EELP HLEDG-DIV1 Series Installation Instructions

Download this manual

HLEDG-DIV1

Series

Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

• Installation and servicing of this equipment should be performed by qualified service personnel only.

• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations if

applicable.

• Do not mount near gas or electrical heaters.

• Do not use outdoors.

• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering

by unauthorized personnel.

• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

• Any modification or use of non-original components will void the warranty and product liability.

• Do not use this equipment for other than intended use.

• Allow battery to charge for 24 hours before first use.

• For use with metal enclosed wiring systems.

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

Need help?

Do you have a question about the HLEDG-DIV1 Series and is the answer not in the manual?

Page 1 HLEDG-DIV1 Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
Page 2 Surface Wall Mount Fig. 1 Mounting 1. Install the (4) mounting feet to the back of the fixture. (Fig. 1) Feet 2. Remove the (2) cover screws and set aside. (Fig. 2) Cover 3. Swing down the cover assembly and the reflector plate. (Fig. 3) Magnetic Screws Test Switch...
Page 3 Electrical Connections Fig. 5 - AC Only All electrical connections should be made inside the Orange (277VAC) or Red (347VAC) J-box. Make electrical connection as follows: Note: Cap unused leads to prevent shorting. Black (120VAC) Indicator Transformer White (Com) AC Only or With Battery Models (Fig. 5 and 6) 120, 277, or 347VAC PCB/LED Board White - Common...
Page 4 Self-Test/Self-Diagnostics (G2) Operation The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the EXIT sign. At predetermined intervals, the EXIT sign will automatically switch into battery mode. Refer to the Self-Test Features section of this page for timing details.
