Summary of Contents for Hypontech HM 2000D Series
- Page 1 USER MANUAL V1.00 HM 2000D SERIES...
-
Page 2: Table Of Contents
CATALOGUE 1 SAFETY AND WARNINGS Safety Instructions Symbols in the document 2 General Introduction Product Introduction Appearance and Interface Introduction Connected to HYPON.CLOUD via a router or WLAN network 3 Installation Packing List Installing the product Positioning 3.3.1 Installing Antenna Storage 4 CONNECTING THE PRODUCT 4.1 Connection Area... -
Page 3: Safety And Warnings
1- SAFETY AND WARNINGS 1.1 Safety Instructions HM-2000D, produced by Suzhou Hypontech Co,. Ltd., is designed, tested and manufactured strictly aligned with relative safety regulation. As an electric device, installation and maintenance shall follow instructions stated in this document. Incorrect operation may cause physical or financial damage to the operator or third parties. -
Page 4: General Introduction
HM-2000D can collect data from inverters, smart meters and other Dataloggers, therefore, to actively control power output, data configuration and firmware update remotely via HYPON.CLOUD. 2.2 Appearance and Interface Introduction Width 115mm Height 40.5mm Length 180mm HYPONTECH HM-2000D USER MANUAL... - Page 5 2- General Introduction Interface Signal terminal Ripple terminal WLAN HYPONTECH HM-2000D USER MANUAL...
-
Page 6: Connected To Hypon.cloud Via A Router Or Wlan Network
No Inverter access SERVER Glowing light Cloud server connected Cloud server not connected Glowing light Ethernet connected Ethernet disconnected WLAN Glowing light WLAN connected WLAN disconnected 2.3 Connected to HYPON.CLOUD via a router or WLAN network HYPONTECH HM-2000D USER MANUAL... -
Page 7: Installation
Terminal Accessories Manual 3.2 Installing the product 3.3 Positioning 1. Protection level of HM-2000D is IP20, it MUST be mounted indoor. 2. Weight and dimension of HM-2000D must be considered to choose installation method and position. HYPONTECH HM-2000D USER MANUAL... -
Page 8: Mounting On Wall
· Remove buckle and foot pad. · Mark 2 drill holes on the wall and align them horizontally. Distance between the center of marks should be 70mm. Drill the holes using a 6mm bit to 30mm depth. HYPONTECH HM-2000D USER MANUAL... -
Page 9: Mounting On Din Rail
Hang the product onto the mounting screws. Ensure the product is stably attached. Mounting on DIN Rail: · Hook the HM-2000D into the guide rail from above and press down the lower part of the HM-2000D until it snaps into place. HYPONTECH HM-2000D USER MANUAL... -
Page 10: Installing Antenna
· The storage carrier should be suitable for the weight of the HM-2000D. · Ambient temperature: -30°C to +80°C; relative humidity: 5-95%, no condensation. · Unpack and check the HM-2000D in powered on state if it has been stored more than half a year. HYPONTECH HM-2000D USER MANUAL... -
Page 11: Connecting The Product
Port for connecting Inverter COM4 Port for connecting Smart Meter COM5 Port for connecting charging pile, Anemoscope Reserved COM6 RESET Reset Button Port for connecting Ethernet cable Signal terminal Description DO1~4 Relay output interface, specification 250Vac/5A, 30Vdc/5A HYPONTECH HM-2000D USER MANUAL... -
Page 12: Connect To Inverter
5. Observe the polarity assignment of A and B. 6. Plug the RS485 terminal block into COM1/2/3 port on the product. · Please use standard RS485 shielded twisted pair conductors · Connect to COM1/2/3 of HM-2000D HYPONTECH HM-2000D USER MANUAL... -
Page 13: Connect To More Than One Inverter
4.3 Connect to Smart Meter Signal terminal Description COM4 Port for connecting Smart Meter · Please use standard RS485 shielded twisted pair conductors · Only connect to COM4 on HM-2000D · Refer to 4.2.1 for further instruction HYPONTECH HM-2000D USER MANUAL... -
Page 14: Connect To Dred
2. Connect the other end of the network cable to a network source, e.g. a router, access point device. DHCP service MUST be supported by the router. DHCP MUST be activated. HYPONTECH HM-2000D USER MANUAL... -
Page 15: Cable Routing Requirements
5. The communication cables should be routed as closely to the ground surface or supports (-such as support beam, steel channel, or metal rail) as possible. Parallel cable length (m) Min. distance (m) HYPONTECH HM-2000D USER MANUAL... -
Page 16: Hm-2000D Connect To Wlan
HM-2000D successfully. 2. Open the browser, enter 192.168.4.1/local_web in the address box, and view the local information. 3. Click scan AP to search for available WLAN signals nearby. HYPONTECH HM-2000D USER MANUAL... - Page 17 5- Configuration 4. Enter the WLAN password and click Connect. 5. Wait until the WLAN is successfully connected to the router. HYPONTECH HM-2000D USER MANUAL...
-
Page 18: Micro-Inverter Monitoring&Control
HHT energy storage machine, the system is based on the real-time power of each phase of the meter. Calculate the difference with the limit value of the feednet and adjust the output of the inverter. HYPONTECH HM-2000D USER MANUAL... -
Page 19: Energy Management Model
1. Self-consumption Mode Power Load Acquire electricity Self supply Self electricity Self supply PV＜Load PV＞Load PV＜Load HYPONTECH HM-2000D USER MANUAL... - Page 20 · When the power grid is powered off, if the PV power is less than the load power, the PV+ battery supplies power to the load HYPONTECH HM-2000D USER MANUAL...
- Page 21 · PV Power < When the load consumes power, the PV+ battery supplies power to the load · At night PV=0, the battery supplies power to the load HYPONTECH HM-2000D USER MANUAL...
- Page 22 · At night, PV=0, the battery supplies power to the load, and the power is reduced to Backup Limited SOC before switching to the power grid to supply power to the load HYPONTECH HM-2000D USER MANUAL...
-
Page 23: Technical Parameter
802.11 n(2.4 GHz), up to 150Mbps Other COMMUNICATION Ethernet 10/100 Mbit/s RS485 RS485 Communication Range / m 1000 Ethernet Communication Range / m HYPON.CLOUD Compatibility Features 16*3=48 Max. Number of Inverters Active Power Limit Power Adjustment Firmware Update HYPONTECH HM-2000D USER MANUAL... - Page 24 Max. operating altitude / m Relative Humidity 10% ~ 90% IP20 Protection class EU declaration of conformity Suzhou Hypontech Co.,Ltd. hereby declares that the communication device sold in theEuropean market meets the requirements of the following directives: · Radio Equipment Directive 2014/53/EU (RED) ·...
- Page 25 Suzhou Hypontech Co., Ltd. - HQ Offices Suzhou Hefeng Science And Technology Innovation Park No.2, Taishan Road, Suzhou China · 215129 T: +86 512 807 12199 E: info@hypon.com W: www.hypon.com Suzhou Hypontech Co., Ltd. - Manufacturing No.588 Wutaishan Road, SND, Suzhou 215000, China Hypontech Deutschland GmbH –...
