ALAULM 24-P029 Instruction Manual

Hide thumbs

Advertisement

Table of Contents

INSTRUCTION
Patio Umbrella
If you have any questions about the Patio Umbrella, please feel free to contact us.
Customer Service Email: Service@alaulm.com
24-P029
IMPORTANT
PLEASE READ BEFORE YOU COMMENCE ASSEMBLY
Follow the guidelines in this user guide to ensure correct
assembly and care for this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 24-P029 and is the answer not in the manual?

Questions and answers

Summary of Contents for ALAULM 24-P029

  • Page 1 INSTRUCTION Patio Umbrella If you have any questions about the Patio Umbrella, please feel free to contact us. Customer Service Email: Service@alaulm.com 24-P029 IMPORTANT PLEASE READ BEFORE YOU COMMENCE ASSEMBLY Follow the guidelines in this user guide to ensure correct...

  • Page 2: Specifications

    SPECIFICATIONS 34.3 inch 143.7 inch...
  • Page 3 SPECIFICATIONS 34.3 inch...
  • Page 4 CATALOG Catalog Specifica�ons......................Catalog........................Care & Instruc�ons ..................... Part List And Screw Set List..................Extra ..........................How to Assemble The Pa�o Umbrella ..............How to Adjust The Pa�o Umbrella ................

  • Page 5: Before You Begin

    NOTICE Before You Begin Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model. Review all instructions before you begin and during assembly，follow the step sequence carefully for correct results. Parts and Parts List: Check to be sure that you have all the necessary parts for building.

  • Page 6: Part List

    PART LIST Parts List Bottom Column Bottom Plastic Part Turn Handle Metal Mesh Base Umbrella Main Body 1 PC 1 PC 1 PC 1 PC 1 PC Universal Wheel 4 PCS Screw Set List A M8x30 M8x35 M8x80 M8 Nut M8 Washer 1 PC 4 PCS...
  • Page 7 PART LIST Extra Screw Set List M8x15 M8x30 M8x35 M8 Washer 1 PC 1 PC 1 PC 4 PCS...

  • Page 8: Installation Steps

    Installation steps How To Assemble Patio Umbrella Step 1 : Attach the four universal wheels(F) to the metal mesh base(E) with G1. NOTE : After installation, please step down the foot pedal to fix the universal wheels. M8*15...
  • Page 9 Installation steps Step 2 : Attach the bottom column(B) to the metal mesh base(E) with G3. NOTE : After installation, please put pebbles or sandbags in the base of the metal mesh to ensure the counterweight. M8*35...
  • Page 10 Installation steps Step 3 : Align the screw holes in the umbrella body(A) for the aluminum tie rods and the aluminum tie rods and lock them together with G4 and H. NOTE : Please tighten the screws. M8*80...
  • Page 11 Installation steps Step 4 : Insert the spring plugs on the umbrella fabric into the corresponding 4 long and 3 short umbrella bones in sequence. NOTE : Observe the order of the umbrella bones and the order of the spring plugs on the umbrella surface, with a circle of spring plugs around the umbrella surface corresponding to a circle of umbrella bones.
  • Page 12 Installation steps Step 5 : Insert the umbrella body(A) into the base. NOTE : Please refer to the diagram to find the front orientation of the umbrella to ensure that the screw holes are aligned after insertion. Ensure that at least two people collaborate on the installation.
  • Page 13 Installation steps Step 6 : Lock the column with G2. M8*30...
  • Page 14 Installation steps Step 7 : Install the bottom plastic part(C) and put pebbles or sandbags in the base. NOTE : Before opening the canopy, pebbles and sandbags must be added to the metal mesh base to ensure counterweight. Counterweight over 200 pounds are recommended. Sandbags and pebbles are not provided in this set, please prepare your own.
  • Page 15 Installation steps How To Adjust Patio Umbrella Step 1 : Hold the switch and lift it upwards so that the canopy is slightly open. NOTE : Untie the strap before you're ready to open the canopy.
  • Page 16 Installation steps Step 2 : Insert the turn handle(D) into the hole in the aluminum tilt rod and turn the handle clockwise until the canopy is fully open. NOTE : Make sure there is plenty of room for the canopy to open, and be careful about hitting anything in the process！...
  • Page 17 Installation steps Step 3 : Hold the switch and lift it upwards so that the canopy is adjusted to the right height. Five levels of tilt angle adjustment. NOTE : Make sure there is enough room for the canopy to rise to its highest point, and be careful about hitting things on the way up!
  • Page 18 Installation steps Step 4 : Insert the turn handle(D) into the hole at the lower part of the position. Turn the handle to rotate the canopy to the right position. NOTE : Turning the handle clockwise rotates the canopy clockwise. Turning the handle counterclockwise rotates the canopy counterclockwise.
  • Page 19 Installation steps Step 5 : The umbrella can be stowed in the opposite direction: lower the canopy to a suitable height by holding the handle; insert the rotating handle into the aluminum tilt rod and rotate it counterclockwise to close the canopy; lower the canopy completely.
  • Page 20 www.alaulm.com...
