  • Page 1 MAINS KLARGESTER SEPARATOR ALARM INSTALLATION & OPERATIONS MANUAL...
  • Page 2: Table Of Contents

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance Contents DECLARATION OF CONFORMITY ............. 3 IMPORTANT ................... 4 GENERAL DESCRIPTION ................4 GENERAL OPERATION ................4 CHANGING FACTORY SETTINGS .............. 4 ....................4 LARM ..................5 HECK NTERVAL TESTING THE PROBE SENSORS ..............5 INSTALLATION ..................
  • Page 3: Declaration Of Conformity

    Sevenoaks Kent TN15 6QY Valid for European Directives: 2014/34/EU Equipment Name and Type Separator Monitor Type 14300 Certificate Number Baseefa 08ATEX0110 Specific Marking of Explosion Protection [Ex ia Ga] IIC (-20°C ≤ Ta ≤ +50°C) ATEX Directive Marking Ex II (1) G...
  • Page 4: Important

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance IMPORTANT Note: In all cases good, standard electrical practice should be followed, and the installation must conform to the appropriate local code of practice – e.g. BS EN 60079-25 in the UK. In essence, the installation must be such that the intrinsic safety is not compromised by: - exposure to risk of mechanical damage, unauthorised modification or interference, exposure to moisture, dust and foreign bodies, excessive heat, invasion of intrinsically safe...
  • Page 5: Check Interval

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance The display will now show Alarm Type: with a flashing cursor over STD, to change this function to EXT, press the Push Switch once. Check Interval Whilst still in the Set Up mode, power down and then power up the unit, the flashing cursor will now be next to Check Intvl: - by pressing the Push Switch, the time can be altered in increments of 1 minute between 2 and 60.
  • Page 6: Connection To Control Unit

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance the distribution box and the control unit. The type of connection cable required will be dependent on the environment it is used in, the route taken and maximum allowable cable capacitance and inductance (see cable parameters in Table 8 on page 11). After making the connections in the distribution box, it is advisable to spray the terminals with a conformal coating lacquer to prevent moisture ingress before finally sealing them with waterproof putty.
  • Page 7: Probe Enable Jumper Links

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance Probe Enable Jumper Links JUMPER LINKS RELAY PROBE INPUT MAINS INPUT OUTPUT Pyramid LIQUID SILT Pollution 230V AC Prevention Ltd. PCB-1006 RELAY MAINS SIGNAL CABLES OUTPUT CABLE CABLE Figure 1 - Probe enable jumper links To enable a probe, REMOVE appropriate jumper link Probe Type Remove Link...
  • Page 8: Probe Cable Terminals

    PP/14201 High Liquid (Float) BLUE PP/14011 High Liquid GREEN/ (Optical) BROWN BLUE YELLOW PP/14210 Silt GREEN/ BROWN BLUE PP/14220 YELLOW Table 2 - Probes cable wiring connection details Figure 2 - 14300 separator alarm installation PP/MAN-8018-KLA Rev 12 (2021-05-20) 8/12...
  • Page 9: Flashing Beacon Wiring

    Table 4 – wiring to beacon from relay output BMS Relay Wiring To allow connection to a BMS when the 14300 relay output is already being used with a beacon, wire a relay as shown in Figure 3. See Accessories for relay order codes.
  • Page 10: Mechanical

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance Mechanical Protection and/or screening of the cable should also be taken into account. The maximum length of cable between probe and control unit must not exceed 200 metres or less if the values in Table 8 would be exceeded.
  • Page 11: Technical Information

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance Technical Information Electrical Supply Voltage 230V ±10% 50Hz 220V ±10% 60Hz Power Normal or consumption alarm 2.5W, 10.9VA, cos φ = 0.23 condition Galvanic isolation Safe electrical isolation acc. to EN 60079-11, voltage peak value TB3 to TB1 / TB2 358V Fusing...
  • Page 12: Accessories

    Mains Powered Klargester Separator Alarm Installation, Operation and Maintenance Accessories High Oil Probe PP/14201 High Level Probe (Float) PP/14011 High Level Probe (Optical) PP/14210 Silt Probe PP/14220 230 VAC Flashing Amber Beacon (Includes mounting bracket and glands) PP/14012 230 VAC Flashing Amber Beacon & Siren (Includes mounting bracket and glands) PP/14100 Probe Cord Guide...
