- Page 1 PATRIOT POWER GENERATOR 1200 USER MANUAL...
- Page 3 Before using this unit, please read ALL instructions and information in this User Manual.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION..............6 SYMBOLS & TERMS................8 FEATURES..................9 PRODUCT USE INSTRUCTIONS............11 CALCULATING RUN TIMES............14 TROUBLESHOOTING / FAQ..............14 MAINTENANCE & CLEANING............20 ENVIRONMENTAL CONSIDERATIONS..........20 TECHNICAL SPECIFICATIONS............21 WARRANTY INFORMATION............23 COMPLIANCE & REGULATIONS.............23... - Page 5 PLEASE READ THIS ENTIRE MANUAL BEFORE ATTEMPTING TO USE THIS PRODUCT. Improper use may result in fire, property damage or personal injury. DANGER: This is not a toy. The outlet produces the same power as household AC outlets and is just as dangerous for children to play with. DANGER: Do not use near open flames or flammable gas.
-
Page 6: Safety Information
SAFETY INFORMATION WARNING This section provides important safety and operating instructions. Any improper use of the generator can result in serious injury and possibly death in extreme situations. Check with manufacturer of medical devices before CAUTION powering any life-support systems or other medical devices or equipment to ensure it is compatible with the power supplied by the Patriot Power Generator. - Page 7 7. Do not short-circuit. This item will short-circuit if a metal object makes connection to the AC or DC output ports. Do not place this item near anything that may cause a short circuit, such as coins, keys or nails. A short-circuited battery may cause fire and personal injury.
-
Page 8: Symbols & Terms
SYMBOLS & TERMS IMPORTANT SYMBOLS The following symbols are used in this guide: Warnings are conditions and practices that could result in WARNING personal injury. Cautions are conditions and practices that could result in CAUTION damage to the unit or other equipment. IMPORTANT TERMS The following terms are helpful for you to know and are used in this guide: Term... -
Page 9: Features
FEATURES PATRIOT POWER GENERATOR 1200 PARTS: 1. Carry Handle with AC 8. AC Input Port Cord Storage 9. AC Outlet x2 2. LED Screen ON/OFF Button 10. USB ON/OFF Button 3. LED Screen 11. Auxiliary DC Outlet 4. Solar Input Port 12. - Page 10 FEATURES CONT. LED SCREEN Battery Meter Charging Indicator Output Input DC & Solar Output Input Battery % Full Time Until Battery Full/Empty Total Power Out Total Power In AC CHARGING CORD • Length: 1.5 Meters • 110V/1.5A Adapter to 24V/4A DC Output...
-
Page 11: Product Use Instructions
PRODUCT USE INSTRUCTIONS GETTING STARTED Thank you for your purchase of the Patriot Power Generator 1200. The 1200- watt pure sine wave AC inverter output in this unit makes it compatible for use with many of today’s high-tech electronic devices. It also allows appliance motors to operate more efficiently and at cooler temperatures. - Page 12 Please note this energy output is an estimation, and actual output may vary from displayed values. The Patriot Power Generator 1200 will turn off automatically after 1 hour of no draw from the AC outlets. You may need to press a button to awaken the unit...
- Page 13 2. Press the USB Outputs button. 3. Your output wattage will show in the lower right corner of the LED screen. The Patriot Power Generator 1200 will turn off automatically after 12 hours of no draw from the USB outlets. LCD SCREEN •...
-
Page 14: Calculating Run Times
CALCULATING RUN TIMES The Patriot Power Generator 1200 holds 1030 watt hours. To find out how long you will be able to power your device, you will first need to know how much power that device draws. You can find this by looking at the specifications on a sticker on the device, the device’s user guide, or by plugging it into your... - Page 15 1. My Patriot Power Generator won’t turn on • Plug in an item and turn on the outlet to activate the generator. You can turn on the LCD screen to assure that your generator has enough power stored to turn on. •...
- Page 16 4. How do I know when my Patriot Power Generator is fully discharged? • The Patriot Power Generator has an LCD display that will show the wattage being used and the battery status bar. These will let you know the status of your battery while charging or discharging.
- Page 17 • Please make sure to turn the screen on to check if the unit is charging. • The optimum position of the solar panel is slightly angled to the south (if living in the Northern Hemisphere) at noon in an open area. The panel will produce less power before and after noon and at angles that are not axially tangent to the relative path of the sun.
- Page 18 • To extend the battery life, connect the Patriot Power Generator to solar panels during use. 10. The AC 120V outlet turns off when I use two electronic devices at the same time. • The Patriot Power Generator has a number of safety features built in to prevent injury to you or damage the unit.
- Page 19 14. My LCD screen turns off and I'm not sure how to turn it back on • The screen dims after 1 minute with no activity. • To turn the screen back on, press the LCD button to the left of the screen.
-
Page 20: Maintenance & Cleaning
MAINTENANCE & CLEANING Be sure to use and charge your Patriot Power Generator at least every six months to maintain the battery capacity. It is recommended that during this biannual charge that you first use the battery to run or charge a smaller item (like your phone), using the battery to empty or nearly empty and then charging all the way to full. -
Page 21: Technical Specifications
TECHNICAL SPECIFICATIONS UNIT BODY Weight: 28.2 lbs. Dimensions: 13.39" x 8.66" x 10.35" Material: PC, ABS and SPCC Plastics *Cooled By Side-Mounted Fans Module Spec Target Battery Capacity (Wh) 1030Wh Lithium Iron Battery Chemistry Phosphate Nominal Voltage 44.8V Battery Life Cycles (down to 80% 4000 DOD) Charge Retention... - Page 22 Module Spec Target Solar Input 15A 12-59 (800W MAX) DC-Charge Rate 15A 12-59 (800W MAX) Solar/DC Input Port Anderson Compatible DC Charge Time AC Charge Rate 8.3A (1000W MAX) INPUT Charger AC Charge Time -1.5H (Approx. Hours) Standard Computer Power AC Input Port Port (C13) Combined Watts In (Bi-...
-
Page 23: Warranty Information
WARRANTY INFORMATION This Patriot Power Generator is backed by our 4Patriots 1-year manufacturer warranty. For questions about our warranty, please contact customer service. COMPLIANCE & REGULATIONS FCC Statement: This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. -
Page 24: Contact Information
NOTICE OF COPYRIGHT Patriot Power Generator 1200 User Manual. Copyright © 2024 4Patriots, LLC. All Rights Reserved. EXCLUSIONS FOR DOCUMENTATION... - Page 25 NOTES:...
- Page 28 Manufactured for: 4Patriots, LLC 2420 Berry Hill Dr., Suite 300 Nashville, TN 37204 (800) 304-4202 | 4Patriots.com Made in China V1.1...
