Kane -DTHA2 Instruction Manual

KANE-DTHA2
Wireless Airflow,
Temperature, & Humidity
Adaptor
Instruction Manual
Inventory No: MAN00156
Rev.: 1.0221
February 2021
REQUIRES Compatible mobile device
& the FREE downloadable App
FCC INFORMATION
NOTE: This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful
interference, & (2) this device must accept any interference received, including
interference that may cause undesired operations.
INFORMATION TO THE USER
This equipment has been tested & found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses & can radiate
radio frequency energy &, if not installed & used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off &
on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment & receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING : Any changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
DISPOSAL
This symbol indicates that equipment & its accessories
CAUTION:
shall be subject to separate collection & correct disposal.
CLEANING
Periodically clean your adaptors' case using a damp cloth.
DO NOT use abrasive, flammable liquids, cleaning solvents, or strong
detergents as they may damage the finish, impair safety, or affect the
reliability of the structural components.
IMPORTANT SAFETY WARNINGS
WARNING : Read entire Safety Notes section regarding potential
hazard & proper instructions before using this meter. In this manual the word
"WARNING" is used to indicate conditions or actions that may pose physical
hazards to the user. The word "CAUTION" is used to indicate conditions or
actions that may damage this instrument.
FEATURES
• iOS or Android compatibility
® ™
• Free App
• Extension screw input for extending into air flow
• Sliding cover
GENERAL SPECIFICATIONS
• Temperature Range: 5° ~ 122°F (-15° ~ 50°C )
• Relative Humidity: 0.1% RH ~ 99.9% RH
• Operating Temperature: 5° ~ 122°F (-15° ~ 50°C)
• Storage Temperature: 5° ~ 122°F (-15° ~ 50°C)
• Dimensions: 128.5 x 49.5 x 23.6 mm (5.06" x 1.95" x 0.93")
• Item Weight: 80 gm (2.8 oz)
• Battery Type: CR2032 X 2
• Temperature Accuracy: ± 1.0°F ( ± 0.6°C)
• Power Consumption:
<8 mA
• App Compatibility:
Bluetooth
®
iOS 10 & newer
®
Android 6.0 & newer
™
SYMBOLS
Velocity Flow
Dry Bulb
Wet Bulb
Home
Units
DTHA2
Rectangle Duct
DTHA2 OVERVIEW
A. Airflow Sensor Input
B. Humidity/Temperature Sensor Input
C. Serial Number
D. Sliding Cover
E. Battery Cover
F. Extension Screw Input
4.0 & newer enabled devices
Toolbox
Relative Humidity
Dew Point
Points Average
Support
Round Duct
Time Average
A
B
C
D
E
F
