Summary of Contents for Ad Notam MWS
- Page 1 MONITOR-ON-WALL MOUNTING SYSTEM (MWS) MWS Mounting Set.indd 1 21.09.2020 12:08:39...
- Page 2 © 2020 ad notam AG, all rights reserved. Use or reproduction of this manual in parts or entirely without the authorization of ad notam is prohibited. Specifications of the ad notam products are subject to unannounced changes; this manual may thus not reflect the current technical status.
- Page 3 10. All maintenance and/or service tasks, as well as repairs may only be carried out by trained customer service personnel. 11. Packaging and packaging aids are recyclable and should principally be recycled. Packaging materials such as foil bag and cover foil must be kept away from children. MWS Mounting Set.indd 3 21.09.2020 12:08:41...
- Page 4 MWS-30 Description Illustration Amount Mounting Brackets (Art20002257) Rounded Head Screws M4 x 12 Spring Washer 4.1 MWS-50 Description Illustration Amount Mounting Brackets (Art20002259) Hexagon Bolt M6 x 16 Lock Washer 6.4 Spring Washer 6.1 MWS Mounting Set.indd 4 21.09.2020 12:08:42...
- Page 5 MWS-60 V2 HO (Horizontal & In-Wall) Description Illustration Amount Mounting Brackets (Art20011471) Hexagon Bolt M6 x 16 Lock Washer 6.4 Spring Washer 6.1 MWS-60 V2 VO (Vertical & In-Wall) Description Illustration Amount Mounting Brackets (Art20011012) Hexagon Bolt M6 x 16 Lock Washer 6.4...
- Page 6 MWS-70 V2 HO (Horizontal & On-Wall) Description Illustration Amount Mounting Brackets (Art20011473) Hexagon Bolt M6 x 16 Lock Washer 6.4 Spring Washer 6.1 MWS-70 V2 VO (Vertical & On-Wall) Description Illustration Amount Mounting Brackets (Art20010953) Hexagon Bolt M6 x 16 Lock Washer 6.4...
- Page 7 1. There are numerous types of wall and structures, that‘s why we can not provide the fittings, screws and anchors for your wall. First determine the type of wall to which you want to attach the product in order to buy the appropriate fittings, screws and anchors. MWS Mounting Set.indd 7 21.09.2020 12:08:45...
- Page 8 2. Affix the two top MWS mounting brackets at the injection nuts on the monitor casing and measure the distance “d” between the middle of both mounting bracket holes - you can also refer to table 1 below. For 65 inch screen size special MWS mounting brackets are to be used a shown in Fig.
- Page 9 4. Drill two holes at the marks, mount the dowels and screw the lower mounting brackets securely to the wall. Monitor 5. Place the ad notam monitor system on the lower brackets so that the injection nuts on the bottom are aligned with the holes in the mounting brackets and mark the drill holes for the upper mounting brackets accordingly on the wall.
- Page 10 When using our products, you agree to the terms of the agreement. Contact information. Please address all communication regarding the agreement to in writing: ad notam AG – Obere Giesswiesen 11-13, 78247 Hilzingen, Germany MWS Mounting Set.indd 10 21.09.2020 12:08:48...
- Page 11 For further questions or troubleshooting, please visit the support section on our website www.ad-notam. com and read the available FAQs. If this does not help you, please send us an email or contact the service center indicated on the website. MWS Mounting Set.indd 11 21.09.2020 12:08:48...
- Page 12 Aktiengesellschaft Obere Giesswiesen 11-13 78247 Hilzingen Germany www.ad-notam.com info@ad-notam.com MWS Mounting Set.indd 12 21.09.2020 12:08:48...
