INTRODUCTION ............5 USER TIPS ..............5 SAFETY ..............5 PARTS LISTING............6 AIR CONDITIONER ACCESSORIES ......7 SETUP & INSTALLATION ...........8 CHILLZONE OPERATION ...........9 BATTERY USE & OPERATION ........11 SOLAR PANEL USE & OPERATION ......13 TECHNICAL SPECIFICATIONS .........13 CARE & MAINTENANCE ...........14 WARRANTY INFORMATION ........14... - Page 4 PLEASE READ THIS ENTIRE MANUAL BEFORE ATTEMPTING TO USE THIS PRODUCT. WARNING 1. Avoid dangerous environments. Do not charge this item in rain, snow or other damp environments. Do not use this item or charger in the presence of explosive atmospheres (gaseous fumes, dust or flammable materials) because sparks may be generated when charging or discharging this item, possibly causing fire.
-
Page 5: Introduction
As such, you must set up your ChillZone with the hot air outlet outside of your space in order to cool the area. This venting is critical for effective use. -
Page 6: Parts Listing
PARTS LIST OF DEVICE FEATURES: 1. DISPLAY BOARD 2. COOLING AIR OUTLET 3. HANDLE 4. CONDENSER AIR INLET 5. HOT AIR OUTLET 6. WATER OUT 7. POWER SUPPLY SOCKET 8. EVAPORATOR AIR INLET... -
Page 7: Air Conditioner Accessories
AIR CONDITIONER ACCESSORIES 24V DC HOT AIR PIPE POWER CONNECTION CABLE USB-C COLD AIR PIPE TO USB-C CONNECTION CORD WATER AIR DUCT DRAIN PIPE (LARGE) REMOVEABLE AIR DUCT RECHARGEABLE (SMALL) BATTERY ACCESSORY ADAPTER CARRY BAG... -
Page 8: Setup & Installation
SETUP & INSTALLATION 1. Set it flat - Remove your ChillZone Portable Air Conditioner from its packaging, and place it on a level surface. For safety, please make sure there are at least 20 inches of clearance around the device. If it’s been tipped, allow the unit to rest flat for 30 minutes before use... -
Page 9: Chillzone Operation
4. Set it in place - You can position the ChillZone in 3 different ways (see diagrams): a. Place the air conditioner inside the area you wish to cool and the big exhaust air duct outside. Screw the big air duct into the... - Page 10 DISPLAY: On the display panel, you should see current air temperature, air flow and operation mode. SLEEP MODE: To choose sleep mode (for air flow only without cooling), press the button for 2 seconds. You will see the snowflake icon disappear.
-
Page 11: Battery Use & Operation
Via solar panel (solar panel not included): 1. Using the included cord, plug the USB-c end into the USB-c outlet on the side of the ChillZone battery (see below). Plug the other end into the connector on the solar panel. - Page 12 ChillZone with the 4 latches on the top of the battery. 3. Press down on the top of the ChillZone to lock the bars into the latches. Lift up on the handle to see if all 4 clicked in. If you missed 2, you might need to scoot the ChillZone forward or backward a bit to align the other 2 latches.
-
Page 13: Solar Panel Use & Operation
When powered with the battery, all operation instructions remain the same. Please note: • You must POWER ON the battery before it can run the ChillZone. • Average run time using the battery is about 4 hours. • Run time on colder settings/higher fan is shorter than warmer settings/slower fan. -
Page 14: Care & Maintenance
• DISPOSAL - it is illegal to vent refrigerant during disposal. If you need to throw away your ChillZone, please take the appliance to the appropriate landfill or small appliance recycling in your area for correct disposal. -
Page 15: Contact Information
EXCLUSIONS FOR DOCUMENTATION Unless specifically agreed to in writing, 4Patriots and the 4Patriots ChillZone: 1. Make no warranty as to the accuracy, sufficiency or suitability of any technical or other information provided in its manuals or other documentation. 2. Assume no responsibility or liability for losses, damages, costs or expenses, whether special, direct, indirect, consequential or coincidental, which might arise out of the use of such information. - Page 16 Manufactured for: 4Patriots, LLC 2920 Berry Hill Dr., Suite 300 Nashville, TN 37204 (800) 304-4202 | 4Patriots.com Made in China V1.4...
