PATRIOT POWER
BATTERY CONNECTOR
Congratulations! Your Patriot Power Battery Connector is a battery
inverter that connects your Patriot Power Battery 1300 to a wide
variety of appliances, devices, and medical equipment when the
power goes out, for maximum peace of mind. It will even connect the
Patriot Power Battery 1300 to your Patriot Power Generator 2000X
for maximum backup power output.
The Patriot Power Battery Connector uses the latest in battery
inverter technology. While using this product should be safe when
following directions. Please exercise caution and read all warnings
carefully.
READ THIS MANUAL
BEFORE OPERATION
1
Advertisement
Summary of Contents for 4Patriots PATRIOT POWER
- Page 1 BATTERY CONNECTOR Congratulations! Your Patriot Power Battery Connector is a battery inverter that connects your Patriot Power Battery 1300 to a wide variety of appliances, devices, and medical equipment when the power goes out, for maximum peace of mind. It will even connect the Patriot Power Battery 1300 to your Patriot Power Generator 2000X for maximum backup power output.
- Page 2 WARNINGS 1. Do not disassemble, resassemble, or repair the battery. Incorrect reassembly may cause combustion or electric shock. 2. If the battery connector is damaged, please contact Customer Service at 1-800-304-4202. 3. Do not short-circuit the battery connector, set it near heat or water sources, or allow it to become wet.
- Page 3 BATTERY CONNECTOR INTERFACE Power Button Expansion Battery Battery Charge Indicator Port & Cover Battery Attachement Knob AC Plug (20V) Battery DC Charging Attachment Port Knob EXPANSION PACK PARTS Patriot Power Battery Connector Patriot Power Expansion Battery 1300 Cable Patriot Power Generator 2000X...
- Page 4 This combination is an industry first and allows your Patriot Power Expansion Battery to perform triple duty... • as a standalone lithium battery, • as an AC power supply when combined with the Patriot Power Battery Connector, and • as extra power capacity for your generator when the Battery Connector and generator are connected with the provided cable.
- Page 5 Then the cable will be inserted into the cable plug on the Battery Connector (under the dust cover that has the 4Patriots logo on it). 7. To insert the cable, pull up on the dust cover which will expose the receptacle for the cable.
- Page 6 • When not in use, please store the Battery Connector, cable, and AC adapter plug in the provided case. • The cable that goes from the Patriot Power Generator 2000X to the Battery Connector is supposed to fit very snugly due to the amount of energy being passed through.
-
Page 7: Features & Specs
INVERTER: • 500 watts OUTLETS: • 2 AC sockets (120 VAC, 4.2A) • 1-8 Pin port to connect to Patriot Power Generator (input/output) INPUTS: • 1 DC barrel socket, 12V 150W max • Used to charge expansion battery ERROR CODES... - Page 8 Manufactured for: 4Patriots, LLC 2920 Berry Hill Dr., Suite 300 Nashville, TN 37204 (800) 304-4202 | 4Patriots.com Made in China V1.1...
