- Page 1 MODEL# NBD01LM6500RGB USE AND CARE GUIDE LED Flood Light THANK YOU Thank you for choosing Orein! We hope you will continue to choose Orein in the future. Visit us online at www.orein-usa.com to see our full line of lighting products.
- Page 2 WARNING: THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED. Carefully read and understand the information given in this manual before beginning the assembly and installation. Failure to do so could lead to electric shock, fire or other injuries which could be hazardous or even fatal.
- Page 3 ve (5) Volts Frequency Watts Current Sensor Dimming Lumen Output (Hz) 120-277 50/60 max0.51 6500 5000K Dusk-to-dawn sensor RGBW WARNING: Shut off power at the circuit breaker or fuse panel before removing the old xture. NOTE: Keep your receipt and these instructions for proof of purchase. TOOLS REQUIRED Wrench Size: M8-0.511"...
-
Page 4: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Light xture RGB switch & light sensor Trunnion mount M8 Screw HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Wire nut M10 Screw Set M10 Allen Wrench M8 Allen Wrench M12 Gasket M4*16 Screw Dry wall anchor... -
Page 5: Surface Mounting
SURFACE MOUNTING NOTE: DISCONNECT POWER BEFORE INSTALLATION. 11(0.433'') 60(2.36'') R5.5(0.216'') Ø15(0.59'') 6(0.236'') 17(0.669'') Drill two holes according to suggested size and distance. Secure the light onto the surface and adjust it to the WARNING: Please pay special ideal angle by using M8 Allen Wrench (DD). attention to wiring and waterproo ng If applicable, plug all unused holes and seal threads issues during the installation process. -
Page 6: Pole Mounting
POLE MOUNTING NOTE: DISCONNECT POWER BEFORE INSTALLATION. N(White) L(Black) GND(Green) Fix the screw (BB) on the fixture mounting surface with the M10 Allen Wrench(CC), and connect the AC wire by using wire nuts (AA). Set the desired tilt angle with the M8 Allen Wrench (DD), then secure and tighten the screws. If applicable, plug all unused holes and seal threads with silicone. -
Page 7: Operation
OPERATION NOTE: The remote wall cradle(HH) can be mounted on the wall in a desired position and attached to the wall using the included screws (FF) and dry wall Remote control cradle 30(1.18'') anchors (GG). mounting hole distance Icon Button Name Action Notes The light will be the same... - Page 8 Light Distribution 9473.8 , 4361.5 lx 5.2ft 2.5ft. 2924.0 , 1346.1 lx 9.3ft 4.5ft. 12.4ft 1644.8 , 757.2 lx 6.0ft. Max , Ave Beam angle of C0 plane 91.89 OPERATION (CONTINUED) WARNING: During installation, the photocell must not be oriented towards the oor to prevent it from failing to operate due to the...
