55 AMP PORTABLE MONSTER BATTERY CHARGER 12/24V
ITEM: 21523
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 4900 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Related Manuals for Stark MONSTER CHARGER
Summary of Contents for Stark MONSTER CHARGER
- Page 1 55 AMP PORTABLE MONSTER BATTERY CHARGER 12/24V ITEM: 21523 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. SAFETY The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. - Page 3 IMPORTANT SAFETY INFORMATION To reduce risk of damage to electric plug and cord, pull by plug rather than cord when disconnecting charger. Check for damaged parts before each use. Carefully check that the product will operate properly and perform its intended function. Replace damaged or worn parts immediately. Never operate the product with a damaged part.
- Page 4 IMPORTANT SAFETY INFORMATION If necessary to remove battery from vehicle to charge, always remove grounded terminal from battery first. Make sure all accessories in the vehicle are off, so as not to cause an arc. Be sure area around battery is well ventilated while battery is being charged. Gas can be forcefully blown away by using a piece of cardboard or other non-metallic material as a fan.
-
Page 5: Product Information
PRODUCT INFORMATION FEATURES: 110V 60Hz Battery Charger For Lead-Acid Batteries AC Input: 12V = 1400W , 24V= 2600W Charger Voltage: 12V = 56A , 24V = 55A Max Charger Current: 90A , Battery Capacities 60-600Ah Starter Current: 600A Built In Fan for Cooling With Automatic Thermistor Protection Adjustable Timer For Quick Charge, Set &... -
Page 6: Operation
OPERATION PRINCIPLE OPERATION 1. Before charging, clear the storage battery and carefully check its initial voltage. 2. When charging, the current lies on the type of storage battery which is generally about 10% of the max current of the battery. TIME: Upon the type of storage battery, the formula is: Charging Type = Battery Current / Charging Current Additionally, when the charging times go by, the charging current will drop so the actual charging time... - Page 7 OPERATION CHARGING A BATTERY OUTSIDE OF THE VEHICLE 1. Check polarity of battery posts. POSITIVE (POS, P,+) battery post usually has a larger diameter than NEGATIVE (NEG, N,–) post. 2. Attach a cable (not provided) to the NEGATIVE (NEG, N, –) battery post. This cable must be a minimum of 24”...
- Page 8 OPERATION CHARGER CARE & MAINTENANCE 1. Clean the clamps after each use. Wipe off any battery fluid that may have come in contact with the clamps to prevent corrosion. Battery fluid may be neutralized with a solution of water and baking soda. 2.
-
Page 9: Troubleshooting
TROUBLESHOOTING PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
