀Type-A ��mA RCD Note： The bending angle should not be too GRID large to avoid cable damage caused by long-term stress.
Page 12: Three Phase Connection
3.4.4 Three phase connection LOAD ➀Type-A Note： ��mA RCD LOAD The bending angle should not be too large to avoid cable damage caused by long-term stress. GRID GRID Note： ➀Type-A The bending angle ��mA RCD should not be too large to avoid cable damage caused by long-term stress.
Page 13: Inspection Before Commissioning
4. Inspection before Commissioning • Location The charger is correctly mounted at a place that is convenient for operation and maintenance. • Charger The charger is firmly and securely installed. • Cable Cables are correctly and firmly connected, and are adequately protected from damage. •...
Page 14 Status Indicator Meaning Displaying a blue breathing light eﬀect Charging in 'plug and play' mode Displaying a green breathing light eﬀect Charging in 'Time of charge' mode Displaying a white breathing light eﬀect Updating LED strip(tri-color LED) Emergency stop Red LED light is on (The relays will disconnect) idle or A malfunction has occurred Make a sound...
Page 15: Wifi And Lora Configuration
For WIFI configuration, the following two methods are recommended. 5.1.1 WiFi conﬁguration via APP Step 1: Tap on “ ” icon in the upper right corner of Deye cloud APP, select “Wi-Fi configuration” and automatically jump to the page for scanning nearby devices; 16:54 16:53 德业变频...
Page 16 Config Device Done Add a Device Config Device Done SN:3422688527 Scanning nearby devices Please use 2.4G WIFI network Nearby devices(24) Select WIFI AP_381927 AP_383545 Deye-TEST AP_3422688527 AP_383354 ..AP_382547 AP_353454 WIFI has no password AP_383547 AP_383578 AP_3636354 AP_3837868 Next Scan...
Page 17: Wifi Configuration Via Localhost
Step 4: Wi-Fi configuration is in process (Please don’t leave this page and place your phone near the devices); Step 5: A er Wi-Fi configuration done, you could enter a personalized device name and tap on “Complete” to end the configuration. Config Device Done Add a Device...
Page 18: Lora Configuration
Webpage monitoring address: https://www.deyecloud.com To use the APP for monitoring on mobile devices, please scan the QR code below. 5.2.Lora conﬁguration 5.2.1 Steps to establish Lora communication Step1: Bind the EV charger to the inverter. Method 1: 1. Enter the Main screen of inverter’s LCD.Click on the gear icon in the upper right corner of the screen to enter the ‘System Setup’...
Page 19 2. Click on the ‘Smart Devices’ item on the ‘System Setup’ page to enter the ‘Smart Devices’ page. System Setup Work Mode Smart Devices Battery Setting Gen Port Grid Setting Basic Advanced Device Info Setting Function 3. Click on the ‘’Smart EV Charge’ icon to enter the parameters page of EV Charger. Smart Devices Smart Switch Smart CT...
Page 20 5. Click the 'Edit SN' button and then click the 'OK' button on the 'SN input' page, the so keyboard will display on the screen for you to type in the series number of the smart CT meter, its series number can be found on its label. SN Input 6.A er completing the input and confirming it is correct, click "OK"...
Page 21 Method 2: 1. Click on the plant that needs to add an "EV Charger" 2. Click on the "Device" item in the bottom on the plant listpage to enter the "Overview" page right corner of the"Overview" page to enter of the plant the "Device"...
Page 22 3. Click on the blue "Smart Devices" item in the 4. Click on the "+" icon in the bottom right middle of the"Inverter" page to enter the "Bind corner of the page to enter the"Scan SN" page. a Lora Device" page - 20 -...
Page 23 5. Scan the QR code corresponding to the SN 6. Manually enter the SN of the EV Charger, information of the EV chargeraccording to the then click the "Confirm" buttonto confirm prompts on this page. You can also click on the " and complete the input.
Page 24 7.Select 'Device Type' as' EV Charger ', then 8.A er completing the binding, the following click the "Confirm" button to confirm and message will pop up indicatingsuccessful complete the binding. binding. - 22 -...
Page 25 Step 2: Enable the EVcharger and conduct communication channel scanning A er correctly inputting SN of EV charger's Lora module and enabling EV charger(as shown in Figure 5.2-1), press and hold the button(as shown in Figure 5.2-2)on EV charger body until its LED strip turns purple to enter channel scanning mode.
Page 26: Adjustment Of Lora Communication Channel
5.2.2 Adjustment of Lora communication channel There are several ways to adjust the Lora communication channel of EV charger: Method 1: Adjust it on the localhost page of the built-in WiFi module of EV charger (as shown in Figure 5.2-4)，and please refer to chapter 5.1.2 for the method of entering the localhost of EV charger. Method 2: Refer to Chapter 6 to set the working mode (communication mode) of EV charger to WiFi mode, and then adjust its communication channel(communication frequency) on the webpage or APP of the cloud platform(as shown in Figure 5.2-5).
Page 27: Setting Of Communication Mode
6.Setting of communication mode This EV charger has two kinds of communication mode: WiFi mode and Lora mode. WiFi mode: Using the built-in WiFi module of EV charger, upload the operational data of EV charger to the cloud platform directly, or send command to the EV charger through the cloud platform's webpage. Lora mode: Pair the built-in Lora module of EV charger with the smart TX master node of the hybrid inverter, and then upload the operational data of EV charger or receive the control commands through the Lora module of EV charger.
Page 28: Local Control Mode
7.Local control mode 7.1 Explaination of parameters Smart Devices Click on 'Smart EV charge' item in the down le corner of 'Smart Devices' page Plug and play to enter the le page. SN:2024103294 ① ② Free work Enable A er checking the CheckBox in the upper Time of charge le corner of the page, you can follow Start-Time...
Page 29: View Operating Status Via Lcd
7.2 View operating status via LCD 1. Click the circle on the center of LCD's main screen. 01/08/2025 12:32:40 Off grid 0.00 0.00 0.09 0.03 2. A er the screen jumps to the page below，press the ‘UP’ or 'Down' button to enter the next page. Inverter 27 W 27 W...
Page 30: Remote Control Via App
8. Remote control via APP 2. A er entering the overview page of the solar 1. Find out the solar plant which the EV charger plant, you can find the icon of EV charger inside is bound in the plant list of the APP. the power flowing diagram.
Page 31 3. Click the icon of EV charger inside the power flowing diagram, the APP will turn to the operation status page of EV charger. And you can also change the settings of EV charger in this page. All these parameters are the same with the parameters on the LCD of inverter, please check the parameters explanation on chapter 7.1 16:54 16:54...
Page 32 4. Back to the overview page of the solar plant, and then click the “Devices” item on the down right corner of overview page to enter the Device page. 16:53 16:54 Production Today Weather ￥ /kWh 0.00 ℃ ￥ /kWh 德业科技股份有限公司...
Page 33 5. On the Device page, you can find the EV charger you need to set. Click the item of the corresponding EV Charger to enter its“Device Data” page. On this page, you can see the following information: Nameplate value, Basic Information, Version Information,Charging Information.
Page 34 6. On the menu line of “Device Data” page, click 7. Click on “Select parameter” in the upper right "History" to enter the page for displaying and corner of the data chart, you can choose the querying historical information. Historical data parameters wanted to display in the data chart can be presented in di erent time periods, such on the pop page.
Page 35 8. Click "Alerts" item on the menu line to enter the 9. Click "Architecture" item on the menu line to Alerts information page. check the Parent Device of this EV charger. 16:54 16:54 EV Charger EV Charger SN:E24C0501FF SN:E24C0501FF Last update 2025-01-14 16:53:34 (UTC +08:00) Device Data History Alerts...
Page 36 10. Click the "..." icon on the up right corner of the 11. There are two subordinate pages for Remote APP, and then select the "Remote control" control, and on the “Classification” page， option on the pop menu to enter the you can set the parameters below .
Page 37 12. Click the “Firmware Upgrade” button on the up right corner of the “Classification” page to enter the Page below. In this page, you can find the current EV Charger firmware information of EV charger. In the Upgrade operation zone, you can select the Remote Control firmware package which is used to upgrade the SN:E24C0501FF...
Page 38: Troubleshooting
LoRa module is fault or damaged. 3. Restart the EV charger,if Lora communication still can not be normal,please contact Deye support team for repairing or replacing. The actual charging current of EV AC charger is greater than the...
Page 39 3. Disassemble the wall box and reinstall the leakage 2.The leakage current sampling current sampling CT correctly CT isn't installed properly If the problem occurs repeatedly, please contact Deye after-sales support team. 1.Check if the charging connector is in good condition and free of foreign objects.
Page 40: Technical Data
10. Technical Data Model SUN-EVSE11K01-EU-AC SUN-EVSE22K01-EU-AC Product Parameter 230Va.c.(0.8Un to 1.15Un), Rated Voltage 400Va.c.(0.8Un to 1.15Un) 400Va.c.(0.8Un to 1.15Un) Connection Mode 3L+N+PE L+N+PE,3L+N+PE Rated Current 16Aa.c. 32Aa.c. Rated Frequency 50/60Hz 7kW (single phase) Maximum Output Power 11kW 22kW (three phase)
Page 41: Eu Declaration Of Conformitya
· Radio Equipment Directive ��/��/EU (RED) · Restriction of the use of certain hazardous substances ��/��/EU)(RoHS) NINGBO DEYE INVERTER TECHNOLOGY CO., LTD. conﬁrms herewith that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives.
Page 44 NINGBO DEYE INVERTER TECHNOLOGY CO., LTD Add.: No.26 South YongJiang Road, Daqi, Beilun, NingBo, China. Tel.: +86 (0) 574 8622 8957 Fax.: +86 (0) 574 8622 8852 E-mail: service@deye.com.cn Web.: www.deyeinverter.com...
