- Page 1 LED-FW10 Video Control Ser ver V1.0 User Manual △ Before using this LED video processor, please read this instruction manual carefully and keep it for future reference. Document Version：V1.0 Document Release Date：2023/11/5 LED-FW10...
-
Page 2: Revision History
Statement Without the written permission of the company, no unit or individual may copy, transcribe or translate part or all of the contents of this manual.This manual shall not be distributed in any form or by any means (electronic,mechanical, photocopying, recording or other possible means) for commercial or commercial purposes. -
Page 3: Table Of Contents
Directory Introduction ..........................1 Trademark Credit ............................1 About the software ............................. 1 Product Features ............................2 Safety Notice ..............................3 Features ............................4 Overview ................................. 4 Technical Specifications ..........................7 Use Menu ............................9 How to use the buttons ..........................9 MENU Area： ............................9 LAYER Area：... -
Page 4: Introduction
Introduction Thank you for purchasing our company's LED all-in-one video controller. Hope you can enjoy the excellent performance of this product. The design of this LED all-in-one video controller complies with international and industry standards, but improper operation may still cause personal injury and property damage. -
Page 5: Product Features
Product Features Standard multiple input interfaces： HDMI2.0×1、 DP1.1×1、 DVI×2、 3G-SDI ×1、Audio×1 Support HDMI2.0 loop out Support arbitrary image scaling Support quick light-up screen, no need computer software connection Support single port 4K * 2K/60Hz (HDMI2.0/12G SDI) input ... -
Page 6: Safety Notice
Safety Notice The input voltage range of the power supply of this product is 100~240V, 50/60Hz, please use the correct power supply. When you want to connect or unplug any signal cable or control cable, please make sure that all power cables have been unplugged beforehand. When you want to add hardware devices to this product or remove hardware devices from this product, please make sure that all signal cables and power cables have been unplugged in advance. -
Page 7: Features
Features Overview The video control server is a video controller created by Magnimage, which integrates video processing, splicing, switching and LED screen sending card functions. This series integrates various professional input interfaces, supports up to 4K×2K/60Hz, LED-FW10 single machine can load 8.80 million pixels, and support 10 Gigabit Ethernet ports for output. -
Page 10: Technical Specifications
Video Input Port DVI1-DVI2 2 x DVI input ports DP1.1 1 x DP input ports HDMI2.0 1 x HDMI2.0 input ports 3G SDI 1 x 3G SDI input ports Audio（in） 1 x Audio input ports Model Video Output Port 10port ， single port load 0.98 million pixels, LED-FW10-B Gigabit Ethernet Port whole unit load 8.80 million pixels... - Page 11 Output Information Port Quantity Of Resolution Specification Single port load 0.98 million pixels, whole unit load 8.80 Gigabit million pixels,a single machine can carry maximum width Ethernet Port 8192 pixels and maximum height 3840 pixels HDMI2.0 LOOP Can loop out HDMI2.0 input source The HDMI 2.0 interface comes with an audio channel that Audio OUT can directly output audio signals through the machine...
-
Page 12: Use Menu
Use Menu Using the product menu system can easily and intuitively set the machine to meet the user's use requirements The all-in-one video controller uses a full-color LCD display to display the entire user menu. When the user does not operate or the operation times out, the default state will be displayed on the LCD screen. -
Page 13: Layer Area
Browsing Mode Setting Mode ↖ confirm button, short press knob, can switch between the two modes ↗ Under browse mode, Anticlockwise rotate the "knob", the cursor moves up or left; rotate the "knob" clockwise, the cursor moves down or right. When moving the cursor to the item to be adjusted, press the "knob"... -
Page 14: Function Area
FUNCTION Area： This area contains 4 buttons：PRESET、SIZE、BRIGHT、LOCK。 Button Default operation of button system PREST Quickly call up the preset template calling interface SIZE Call out the adjust layer size menu interface BRIGHT Shortcut button for adjusting the brightness of the large screen LOCK Button lock Introduction to Default State... - Page 15 The information in the above figure is explained as follows： Symbol Description Resolution Current output resolution Brightness Current screen brightness Machine IP address OPT If the icon is green, the cable communication is normal. If the icon is gray, the cable is not connected or the communication is abnormal The serial number of the network port.
-
Page 16: Main Menu Introduction
Main Menu Introduction In the main menu, the user uses the “ ”buttons and the knob to select and adjust each item. The operation mode is as follows： Operate Introduction In the default state, press the rotary knob or slide the "magnimage" in Open Main Menu the upper left corner Select each Item... -
Page 17: Screen
There are 4 menu items in the main menu. Use the knob to select the 4 menu titles listed above. After selecting, press the knob to enter the selected item, and press the " " button to return to the previous menu SCREEN Quick Configuration：... - Page 18 Manual Configuration： CabineMark： Set the corresponding routing method, box width and height quantity, Manual and horizontal/vertical position value of the network cable offset for Configuration each network port When opening the box marking, the large screen will display the network CabinetMark port number and receiving card number of each box, allowing for a very intuitive connection diagram...
- Page 19 RxCardReset： Test Patten1~10 RxCardReset Reset receiving card parameters Output Resolution Customize the output resolution of the machine Test Patten Default to off state, test screen 1-10 options...
- Page 20 Local Backup： Muilti Machine Backup：...
- Page 21 Single machine can specify any network port for Local Backup backup. Ethport When multiple machines are in the same LAN, Backup Multi-Machine you can choose another machine as the backup Backup or primary machine, and setting the IP address of the other machine can achieve fast backup The default state is off.
- Page 22 machine LocalParam USB flash drive for saving single box parameter SaveUdisk files stored in the machine Obtain all single box parameter files stored in Local Files the machine in DTR format LinUpFile： Save the display screen connection cable file to UDiskLineUpSave the USB flash drive UDiskLineUpSavet...
-
Page 23: Layer
LAYER Layer： Crop：... - Page 24 Picture： Size/Pos Can change the horizontal position, vertical position, horizontal width, vertical ition position of each layer Each layer can be independently Cropped without affecting each other, and this Crop is the signal source Crop of the layer Horizontal The maximum value is the difference between "width of Position horizontal reference"...
-
Page 25: Input
INPUT Input： RGB Range： EDID Setting Optionally set EDID for a certain input H_Active Horizontal width V_Active Vertical height Refresh Rate Advanced Adjust BandWidth RGB Range Can modify the color range of DVI, HDMI, and DP inputs, divided into... -
Page 26: Misc
"automatic", "0-255", and "16-235" After setting up the EDID, for different computers and graphics card outputs, it may be necessary to restart the computer or unplug the signal cable. In the display settings menu of the computer, select the corresponding resolution. - Page 27 Enter the save preset interface and select and press the knob button to Save Preset save the preset by rotating the knob Enter the loading preset interface and select and press the knob button Load Preset to load the preset by rotating the knob Clear all user saved presets by rotating the knob to select and pressing Clear All Preset the knob button to clear the preset...
- Page 28 COMM.： USB Setting： Out Freeze： IP Setting Can change the IP address of this machine Switch this mode and use square USB COMM communication COMM USB Setting Switch this mode to upgrade the machine UDisk Files using a flat USB port Out Freeze Freeze the current device output screen...
- Page 29 English/语言： Optical Fiber Output： 语言/Language Can switch between English or Simplified Chinese The default is' off ', and when multiple devices are spliced, the SyncLock synchronization lock needs to be turned on to synchronize between Settings multiple devices...
- Page 30 Time/Task Management： Date And Set the time and date of the machine Time 10 time tasks can be set, which can be edited separately. Select a trigger time, and then select the trigger time point screen brightness or load preset. Task operations include "single time", "daily", and "cycle".
- Page 31 Optical Fiber Output： Work Mode： Supports two optical port working modes: "optical port hot backup" Optical and "optical port copy output", with the default being optical port hot Fiber Output backup mode. Supports "two in one" and "photoelectric" working modes, and the Working Mode default is "two in one"...
-
Page 32: Warranty
Factory Reset Restore the machine factory settings Check the ARM, FPGA, CPLD versions and current operating Version Information temperature of the machine Warranty Machine Warranty Period 24 months from the date of the user's purchase invoice； If the user's purchase invoice is lost, the 60th day after the production ...
