Summary of Contents for GRAND + BENEDICTS 290-3WAY
- Page 1 3-WAY :: 290-3WAY GRAND + BENEDICTS ASSEMBLY INSTRUCTIONS PAGE 1 OF 8 503.232.1988 | grand-benedicts.com GRAND + BENEDICTS...
- Page 2 3-WAY :: 290-3WAY GRAND + BENEDICTS PART LIST: 1X. WOOD PANEL A 1X. WOOD PANEL B 2X 2" DOUBLE WHEEL CASTER W/ BRAKE 2X 2" DOUBLE WHEEL CASTER NON- BRAKE 1X. BASE FRAME 16X. SBHC SCREW 16X. HEX NUT 16X. SBHC SCREW 5/16"-18 X 0.5"...
- Page 3 GRAND + BENEDICTS 3-WAY :: 290-3WAY STEP ONE BASE FRAME 1. Remove all items from the box 2. Attach casters to base using 4 screws and 4 hex nuts on each caster. SBHC SCREW 5/16"-18 X 0.5" HEX NUT 5/16"-18UNC...
- Page 4 GRAND + BENEDICTS 3-WAY :: 290-3WAY STEP TWO 1. Place the shelf into the base frame Shelf Shelf Base PAGE 4 OF 8 GRAND + BENEDICTS 503.232.1988 | grand-benedicts.com...
- Page 5 GRAND + BENEDICTS 3-WAY :: 290-3WAY STEP THREE 1. Attach frame Upright A to frame Base hole faces inward and line up the bolt holes. NOTE: Attach Upright A with the pre- drilled hole at the top facing in, toward...
- Page 6 GRAND + BENEDICTS 3-WAY :: 290-3WAY STEP FOUR 1. Position Upright A and B as shown in the diagram and secure Upright B to the base with the bolts provided. 2. Tighten the bolts with an Allen wrench. Side Upright...
- Page 7 GRAND + BENEDICTS 3-WAY :: 290-3WAY Upright frame B has STEP FIVE hole in the middle. 1. Attach Upright A to Upright B by inserting the single screw (provided) as shown in the diagram Insert screw securly through the pre drilled holes in Upright A &...
- Page 8 GRAND + BENEDICTS 3-WAY :: 290-3WAY 3-WAY ACCESSORIES | Use with Hangbar (B) Faceout 12” Projection 290-HW-FO12 | 1½” rectangular tube | Includes mounting brackets Hangbars 290-WAY-WHB-2 2” Projection Hangbar 290-WAY-WHB-9 9” Projection Hangbar | Use with Hangbar (B) Peghooks 290-HW-PEG6 6”...
