BACnet Gateway /
Data Management Server
User & installation manual
VCTRL02P-1 / VCTRL09P-1
• Thank you for purchasing this Lennox Product.
• Before operating this unit, please read this manual carefully and retain it for future reference.
• For more information on using the product, download the user manual from the product and refer to it.
DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 1
DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 1
2024-09-20 오후 1:40:46
2024-09-20 오후 1:40:46

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lennox VCTRL02P-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung Lennox VCTRL02P-1

Summary of Contents for Samsung Lennox VCTRL02P-1

  • Page 1 BACnet Gateway / Data Management Server User & installation manual VCTRL02P-1 / VCTRL09P-1 • Thank you for purchasing this Lennox Product. • Before operating this unit, please read this manual carefully and retain it for future reference. • For more information on using the product, download the user manual from the product and refer to it. DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 1 DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 1 2024-09-20 오후...

  • Page 2: Safety Precautions

    Safety Precautions California Proposition 65 Warning (US) WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Cautions for operation Before using the DMS, BACnet Gateway, read carefully these instructions. After reading the instructions, keep this user's manual in a handy and safe place. If a user is changed, you must hand over the manuals.

  • Page 3: Table Of Contents

    Contents ...... afety recautionS etting the oMPuter nVironMent DMS ... DMS......efore nStalling the etting the ................ cceSSorieS racking ......iewing the artS etting the ower iStriBution ............roDuct iMenSionS PPenDix ........ySteM rchitecture ateway Setting .......

  • Page 4: Before Installing The Dms

    Before Installing the DMS Checks before installation DMS IP  Basically, only Private IP can be set to IP address. To use Public IP, you must set Enable public IP as ‘Enable’ from the menu [System Settings]  [System environment setting]. - Private IP range : 10.0.0.0 ~ 10.255.255.255, 172.16.0.0 ~ 172.31.255.255, 192.168.0.0 ~ 192.168.255.255 - Public IP range: IP except for Private IP range and 127.0.0.1(localhost)

  • Page 5: Accessories

    Accessories Make sure you have each item. Supplied items may vary depending on your country or service provider. Item Adapter Power cable M4 x16 Screw Quantity Shape User & Installation Cable tie manual CAUTION The DMS must be installed by a trained installer. ...

  • Page 6: Iewing The P Arts

    Viewing the Parts Main Parts DMS Exterior DMS Exterior LCD Display Shows current time and IP address. Various messages will be displayed depending on button input. LCD operation button There are 4 buttons(Menu, ▼(Down), ▲(Up), Set) and you can access menu and move, check the menu.
  • Page 7 DMS Cable Connection Part DMS Cable Connection Part RS485 Communication Terminal DI Terminal1 DI Terminal2 DO Terminal3 DO Terminal4 Reserved Cable tie groove Power Terminal SD Card Socket Ethernet Terminal Reset Button Name Description DI Terminal1 Digital Input connection terminal, Channel1~Channel5 DI Terminal2 Digital Input connection terminal, Channel6~Channel10 DO Terminal3...

  • Page 8: Product Dimensions

    Viewing the Parts (Continued) Main Parts DMS Interior DMS Interior Display Board 20-pin Cable Main Board 40-pin Cable Sub Board Note Note  If you need external circuit configuration, consult with the manufacturer.  Refer to page 17 for DI contact input operation. Product Dimensions [Unit : inch (mm)] 2.55 (64.80)

  • Page 9: System Architecture

    System Architecture Web Client TCP/IP Internet Centralized PM 05:45 Touch Controller Outdoor Unit Power Meter Max 256 Indoor units (VRF Series) Connecting outdoor unit and DMS.  - You can control up to 80 outdoor units and 256 indoor units by using DMS. ...

  • Page 10: Compatible Devices

    Compatible Devices Devices Model Note VRF HR, VRF HP, Mini-VRF, VRF, Mini-Split indoor/outdoor units Indoor Unit Water-Cooled VRF only outdoor product groups that support NASA Outdoor Unit units and indoor units that can be communication connected to these outdoor units Centralized Touch VCTRL01P-1 Controller...
  • Page 11 Maximum Devices Attachable Devices Max. Note Tracking error occurs if exceeded The maximum number of indoor units Indoor Unit (including MSB) that can be connected to each DMS communication channel is 128. Must not exceed 15 units per each RS485 Centralized Touch Controller communication terminal Must not exceed 16 units per each RS485...

  • Page 12: Installing The Xdms

    Installing the DMS Separate the installation plate on the rear side of DMS. Fix the installation plate on the wall using 4 screws. Hang the DMS on the groove which is on the top of the installation plate. Installation plate Fix the installation plate and DMS using 2 screws.

  • Page 13: Connecting Outdoor Unit

    Connecting Outdoor Unit Unfasten the 2 screws on the bottom of the DMS front cover. Hold the bottom 2 sides of the DMS and push downwards to slide open the cover. Connect the adapter to the power terminal.  Arrange the adapter as the right figure. Adapter Separate 1 terminal block from 5 terminal blocks that are attached to RS485 communication terminal of...
  • Page 14 Installing the DMS (Continued) Connecting PIM Unfasten the 2 screws on the bottom of the DMS front cover. Hold the bottom 2 sides of the DMS and push downwards to slide open the cover. Connect the adapter to the power terminal. ...
  • Page 15 Using the DI External Contact Control (Optional) Setting the External Contact Control Pattern Setting the External Contact Control Pattern You can set the system settings through contact control pattern.  Select [System Settings] menu and click [System environment setting]. Click [Edit] from ‘Select the contact control pattern’ . Select the pattern you want to check.
  • Page 16 Installing the DMS (Continued) Contact control Pattern Contact control Pattern Pattern Control ▶ No external input (Factory default setting) Pattern1 When you input contact control signal in port 1, there will be no response. ▶ Level input (Emergency stop) 1. If the contact control signal is changed to ON, emergency stop status and all the indoor units are given ‘Stop’...
  • Page 17 DI(Digital Input) Circuitry according to Contact control Pattern DI(Digital Input) Circuitry according to Contact control Pattern Pattern 2 (May be used for connection with a fire sensor)  Emergency Stop/Resume Operation No Connection Pattern 3 (External contact signal control)  Operation/Stop A/C Enable/Disable remote control Pattern 4 (Pulse signal control)

  • Page 18: Setting The Computer Environment

    Setting the Computer Environment Device related to network (Purchase separately)  Computer with a LAN Card  HUB or network cable(Cross·Direct cable) Computer web browser specification  Chrome 86 or later version Note Note  A cross cable is used when connecting to PC directly. It is produced as transmission and reception cables are crossed.
  • Page 19 Computer Settings for DMS Connection All settings of DMS will be arranged in web page which built in DMS. You should  access to DMS IP to use DMS web page. Set your computer settings as follows. DMS Factory default setting ...

  • Page 20: Setting The Dms

    Setting the DMS DMS Connection and Login From the computer desktop, double-click the Chrome icon. When the Chrome window appears, enter IP (https://192.168.0.100) in the address input field and press [ENTER].  When you access DMS for the first from the Chrome browser on your computer, a security certificate warning screen appears.
  • Page 21 CAUTION If the screen above appears again although you have registered the DMS certificate, stop accessing the solution. There is a risk that a security issue may occur. DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 21 DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 21 2024-09-20 오후 1:40:50 2024-09-20 오후 1:40:50...
  • Page 22 Setting the DMS (Continued) How to register the DMS certificate to a web browser At the top right of the Chrome browser, click the three-dot button and select ‘Settings’ to access the Settings page. B. From the Settings page, access the ‘Privacy and security’ menu and click Security. C.
  • Page 23 In the Certificates dialogue box, select the ‘Trusted Root Certification Authorities’ tab and then the ‘Import’ button. Load the saved certificate and click ‘Next’ . The DMS certificate can be downloaded from [System environment setting] DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 23 DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 23 2024-09-20 오후...
  • Page 24 Setting the DMS (Continued) Setting the DMS (Continued) Select the ‘Place all certificates in the following store’ option, set Certificate store to ‘Trusted Root Certification Authorities’ and then click ‘Next’ . Read the details, and click ‘Finish’ to complete certificate registration. DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 24 DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 24 2024-09-20 오후...
  • Page 25 When the initial screen of the DMS website appears, enter your ID and password and click [Login].  Access to some functions may be restricted, depending on the user authorisation setting configured by the administrator.  To change your user authorization setting, select System Settings > User authorization management.
  • Page 26 Setting the DMS (Continued) DMS System Environment Setting (Network settings) You can set and check information about DMS installation operation.  DMS Network Information Setting DMS Network Information Setting Select [System Settings] menu and click [System environment setting]. Click [Edit] from DMS network information window. When text boxes of IP address, subnet mask address, default gateway and DNS server are enabled, enter values for each item.
  • Page 27 Note Note  Factory setting is as follows. - IP address: 192.168.0.100 - Subnet mask address: 255.255.255.0 - Default gateway: 192.168.0.1 - DNS server: 0.0.0.0  If you enabled the function by checking ‘DHCP‘ , you can check changed network information on the external LCD display.

  • Page 28: System Time Setting

    Setting the DMS (Continued) System Time Setting System Time Setting Select [System Settings] menu and click [System environment setting]. Click [Edit] from system time setting. Enter system time(year/month/day/hour/minute/second).  You can enter only numbers.  Year: You can enter from 1980 to 2035. ...
  • Page 29 DMS Name Setting DMS Name Setting Select [System Settings] menu and click [System environment setting]. Click [Edit] from DMS name setting window. Enter name of DMS when DMS name field enabled.  You can use maximum 30 letters including English alphabets and special symbols.
  • Page 30 Setting the DMS (Continued) Error Mail Forwarding Setting Error Mail Forwarding Setting Select [System Settings] menu and click [System environment setting]. Click [Edit] from error mail forwarding setting. Set all the items as the value you want when all items fields are enabled. ...
  • Page 31 Setting Enable public IP Setting Enable public IP Select [System Settings] menu and click [System environment setting]. Click [Edit] on Enable public IP section. Select whether to use Public IP or not.  When you select ‘Enable’ , you must register the Public IP of PCs or network devices to access DMS from the PCs or network devices.

  • Page 32: System Setting Initialization

    Setting the DMS (Continued) System setting initialization 192.168.0.100 06:12:13(AM) Press [Menu], [], [] or [Set] on LCD if IP and current time are displayed on LCD screen.  Main menu screen appears.  Initialization is not possible in the screen which time information is displayed. MAIN MENU 1.IP Config Press [Menu] ...

  • Page 33: Tracking

    Tracking  What is tracking? Tracking is an operation that finds devices which are connected to DMS. Through tracking operation, devices which are connected to DMS can recognize if they are connecting to DMS. To supervise and control system air conditioner using DMS, tracking should be done first. ...
  • Page 34 Tracking (Continued) Setting Communication Mode for Each Channel Setting Communication Mode for Each Channel Select [System Settings] menu and click [Tracking]. Click [Edit] from communication mode for each channel setting.  [Edit] will change to [Cancel].  Selection buttons are enabled. However, the channels which have searched device maintains its selection button disabled.
  • Page 35 VRF Tracking VRF Tracking Select [System Settings] menu and click [Tracking]. Click [VRF Tracking]. Enter administrator’s password and then click [OK]. Tracking information window pops up. Check it and click [OK] to continue.  Execute tracking depending on the communication mode set by communication mode setting for each channel.
  • Page 36 Tracking (Continued) Tracking completed message will appear. Select Zone initialization mode you want.  No initialization: No zone information initialization will be made.  Individual initialization: Initialize zone information as individual mode. - Individual mode: Arrange by indoor unit main address on monitoring page. ...
  • Page 37 Disconnect All Devices Function Function Initialize searched device status in DMS. Monitoring and controlling of all the connected devices to DMS will be stopped when you use this function.  Connect searched device to the other channel and execute tracking. If the other device is searched in the channel you want to use, use ‘Disconnect all devices’...

  • Page 38: Renaming The Device

    Tracking (Continued) Renaming the Device Renaming the Device Select [System Settings] menu and click [Tracking]. Click [Edit] on the bottom of tracking device list.  [Edit] will change to [Cancel].  When the type of the device is displayed, NEW communication address will be shown with it.
  • Page 39 DMS DI•DO Port Setting DMS DI•DO Port Setting Select [System Settings] and then click [Tracking]. Click [Setting] which is next to DMS DI•DO of device list. Click [Edit] which is on the bottom of DMS DI•DO setting page.  [Edit] will change to [Cancel]. Edit each item when DMS DI•DO selection and input fields are activated.

  • Page 40: Pim Setting

    Tracking (Continued) PIM Setting System Settings ]  [ Tracking ] when DMS web page menu screen appears. Click [ Setting ] which is next to PIM of device list. Click [  Enter administrator’s password and then click [ OK ]. Click [ Edit ] which is on the bottom of PIM setting page.

  • Page 41: Setting The Power Distribution

    Setting the Power Distribution  When doing power distribution, set PIM channel for each indoor unit. Channel Setting by Indoor Unit Click [EHP Power Consumption Inspection]  [Channel setting by indoor unit] when DMS web page menu screen appears. Click [Edit] when the setting channel by indoor unit screen appears. Check the address and channel information of PIM which is connected to watt-hour meter.
  • Page 42 Setting the Power Distribution (Continued) Check the virtual channel information of indoor/outdoor unit.  To execute power distribution without PIM, you should set virtual channel.  When bringing indoor unit’s power from outdoor unit, set the ‘Outdoor unit virtual channel’ information only. ( ‘Outdoor unit virtual channel’...

  • Page 43: Ppendix

    Appendix IP Terminology DMS needs IP address to contact other computers.  1. Public IP Static IP 1-1. Dynamic IP 1-2. 2. Private IP Static IP 2-1. Dynamic IP 2-2. : Ordinary IP used to connect internet is called public IP. 1.
  • Page 44 Appendix (Continued) Examples of DMS Installation with DSL Local Management without External Control : Use Private IP Local Management without External Control : Use Private IP  Direct connection between DMS and computer or controller Cross cable Private IP : 192.168.0.100 ...
  • Page 45 Initial Connection Error (for Private IP) Several DMSs are Connected to the Same Network Several DMSs are Connected to the Same Network Computer DMS ① Initial IP : 192.168.0.100 Computer cannot distinguish which DMS has DMS ② 192.168.0.100 IP. Initial IP : 192.168.0.100 DMS ③...

  • Page 46: Bacnet Gateway Setting

    BACnet Gateway setting System Architecture BMS system BMS Engineering Internet Lennox BACnet Gateway Centralized PM 05:45 Centralized Touch Controller Touch Control & Schedule Settings Monitoring Controller Outdoor Unit Max 256 Indoor units (VRF Series)  Connecting outdoor units and BACnet Gateway - You can control up to 80 outdoor units and 256 indoor units using BACnet Gateway.
  • Page 47 Compatible Devices Devices Model Note Outdoor unit: VRF HR, VRF HP, You should check that your indoor Indoor Unit Mini-VRF, Water-Cooled VRF unit supports BACnet Gateway. Outdoor Unit Indoor unit: Models that can be (Refer to BACnet point list.) connected with above outdoor units Centralized Touch VCTRL01P-1...
  • Page 48 BACnet Gateway setting (Continued) Maximum Devices Attachable Maximum Devices Attachable Devices Max. Note Tracking error occurs if exceeded The maximum number of indoor units (including Indoor Unit MSB) that can be connected to each communication channel is 128. Centralized Must not exceed 15 units per each RS485 Touch communication terminal Controller...

  • Page 49: Setting The Bacnet Gateway

    Setting the BACnet Gateway BACnet Gateway Connection and Login BACnet Gateway Connection and Login Click web browser (chrome) twice on your computer. When web browser window appears, enter IP address (https://192.168.0.100) on the address bar then press [ENTER]. Enter ID and password when BACnet Gateway main web page appears, Then click [Login].
  • Page 50 BACnet Gateway setting (Continued) CAUTION If you use accounts with authorization level lower than management group or accounts  with general authorization level, you cannot access BACnet Gateway settings. If you cannot access BACnet Gateway, consult the manager.  If you login successfully, 'Control and Monitoring' screen will appear. Click [System Settings] ➔...

  • Page 51: Reading Ehp Watt-Hour Meter

    Reading EHP Watt-hour Meter Setting and checking watt-hour meter Setting and checking watt-hour meter Click [System and Checking Watt-hour meter].  You can change settings on watt-hour meter only when PIM interface module is connected. Click [Edit] from the 'Setting and checking Watt-hour meter' screen. ...

  • Page 52: Period Setting

    BACnet Gateway setting (Continued) Monthly baseline setting Monthly baseline setting Click [System and Checking Watt-hour meter]. Click [Edit] from the ‘Monthly baseline setting’ screen.  You can make changes when list box enables. Set the Monthly baseline setting.  You can select from 1 ~ 31. ...

  • Page 53: System Settings

    System Settings  You can set and check information about BACnet Gateway installation and operation. BACnet Gateway network information BACnet Gateway network information Click [System Settings]. Click [Edit] from the ‘BACnet network information’ section. When text boxes of IP, Subnet mask, Default gateway, DNS server, BBMD IP, BBMD PORT, Network No., and BACnet PORT are enabled, enter the address values for each item.
  • Page 54 BACnet Gateway setting (Continued) BACnet gateway information and initialization BACnet gateway information and initialization Click [System Settings]. You can check the basic BACnet gateway information from 'BACnet gateway information' section. Click [Edit] from the ‘BACnet gateway information’ section. If you want to initialize ‘Recipient_list’ , Check and click [Save]. When the pop-up window appears, click [OK].
  • Page 55 Device Configuration Checking device information Checking device information Click one of the Object ID from 'Object ID' column. Detail information of the selected device will be displayed in device information. Analog data of the selected device will be displayed in Analog data. ...

  • Page 56: Bacnet Protocol Implementation Conformance Statement

    BACnet Gateway setting (Continued) BACnet Protocol Implementation Conformance Statement Date: 2024. 09. 05 Vendor Name: Lennox International Inc. Product Name: BACnet Gateway Product Model Number: VCTRL02P-1 Application Software Version: 1.20 Firmware Revision: 1.35 BACnet Protocol Revision: 12 Product Description: This product supports BACnet/IP and provide functions to monitor and control status of air conditioners.
  • Page 57 SUPPORTED BIBB NAME SUPPORTED REMARKS BIBBS AE-N-A Alarm&Event-Notification-A  AE-N-I-B Alarm&Event-Notification Internal-B  AE-N-E-B Alarm&Event-Notification External-B  AE-ACK-A Alarm&Event-ACK-A  AE-ACK-B Alarm&Event-ACK-B  Alarm and AE-ASUM-A Alarm&Event-Summary-A  Event AE-ASUM-A Alarm&Event-Summary-B  Management AE-ESUM-A Alarm&Event-Enrollment Summary-A  AE-ESUM-B Alarm&Event-Enrollment Summary-B ...
  • Page 58 BACnet Gateway setting (Continued) SUPPORTED BIBB NAME SUPPORTED REMARKS BIBBS DM-R-A Restart-A  DM-R-B Restart-B  DM-LM-A List Manipulation-A  DM-LM-B List Manipulation-B  DM-OCD-A Object Creation & Deletion-A  Device and DM-OCD-B Object Creation & Deletion-B  Network DM-VT-A Virtual Terminal-A ...
  • Page 59 Data Link Layer Options:  BACnet IP, (Annex J)  BACnet IP, (Annex J), Foreign Device  ISO 8802-3, Ethernet (Clause 7)  ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)  ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s)  MS/TP Main (Clause 9), baud rate(s): ...

  • Page 60: Detail Description Of Object

    BACnet Gateway setting (Continued) Detail Description of Object Device Device Following table shows regulation of device ID and they are created automatically. DNET – Range CPP – Range INDOOR – Range Item [Digit 2] [Digit 3] [Digit 2] Centralized Touch Controller 1~40 000~015 1~40...

  • Page 61: Bacnet Point List

    BACnet Point List The BACnet point list varies depending on which [BACnet point provision type] is selected in the [System Settings] menu. There are two BACnet point provision types: (1) Basic: Reflects the default points. (2) Advanced: Reflects updated points. For details, refer to the point list below.
  • Page 62 BACnet Gateway setting (Continued) Unit Status value Instance Object Object Object Name Inactive Active Number Type Text-1 Text-2 Text-3 Text-4 Text-5 * 24 °C(°F) Discharge current temperature AC_DisCurrentTemp_xx_xxxxxx When the error occurred, send event to list of ** 25 AC Indoor Notify AC_Notify_xx_xxxxxx destination in the recipient_list.
  • Page 63 Unit Status value Instance Object Object Object Name Inactive Active Number Type Text-1 Text-2 Text-3 Text-4 Text-5 Integrated error code of both indoor ** 19 Refer to list of error code AC_Error_Code_xx_xxxxxx unit and outdoor unit * 20 False True SPI setting AC_SPI_xx_xxxxxx * 21...
  • Page 64 BACnet Gateway setting (Continued) AHU Kit [Basic] AHU Kit [Basic] Single AHU unit has following point list. Unit Status value Instance Object Object Object Name Inactive Active Number Type Text-1 Text-2 Text-3 Text-4 Text-5 Indoor Temperature AHU_RoomTemp_xx_xxxxxx °C Set temperature AV AHU_Temp_Set_xx_xxxxxx °C Setting lower temperature...
  • Page 65 AHU Kit [Advanced] AHU Kit [Advanced] Single AHU unit has following point list. Unit Status value Instance Object Object Object Name Inactive Active Number Type Text-1 Text-2 Text-3 Text-4 Text-5 Indoor Temperature AHU_RoomTemp_xx_xxxxxx °C Set temperature AV AHU_Temp_Set_xx_xxxxxx °C Setting lower temperature AV AHU_Cool_LimitTemp_xx_xxxxxx °C limit...
  • Page 66 BACnet Gateway setting (Continued) Unit Status value Instance Object Object Object Name Inactive Active Number Type Text-1 Text-2 Text-3 Text-4 Text-5 Use of cooling temperature BV AHU_Cool_Upper_Limit_set_xx_xxxxx False True upper limit Use of heating temperature BV AHU_Heat_Lower_Limit_set_xx_xxxxx False True lower limit Automatic Cooling Set AV AHU_DualSetPoint_CoolTemp_xx_xxxxx °C(°F) Temperature...
  • Page 67 VRF CHILLER [Basic, Advanced] VRF CHILLER [Basic, Advanced] Single VRF CHILLER Unit has following point list. Unit Status value Instance Object Object Object Name Inactive Active Number Type Text-1 Text-2 Text-3 Text-4 Text-5 Chilled Water Temperature MC_WaterTemp_xx_xxxxxx °C/F Set temperature MC_WaterTemp_Set_xx_xxxxxx °C/F Demand limit setting MC_Demand_Set_xx_xxxxxx The number of hours usage of an...
  • Page 68 BACnet Gateway setting (Continued) Interface Module (Outdoor Unit) [Basic] Interface Module (Outdoor Unit) [Basic] Single Interface Module (Outdoor Unit) has following point list. Unit Status value Instance Object Object Object Name Inactive Active Number Type Text-1 Text-2 Text-3 Text-4 Text-5 Outside temperature ODU_Outside_Temp_xx_xxxx °C...
  • Page 69 BACnet Gateway [ BACnet Gateway [Basic, , Advanced] ] BACnet Gateway has following point list. Instance Control and Object Object Name Status Value Number Monitoring Type All device OFF ALL_OFF_xx Inactive : All devices Off 0: Normal, 8: Emergency stop, 105 : Tracking in progress, DMS Status DMS_Status_xx...

  • Page 70: Other Information

    BACnet Gateway setting (Continued) Other Information Object setting when there is communication error Object setting when there is communication error If any communication error occurs between the air conditioner devices, the property will be set as below. 1. Reliability property will be set as COMMUNICATION_FAILURE. 2.

  • Page 71: Specifications

    Specifications Items Description Exterior Size 240 X 255 X 64.8 mm ( Width X Length X Height ) Weight 1.48 Kg Source DC ADAPTOR Power INPUT Voltage 100-240V 50/60Hz 1.0A OUTPUT Voltage 12V 3A RS-485 5 Channels Ethernet 10/100Mbps 1 Port SD CARD Option (Purchase SD card separately) Inter-...

  • Page 72: License

    The software included in this product contains open source software. You may obtain the complete corresponding source code for a period of three years after the last shipment of this product by contacting our support team via http://opensource.samsung.com (Please use the “Inquiry” menu.) It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM;...
  • Page 73 Memo DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 73 DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 73 2024-09-20 오후 1:40:54 2024-09-20 오후 1:40:54...
  • Page 74 DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 74 DB68-13099A-00_IBIM_LENNOX BAC DMS_CV_EN_.indd 74 2024-09-20 오후 1:40:54 2024-09-20 오후 1:40:54...
